TransPort ® WR41 Utility Installation Guide
3.2 Interior Features
1. Primary Cellular Antenna Cable
2. Secondary Cellular Antenna Cable
3. SIM Slot
4. Ethernet Switch
5. RS232 (RJ45) Connector
6. Battery Mounting Bracket
7. Protected Bonding Ground
8. AC Wiring Terminal Block/Protected Earth Ground (PE)
9. Battery Terminal
1
2
3
6
4
5
7
7
8
9
Page 9
