Initialization

The initialization interface to the RFID module is auto baud detectable by the printer. Commands
necessary to enable, configure, read, write, and verify RFID tags are detailed below, arranged in the
following sections: Database / Menu, Data Input, Interfaces, Option Feedback, and Diagnostics.

Database / Menu

Menu mode accesses the following system level data (below, menu selections are listed on the left and
available parameters are listed on the right; see the Operator's Manual for details):
PRINTER OPTIONS
RFID
MODE
POSITION
HF SETTINGS
TAG TYPE
AFI VALUE
AFI LOCK
DFSID VALUE
DFSID LOCK
EAS VALUE
AUDIO INDICATOR
ERASE ON FAULT
UHF SETTINGS
TAG TYPE
TAG DATA SIZE
POWER ADJUST
KILL CODE
ACCESS CODE
LOCK CODE
LOCK AFTER WRITE
RETRY ATTEMPTS
AUTO DETECT TAG
COMMUNICATIONS / HOST SETTINGS
OPTION FEEDBACK
DISABLED, HF (Securakey), UHF CLASS 1 (Alien),
UHF MULTI-PROTOCOL (Samsys)
0.00 - 4.00 (If 0.00 then the Print Position is used to
encode tag; otherwise, the Presented Position is used.)
ISO 15693, TI, PHILIPS, ST LRI512, ST LRI64
2 Character Hex Value (Industry Codes)
ENABLED or DISABLED
2 Character Hex Value (Industry Codes)
ENABLED or DISABLED
2 Character Hex Value (Mfg. Codes)
BUZZER ON or BUZZER OFF
ENABLED or DISABLED
EPC 0, EPC 0+ MATRICS, EPC 0+ IMPINJ, EPC 1,
UCODE EPC 1.19, EM 4022/4222, GEN 2 (Samsys)
64-BIT or 96-BIT (Samsys)
-4 dBm to +4 dBm (Samsys)
In the form: B3, B2, B1, B0
In the form: B3, B2, B1, B0
2 Character Hex Value (Alien)
ENABLED or DISABLED
0 – 9
Moves the label to find the tag and sets the present
distance. This will write to the tag in order to verify.
DISABLED, SCANNER, RFID HEX, RFID ASCII
4
