Summary of Contents for Digi WR41v1
- Page 1 Test a WR41v1 Router How to test a WR41v1 router step by step. Technical Support March 2016...
-
Page 2: Table Of Contents
Contents Introduction ............................3 Outline ............................3 Assumptions ..........................3 Corrections ........................... 3 Version ............................3 Equipment Required ..........................4 Set up the test equipment ........................4 Perform Low Level Tests ........................6 Program the Flash ..........................7 Using Flashwriter ......................... 7 Reviewing Flashwriter error messages.................. -
Page 3: Introduction
1 INTRODUCTION 1.1 Outline This guide will enable a competent technician to test the hardware of a WR41V1 router. NOTE: The WR41V1 router may also be referred to as WR41. If the tests in sections 4 – 10 all complete without a problem then the router can be returned to service. -
Page 4: Equipment Required
It is possible to use another appropriately configured WR41V1 as a switch/hub. It is essential that the PC’s Ethernet communication interface is configured correctly and has an IP address. The best strategy is normally to connect both your PC and the WR41V1 to your normal office LAN. ... - Page 5 Extract the contents of the zip file to a folder in the root directory of the test PC. Download the latest WR41V1 Flashwriter zip file and extract the contents to a single folder on your PC: http://transport.digi.com/digi/firmware/flashwriter/XXXX/WR41/WR41-XXXX.zip where XXXX is the current firmware version.
-
Page 6: Perform Low Level Tests
(E.g. for COM port 2) Hold the reset button in and then power up the WR41V1. This may take a little practise. Check the output of the imxtest program. If the test passes then the following output will be seen: If the SDRAM, FLASH or SRAM test fails then the product should be returned via RMA. -
Page 7: Program The Flash
Launch Flashwriter from the start menu. Select the communications port number (PC comm. port number) to which the WR41V1 is connected. (On most PC’s with a built in serial port, this will be “1” OR “2”. Leave the other settings are their default values (TFTP and Event driven mode ONLY ticked): If your PC has more than one network adapter, be sure to select the one that represents the connection to LAN illustrated in section 3. - Page 8 In the file dialogue, select the “ALL” file you extracted from the ZIP earlier: And click “Open”. The following message will appear: Page | 8...
- Page 9 It is critical that the correct selection is made at this point. Note characters 6 and 7 of the part number (SKU) on the approval label. In the example below these are “U0”: Refer to the following table to determine which selection to make: Characters 6 &...
- Page 10 7 Sierra Wireless 3G module 13 Ericsson F3507g/F3607gw/F3307/F5521gw HSDPA module 17 Gobi UMTS or 18 Gobi CDMA 13 Ericsson F3507g/F3607gw/F3307/F5521gw HSDPA module 13 Ericsson F3507g/F3607gw/F3307/F5521gw HSDPA module 17 Gobi UMTS Once you click ok, the following message should appear: Click “OK”, hold in the reset button (and keep it held) then plug in the power. This may take a bit of practise.
- Page 11 Eventually you should be prompted to enter the 6 digit serial number. (Refer to the label under the WR41V1 to find the correct serial number.) Page | 11...
- Page 12 Click OK Next enter the hardware revision: Click OK The .ALL file should start to load: Page | 12...
- Page 13 After reboot, it should check the interface to the W-WAN module (if one is fitted): After this and other tests, it should report “Device upgraded successfully”: Page | 13...
-
Page 14: Reviewing Flashwriter Error Messages
This means the WR41V1 has been successfully flashed and correct communication with the internal radio module (if fitted) verified. At this stage the following hardware components (and more) have been successfully tested : FLASH SDRAM SRAM ... -
Page 15: Check Leds
RMA with reason. “Flashwriter TFTP failed to complete” Unable to communicate with device after Check to see if the router is continuously rebooting. Please contact Digi reboot. technical support for help. -
Page 16: Check W-Wan Connectivity
7 CHECK W-WAN CONNECTIVITY 7.1 Test SIM detection switch With the router powered off, insert a SIM card into BOTH SIM slots of the WR41V1. Access the web user interface of the WR41V1. Click the button to load the Java Applet front panel display. -
Page 17: Test Sim 1
7.2 Test SIM 1 Ensure that an antenna is connected and the router is located in an area with good signal strength. Navigate to: Configuration - Network > Interfaces > Advanced > PPP 1 > Mobile Change W-WAN SIM: from “Any” to “SIM 1” Click Apply Next navigate to Configuration - Network >... -
Page 18: Test Sim 2
If a valid IP address is NOT found, please download debug.txt and email this to Digi technical support for assistance. 7.3 Test SIM 2 Navigate to: Configuration - Network > Interfaces > Advanced > PPP 1 > Mobile Change “W-WAN SIM: from “SIM 1” to “SIM 2”... -
Page 19: Check W-Wan Signal Strength
A valid IP address for SIM 2 should be seen – Notice it is different to the one assigned for SIM 1 If a valid IP address is NOT found, please download debug.txt and email this to Digi technical support for assistance. -
Page 20: Check Usb Ports
9 CHECK USB PORTS Insert a valid USB device into the USB slot on the front of the WR41V1. A valid USB device is a device that you know works in a WR41V1 because you have tried it previously. Examples to try: ... -
Page 21: Check Serial Ports
WR41V1,please request an RMA with code: “External USB port test failed” 10 CHECK SERIAL PORTS With the PC serial port still connected to “Serial 0” of the WR41V1, launch Flashwriter again, ensure that the correct PC comm. port number is selected and click on “Check Serial”” from the Advanced menu of FlashWriter. - Page 22 As you are testing “Serial 0” just click OK. If any error messages occur, please refer to the following table to identify the best course of action: Error Message Recommendation Flashwriter is unable to establish contact with the router under test. Please check the cabling and try again.
