Installing the Option
If RFID is already installed, proceed to "Programming Information"; otherwise, follow the steps below:
1. Turn off the power switch and unplug the printer.
2. Open the cover. Remove the three Screws that
secure the Front Cover Panel to the printer.
3. Position the RFID Front Cover Panel on the
printer and re-install two of the previously
removed screws, as shown.
Front Cover
Panel
RFID Front
Cover Panel
2
Screws
Screws
