Onkyo DV-SP800 Service Manual

Sacd & dvd audio/video player

Hide thumbs Also See for DV-SP800:

Service manual (95 pages)

Instruction manual (76 pages)

Brochure & specs (28 pages)

Table of Contents

Nadis

Quick Links

Need help?

Do you have a question about the DV-SP800 and is the answer not in the manual?

Questions and answers

Summary of Contents for Onkyo DV-SP800

Page 1 DV-SP800 Ref. No. 3742 102001 SERVICE MANUAL SERVICE MANUAL Schematic diagram & Printed circuit board view only SACD & DVD AUDIO/VIDEO PLAYER DV-SP800 MODEL ENTER VIDEO OFF SACD DISPLAY DIMMER AUDIO SEL MUTING TV / VCR STANDBY/ON PAUSE STOP PLAY...
Page 2: Nadis
DV-SP800 SPECIFICATIONS General Power supply USA & Canadian models AC 120 V, 60 Hz European models AC 230 - 240 V, 50 Hz South American models AC 230 240 V, 50 Hz World wide models AC 120/220 - 230 V switchable, 50/60 Hz Power consumption USA &...
Page 3: Protection Of Eyes From Laser Beam During Servicing
DV-SP800 SERVICE PROCEDURES-1 PROTECTION OF EYES FROM LASER BEAM DURING SERVICING This set employs a laser. Therefore, be sure to follow Laser Diode Properties carefully the instructions below when servicing. WARNING!! Wavelength: 650 nm SERVICE WARNING : DO NOT APPROACH THE Laser output: 0.43 mW...
Page 4 DV-SP800 SERVICE PROCEDURES-2 INITIALIZING Factory-shipped condition Push button "ON" (Mechanical SW) Press the [STOP] and [STANDBY] same time. (Wait until FL display "No Disc") . Push button "STANDBY". Others Phones level volume -------- MIN. SURR. switch ---------------- 1 Mechanical power switch -- ON Remove the solder of Laser Diode shorting Connect Pickup and DVD main circuit PC board by FFC(3 pcs).
Page 5: Front Panel
When STANDBY/ON button is pressed to ON while the POWER DIMMER button switch is set to ON, the DV-SP800 turns on and the STANDBY Toggle to control the lightness of the display (4 steps). indicator turns off. The indicator around button lights up.
Page 6 DV-SP800 PANEL VIEW-2 DISPLAY 10 11 DVD - AUDIO SACD V CD LAST TITLE GROUP CHP TRACK REMAIN S RS D.MIX COND TOTAL PROGRESSIVE 13 14 15 16 D indicator COND indicator Lights when Dolby Digital sound is selected and played back. (Only PROGRESSIVE indicator with DVDs recorded in Dolby Digital).
Page 7: Rear Panel
DV-SP800 PANEL VIEW-3 REAR PANEL COMPONENT S VIDEO VIDEO VIDEO OUTPUT AC INLET CH 1 CH 2 FRONT SURR 1 CENTER SURR 2 SACD & DVD AUDIO/VIDEO PLAYER DV-SP 800 MODEL NO. DIGITAL OUTPUT ANALOG SURR OUTPUT 1 1+2 REMOTE...
Page 9: Parts List
DV-SP800 EXPLODED VIEW (LOADING MECHANISM) / PARTS LIST EXPLODED VIEW (LOADING MECHANISM) / PARTS LIST Z101 : DVD Mechanism DB-VLD301-006 GEM1036 GEM1036 To DVDM CN151 Lubricating Oil GYA1001 Lubricating Oil Lubricating Oil GYA1001 GYA1001 Parts list REF.NO PART NO. PART NO.
Page 10: Traverse Mechanism Assy
DV-SP800 EXPLODED VIEW / PARTS LIST TRAVERSE MECHANISM ASSY 17 (Torque : 0.12+/- 0.01 N m) 4 (Adjustment Screw) 4 (Adjustment Screw) (Torque : 0.12+/- 0.01 N m) 17 (Torque : 0.12+/- 0.01 N m) PARTS LIST Mark No. Description Part No.
Page 16 DV-SP800 PC BOARD NAAR-7616 L . M U T E C 1 1 3 5 R . M U T E 1 2 2 G N D R 1 1 1 3 1 . 8 K + 1 2 V...
Page 17 SCHEMATIC DIAGRAM U1: OUTPUT TERMINAL PC Q 1 9 1 2 Q 1 9 0 2 U10: Regulator-2PC NAETC-7775 2 . 4 w 7 9 M 0 5 P Q 3 R D 2 3 1 4 0 m A R 1 9 0 1 0 A12V U8: Regulator-1PC...
Page 18 DV-SP800 U13: HEADPHONE TERMINAL PC BOARD RCUIT PC BOARD NADG-7761 NADG-7761 R 4 7 9 3 3 K Q 4 7 1 N J M 4 5 6 5 R 4 8 1 4 7 0 L 4 7 7...
Page 19 SCHEMATIC DIAGRAM SACD CIRCUIT PC BOARD SECTION U14: SACD CIR 3 . 3 3 . 3 L 1 4 0 3 B L M 2 1 B 2 2 2 I S 4 2 S 1 6 1 0 0 - 7 T C 1 4 2 6 Q 1 4 0 2 R 1 4 8 8...
Page 21 DV-SP800 U3: STANDBY LED PC BOARD NADIS-7619 NADIS-7619 7 4 8 R 7 4 9 R 7 5 0 R 7 7 1 R 7 7 2 8 2 0 1 . 8 K 3 . 9 K R 0 4 1...
Page 22 SCHEMATIC DIAGRA DISPLAY CIRCUIT PC BOARD SECTION NADIS-7618 Q 7 0 5 P I C - 3 7 0 4 3 T H 2 R 7 4 7 R 7 4 R720 8.2k 3 9 0 4 7 0 R721 5.6k 4.7k R 7 9 4...
Page 25 DV-SP800 R 2 4 1 4 Q 2 8 5 3 R 2 4 1 7 Q 2 8 5 4 C V D R V R N 2 4 0 3 R N 2 4 0 3 R 2 4 1 9...
Page 26 DV-SP800 R 2 4 1 4 Q 2 8 5 3 R 2 4 1 7 C V D R V C V 1 R N 2 4 0 3 R 2 4 1 9 Q 2 8 5 1...
Page 27 SCHEMATIC DIAGRAM OUT_V U11: VIDEO CIRCUIT PC BOARD OUT_YS OUT_C VIDEO SECTION NAVD-7632 EXCEPT <MPP> R 2 5 0 3 OUT_Y/G Q 2 5 0 1 K T A 1 5 0 4 3 . 3 R 2 2 5 2 + 3 .
Page 28 SCHEMATIC DIAGRAM U11: VIDEO CIRCUIT PC BOARD OUT_V VIDEO SECTION OUT_YS OUT_C NAVD-7632 <MPP> only R 2 5 0 3 OUT_Y/G Q 2 5 0 1 K T A 1 5 0 4 3 . 3 R 2 2 5 2 0 + 3 .
Page 30 V / Y _ I N V / Y _ I N C 2 9 3 2 4 7 0 / 6 . 3 1 B _ I N V I D E O _ G N D 7 DV-SP800 8/8 PP2P...
Page 31 SCHEMATIC DIAGRAM U12: SCART TERMINAL PC BOARD SECTION <MPP> only A _ R C H R C H _ O U T A _ G N D A _ G N D A _ L C H L C H _ O U T A _ R C H A _ L C H A U D I O...
Page 33 DV-SP800 : The power supply is shown with the marked box. : AUDIO (DIGITAL) SIGNAL ROUTE 1.8V REGULATOR...
Page 34 SCHEMATIC DIAGRAM MAIN PC BOARD-4 DVD-AUDIO DSP 150/4...
Page 36 DV-SP800 : RF (VIDEO) SIGNAL ROUTE (VD) : VIDEO DATA SIGNAL ROUTE (AD) : AUDIO DATA SIGNAL ROUTE : AUDIO SIGNAL ROUTE : AUDIO (DIGITAL) SIGNAL ROUTE (VD) (VD) (VD) AV-1 2/4, 4/4...
Page 37 SCHEMATIC DIAGRAM MAIN PC BOARD-3 2/4, 4/4 64M DRAM C219 220/4 (VD) (VD) (AD) SCRUT...
Page 39 DV-SP800 : The power supply is shown with the marked box. CN501 CLOCK GENERATOR 2/4, 4/4 (VD) (VD) CN601 3.3 5V CONVERTOR CN401 5 3.3V CONVERTOR CN602 (AD) CN302 CN801 (AD) (VD) : VIDEO DATA SIGNAL ROUTE (AD) : AUDIO DATA SIGNAL ROUTE...
Page 40 SCHEMATIC DIAGRAM MAIN PC BOARD-2 PGM FLASH MEMORY VYW1896...
Page 41 SCHEMATIC DIAGRAM MAIN PC BOARD-1 (RF) 100/6.3 RF IC CN101 (RF) CN103 FTS DRIVER CN105 CN601 (F) (F) CN104...
Page 42 DV-SP800 (RF) : RF SIGNAL ROUTE : RF (VIDEO) SIGNAL ROUTE : RF (AUDIO) SIGNAL ROUTE (AD) : AUDIO DATA SIGNAL ROUTE : FOCUS SERVO LOOP LINE : TRACKING SERVO LOOP LINE : SLIDER SERVO LOOP LINE C205 VCH1195 150/4...
Page 43 P2801A P902B P1810 P471B P106A CN401 P903A Q1906 P902A P1701B P901B CN501 P1701A P1401A...
Page 44: Spindle Motor
DV-SP800 PRINTED CIRCUIT BOARD VIEW MAIN CIRCUIT PC BOARD DB-VPB308 SIDE B STEPPING SPINDLE PICKUP MOTOR CN601 MOTOR ASSY (CARRIAGE) IC251 Q103 IC271 Q109 Q108 Q130 IC903 IC909 IC910 IC608 Q271 Q281 IC101 Q142 Q161 IC913 IC701 IC902 IC612 IC905...
Page 45 DV-SP800 PRINTED CIRCUIT BOARD VIEW MAIN CIRCUIT PC BOARD DV-VPB308 SIDE A IC401 IC911 IC912 IC901 Q101 Q118 IC281 Q543 IC351 IC532 IC211 IC261 Q102 Q116 Q107 Q542 Q112 Q571 IC210 IC702 Q115 Q117 Q291 Q292 IC291 IC201 IC491 IC601...
Page 46 DV-SP800 PRINTED CIRCUIT VIEW U2: Display circuit PC board NADIS-7618 From soldering side view Component side...
Page 47 DV-SP800 PRINTED CIRCUIT VIEW U2: Display circuit PC board NADIS-7618 From soldering side view R748 R750 R749 R719 R066 R052 R759 R713 R712 R794 R711 R710 R709 R780 R781 R795 R723 R722 R725 R724 R727 R726 R051 D701 C702 R791...
Page 48 DV-SP800 PRINTED CIRCUIT BOARD VIEW U12: SCART TERMINAL PC BOARD <MPP> only : Component side pattern : Soldering side pattern Component side view...
Page 49 DV-SP800 PRINTED CIRCUIT VIEW U14: SACD CIRCUIT PC BOARD NADG-7761 U13: HEADPHONE TERMINAL PC BOARD NAAF-7617 Component side view : Component side pattern : Soldering side pattern 2513776 2513776 25137 Component side view...
Page 50 DV-SP800 PRINTED CIRCUIT BOARD VIEW From Soldering side view U3: STANDBY LED PC BOARD NADIS-7619 NCDIS-7619 NCDIS-7619 25137619 25137619 Q722 STANDBY S723 VIDEO CIRCUIT DIMMER Component side Soldering side U4: POWER TRANSFORMER PC BOARD NAPS-7620 U5: INLET TERMINAL PC BOARD...
Page 52 DV-SP800 PRINTED CIRCUIT BOARD VIEW From Soldering side view U3: STANDBY LED PC BOARD NADIS-7619 NCDIS-7619 NCDIS-7619 25137619 25137619 Q722 STANDBY S723 VIDEO CIRCUIT DIMMER Component side Soldering side U4: POWER TRANSFORMER PC BOARD NAPS-7620 U5: INLET TERMINAL PC BOARD...
Page 53 DV-SP800 PRINTED CIRCUIT BOARD VIEW From Sodering side view U9: VOLTAGE SELECTOR PC BOARD NASW-7624 <MWS, MWR, MPS> only LOAB ASSY (DVD MECHANISM) S992 S992 NCSW-7624 25137624 J905B J906B J904A CN103 LOADING U6: POWER SWITCH PC BOARD MOTOR SIDE A...
Page 54 DV-SP800 PRINTED CIRCUIT BOARD VIEW U11: VIDEO CIRCUIT PC BOARD : Component side pattern : Soldering side pattern NAVD-7632 Component side view...
Page 55 DV-SP800 FL TUBE VIEW Pin connection DVD-AUDIO DVD-AUDIO SACD V CD SACD V CD PBCRANDOM RANDOMMEMORY MEMORY 1A-B 1A-B LFE LAST D.MIX COND. PRO LOGIC PRO LOGIC TITLE TITLE GROUP GROUP COND. CHP TRACK TRACK TOTALREMAIN REMAIN PROGRESSIVE PROGRESSIVE [5G,3G]...
Page 56: Dv-Sp800
DV-SP800 Disassembly of the Traverse Mechanism Assy-1 Remove the top cover and Tray Panel. Remove the Loading Mechanism Assy (Screws 4). Remove the Tray panel and Front Panel. Remove a screw. Remove the Bridge (Screw 1). Cautions: Screw is locked with Silicone Adhesive.
Page 57 DV-SP800 Disassembly of the Traverse Mechanism Assy-2 When Removing The Pickup Assy Remove two screws. Remove the Pickup Flexible Cable. Cautions: Screw is locked with Screw Lock. Please lock it with Screw Lock when installs it. Screw lock Slider Hold Spring...
Page 58 DV-SP800 Disassembly of the Traverse Mechanism Assy-3 Styling the Pickup Flexible Cable Fold a edge of lining part of the Pickup Flexible Cable. Insert the Pickup Flexible Cable in connector, and lock it surely. Pickup Assy Bottom View Conducting plane...
Page 59: Adjustment Procedures
DV-SP800 ADJUSTMENT PROCEDURES-1 ADJUSTMENT OF DVD MECHANISM-1 1. Adjustment items and location Tangential and Radial Height Coarse Adjustment Tangential Radial adjustment adjustment DVD Jitter Adjustment screw screw How to initialize the Focus Sweep Setting [Electrical Part] Electrical adjustments are not required.
Page 60 DV-SP800 ADJUSTMENT PROCEDURES-2 ADJUSTMENT OF DVD MECHANISM-2 A. Connection VIDEO OUT VIDEO IN B. Test mode SETTING THE REMOTE CONTROLER Press 1 as holding down DVD. Remote controller C: TEST MODE: ON RC-484M Part No. 24140484 STANDBY switch is ON.
Page 61 DV-SP800 ADJUSTMENT PROCEDURES-3 ADJUSTMENT OF DVD MECHANISM-3 TEST MODE: PLAY An address is displayed < When playback with the target address of disc (DVD)> For example, when playback with # 30000 During PLAY Press keys in order 030000 TEST MODE: OFF Press the "STANDBY"...
Page 62 DV-SP800 ADJUSTMENT PROCEDURES-4 ADJUSTMENT OF DVD MECHANISM-4 DVD Jitter Adjustment Playback method of inner and outer address for the purpose is refererd to "5. TEST MODE". Use disc: GGV1025 Test mode Play the DVD test disc at outer track Monitor...
Page 63 DV-SP800 ADJUSTMENT PROCEDURES-5 ADJUSTMENT OF DVD MECHANISM-5 Initialize the Focus Sweep Setting Purpose: To set the sweep which was correct with the individual Traverse mechanism. RC-484M CLEAR Monitor Memory Clear!!! PL Region : X1 ROM Version : 1.128 NOTE: When Change the mechanism or pickup mechanism,...
Page 64 DV-SP800 ADJUSTMENT PROCEDURES-6 CHECKING THE ERROR RATE Setting remote controller Press the hold down DVD button, then press 1 button. Check the CD error rate CD test disc Waiting for 8 seconds Play [Example] CD error rate = 33 / (7.35 x 5 x 1000) = 0.9 x 10 SPEC : CD error rate 3.26 x 10...
Page 65 DV-SP800 UPGRADE FIRMWARE-1 Prepares for upgrade firmware ID DATA DISC (DB-VPB302) REMOTE CONTROLLER for UPGRADE Part No. 0R117 Part No. 24140484 (RC-484M) It is remote control of the exclusive use for inputting ID data and upgrade It is used for the input of ID data.
Page 66 DV-SP800 UPGRADE FIRMWARE-2 Connections Rear panel view COMPONENT S VIDEO VIDEO VIDEO OUTPUT AC INLET CH 1 CH 2 FRONT SURR 1 CENTER SURR 2 SACD & DVD AUDIO/VIDEO PLAYER DV-SP 800 MODEL NO. DIGITAL OUTPUT ANALOG SURR OUTPUT 1 1+2...
Page 67 DV-SP800 UPGRADE FIRMWARE-3 Flow chart In the case of upgrade firmware In the case of replace of the DVD main board Replace of the DVD main board Check the firmware Setting the regional code Download the firmware Except UDD1N type...
Page 68 DV-SP800 UPGRADE FIRMWARE-4 Check the firmware Please operate it by remote controller (RC-484M). 1. Press the DVD button. 2. Press SETUP button. 3. Operate cursor button and select General menu. Refer to 4. Operate cursor button and select Setup Menu mode.
Page 69: Download Firmware
DV-SP800 UPGRADE FIRMWARE-5 Download firmware 1. Start MS-DOS prompt using the start-up menu of PC. Windows of MS DOS prompt Example C: WINDOWS>_ 2. Press the Enter button, after input cd.. by the keyboard. >_ 3. Press the Enter button, after input >cd dvsp800fw...
Page 70 DV-SP800 UPGRADE FIRMWARE-6 Download procedures 5. Connect the PC and set. 6. NO DISC. codition. 7. Turn ON the power supply switch of the unit. 8. Press the Enter key of PC. 9. Press the Enter button, after input MO by the keyboard.
Page 71 DD-SP800 UPGRADE FIRMWARE-7 Download procedures Completed download view The state which download completed Download was completed.
Page 72 Region cord is set automatically. MDD1N MPP2P UPT3P UDT3P UGK3P UPA4P UDS4P UGR6P FL display NO DISC 3. Turn OFF power of DV-SP800. 4. Disconnect DV-SP800 and PC. Confirm the firmware and regional cord Refer to about check procedure. (Page 4)
Page 73 DV-SP800 UPGRADE FIRMWARE-9 Setting the ID number. 1. Input the ID number recorded before using the number button. (Refer to " Check ID number" TV Monitor [Player's ID Number Setting] ID Number? > 0 0 0 0 0 0 0 0 1 Number key <PLAY>...
Page 74 DV-SP800 UPGRADE FIRMWARE-10 Confirm the ID number For use the RC-484M remote controller RC-484M 1. Power ON and standby ON of the unit. Part No. 24140484 2. Press RETURN key. 3. Press STEREO key before displayed TV monitor. When key number clear, press CLEAR key.
Page 75 DV-SP800 ERROR CODE ERROR CODE Error codes that are displayed on the FL display. FL Display Possible causes Operation of the unit The sound may not out AV1 VER AV-1 chip is not a match with the program of system controller with the specific audio.
Page 76: Trouble Shooting
DV-SP800 TROUBLE SHOOTING Condition When No Power ON FL is not turned ON FL indication is unusual START Power ON Blow out thermistor or fuse on the POWER TRANSFORMER PC BOARD. (Check the each voltage.) FL controller IC (Q70I) on the DISPLAY CIRCUIT PC BOARD is damaged.
Page 77 DV-SP800 PACKING VIEW A952, A065 A953,A954 Tape A901 A530 <MDD> only A903 A951 A833 <MPP> only A905 RC-498DV A906 A051 A982 <MWT, A902 MWS> P981 A057 A907 <MPP> only Front side A051 A061 A415 A417 A416...
Page 78 EXPLODED VIEW PARTS LIST B : Black color S : Silver color G : Golden color <MDD1N> : U.S.A. and Canadian area, Regional code: 1, TV system: NTSC <MPP2P> : European area, Regional code: 2, TV system: PAL <MWT3P>: South East Asia and Middle East area, Regional code: 3, TV system: PAL <MPS4P>: Australian area, Regional code: 4, TV system: PAL <MWS4P>: South America area, Regional code: 4, TV system: PAL <MWR6P>: Chinese, Regional code: 6, TV system: PAL...
Page 79 SCREW 3TTB+8B(BC), B 838430088 SCREW 3TTB+8B(UN), S, G 838930088 A401 F PANEL 27212429 B <MDD1N> A401 F PANEL B <MPP2P>, B <MPS4P>, 27212432 B <MWT3P>, B <MWS4P> A401 F PANEL S <MPP2P> 27212430 A401 F PANEL G <MWT3P>, 27212431 G <MPS4P>, G <MWR6P> A403 BADGE BADGE, B...
Page 80 Inlet terminal PC board assy NAPS-7621-1F <MWR6P> 1H490521-1F Power switch PC board assy NASW-7622-1A <MDD1N> 1H490522-1A Power switch PC board assy NASW-7622-1B <MPP2P> 1H490522-1B Power switch PC board assy NASW-7622-1C <MWT3P> 1H490522-1C Power switch PC board assy NASW-7622-1D <MPS4P> 1H490522-1D Power switch PC board assy NASW-7622-1E <MWS4P>...
Page 81 EAN LABEL 29363197 S <MPP> A417 EAN LABEL G <MWT>,G <MPS>,G <MWR> 29363198 A419 LABEL LABEL SHEET <MDD> 29360840 A530 WRNTY CARD 29365090A (ONKYO) <MDD> A833 POLY BAG 350*250 29100097-1A A901 PIN CORD AS RCA3P(YWR) 2010379 A902 BATTERY UM-3 3010054 A903 PLUG CORD 3.5-MINI PLUG (RI)
Page 82 PRINTED CIRCUIT BOARD PARTS LIST <MDD1N> : U.S.A. and Canadian area, Regional code: 1, TV system: NTSC <MPP2P> : European area, Regional code: 2, TV system: PAL <MWT3P>: South East Asia and Middle East area, Regional code: 3, TV system: PAL <MPS4P>: Australian area, Regional code: 4, TV system: PAL <MWS4P>: South America area, Regional code: 4, TV system: PAL <MWR6P>: Chinese, Regional code: 6, TV system: PAL...
Page 83 C1213 TF C ECQ-B50V-101K 374721015 C1214 TF C ECQ-B50V-101K 374721015 C1215 VX C CE04W16V-470M(VX) 393344717 C1216 VX C CE04W16V-470M(VX) 393344717 C1221 TF C ECQ-B50V-681J 374726814 C1222 TF C ECQ-B50V-681J 374726814 C1223 TF C ECQ-B50V-152J 374721524 C1224 TF C ECQ-B50V-152J 374721524 C1225 TF C ECQ-B50V-102J...
Page 84 C1924 ELECT C CE04W6.3V-100M 354721019 C1925 ELECT C CE04W6.3V-1000M 354721029 C1926 ELECT C CE04W50V-4.7M 354780479 C1927 ELECT C CE04W16V-10M(VZ) 394541007 C1929 ELECT C CE04W6.3V-470M(VZ) 394524717 C1931 ELECT C CE04W16V-47M 354744709 C1934 ELECT C CE04W6.3V-220M(VZ) 394522217 CN401 SOCKET NSCT-40P2509 25052612 CN501 SOCKET NSCT-40P2509 25052612...
Page 85 Q1102 CS4392-KS 22241635R2 Q1103 NJM2068V 22241869R2 Q1104 NJM2068V 22241869R2 Q1105 NJM4565V 22241554R2 Q1106 NJM4565V 22241554R2 Q1109 2SD655-E 2211705 Q1109 or 2SD655-F 2211706 Q1110 2SD655-E 2211705 Q1110 or 2SD655-F 2211706 Q1111 2SD655-E 2211705 Q1111 or 2SD655-F 2211706 Q1112 2SD655-E 2211705 Q1112 or 2SD655-F 2211706 Q1113...
Page 86 Q1134 or 2SC2712-Y 2213144R2 Q1134 or 2SC2712-GR 2213145R2 Q1201 IC(REGURATOR) 74VHC157FT 22274157ER2 Q1202 CS4392-KS 22241635R2 Q1203 NJM2068V 22241869R2 Q1204 NJM2068V 22241869R2 Q1205 NJM4565V 22241554R2 Q1206 NJM4565V 22241554R2 Q1209 HN1C03F-B 2216141R2 Q1210 HN1C03F-B 2216141R2 Q1211 HN1C03F-B 2216141R2 Q1212 HN1C03F-B 2216141R2 Q1213 KRC107S 2216340R2 Q1213 or...
Page 87 Q1703 PHT CP GP1FA551TZ 24120085 Q1901 IC (REGULATOR) 7812 222780124 Q1901A HEAT SINK RAD-178 27160518 Q1901B SCREW 3P+10FN(BC) 82143010 Q1903 IC (REGULATOR) 78M12HF 222780125 Q1903A RADIATOR RAD-51(B) 27160220 Q1903B SCREW 3P+10FN(BC) 82143010 Q1904 IC (REGULATOR) 79M12HF 222790125 Q1904A RADIATOR RAD-51(B) 27160220 Q1904B SCREW...
Page 88 D708 SEL2E10C 225374 D711 ZENER D UDZS4.7B 224550470R2 E703 FUSE LABEL T2.5A 250V_F911,F912 29363314 E703 FUSE LABEL T2.5A 250V_F911,F912 29363314 E703 FUSE LABEL T2.5A 250V_F911,F912 29363314 E703 FUSE LABEL T2.5A 250V_F911,F912 29363314 E704 FUSE LABEL T800mAL250V 29362519 E704 FUSE LABEL T800mAL250V 29362519 JL771...
Page 89 Q721 KRC107S 2216340R2 Q721 or RN1407 2216260R2 Q722 KRC107S 2216340R2 Q722 or RN1407 2216260R2 S721 PUSH SW NPS-111-S662 25035699 S722 PUSH SW NPS-111-S662 25035699 S723 PUSH SW NPS-111-S662 25035699 U4: POWER TRANSFORMER PC BOARD (NAPS-7620) DESTINA- CIRCUIT NO. PART NAME DESCRIPTION PART NO.
Page 90 S991 or P SW NPS-111-L512P 25035550 U8: REGULATOR_1 PC BOARD (NAETC-7774) DESTINA- CIRCUIT NO. PART NAME DESCRIPTION PART NO. REMARK TION C1919 ELECT C CE04W6.3V-220M 355722219 C1936 ELECT C CE04W35V-10M(S) 353761009 P1904 JUMPER LEAD JL3 250 H 3J250606H P1904A WIRE HOL NSCT-3P894 25051107 Q1912...
Page 91 P2402 SOCKET NSCT-8P1743 25051956 P2501 PIN JACK NPJ-3PDGLR429 25045622 MPP2P P2801A SOCKET NSCT-20P2483 25052586R2 MPP2P P2801B SOCKET NSCT-20P2483 25052586R2 MPP2P P2903 SOCKET NSCT-21P2557 25052660 MPP2P P2904 SOCKET NSCT-21P2557 25052660 MPP2P P902B PLUG NPLG-10P138 25055154 Except P903B PLUG NPLG-6P134 25055150 MPP2P Q2001 PM0033A 22241827R3...
Page 92 Q2602 or KTC3875-Y 2216174R2 Q2602 or 2SC2712-Y 2213144R2 Q2603 MAX4016ESA 22241441R2 MPP2P Q2651 KTA1504-GR 2216185R2 MPP2P Q2651 or 2SA1162-GR 2214375R2 MPP2P Q2651 or KTA1504-Y 2216184R2 MPP2P Q2651 or 2SA1162-Y 2214374R2 MPP2P Q2701 KTA1504-GR 2216185R2 MPP2P Q2701 or 2SA1162-GR 2214375R2 MPP2P Q2701 or KTA1504-Y 2216184R2...
Page 93 Q2905 or KTC3875-Y 2216174R2 Q2906 2SC2712-GR 2213145R2 Q2906 or KTC3875-GR 2216175R2 Q2906 or 2SC2712-Y 2213144R2 Q2906 or KTC3875-Y 2216174R2 Q2907 4053BF(TC4053BF) 222840531R2O Q2908 4053BF(TC4053BF) 222840531R2O Q2909 2SC2712-GR 2213145R2 Q2909 or KTC3875-GR 2216175R2 Q2909 or 2SC2712-Y 2213144R2 Q2909 or KTC3875-Y 2216174R2 Q2910 RN1407 2216260R2...
Page 94 L1405 CHOKE COIL BLM21B222SPT 230921R2 L1406 CHOKE COIL BLM21B222SPT 230921R2 L1407 CHOKE COIL BLM21B222SPT 230921R2 L1408 EMIFIL BK1608LL241-T 230959R1 L1409 EMIFIL BK1608LL241-T 230959R1 L1410 EMIFIL BK1608LL241-T 230959R1 P1401B SOCKET NSCT-20P2200 25052303 Q1401 CXD2753R 22241829R3 Q1402 IS42S16100-7T 22241686R2 Q1403 TC74VHC74FT 22274074ER2O Q1404 TC7SH08FU 22241830R2O...
Page 95 Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8111 Fax: 072-833-5222 ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 E-mail: onkyo@onkyousa.com ONKYO EUROPE ELECTRONICS GmbH Industriestrasse 20, 82110 Germering, GERMANY Tel: 089-849-320 Fax: 089-849-3265 E-mail: info@onkyo.de...
