TG5200CE.fm.fm Page 1 Tuesday, March 23, 2004 11:37 AM
5.8 GHz Expandable Cordless Phone System

Operating Instructions

KX-TG5200C
Model No.
Pulse-or-tone dialing capability
This unit is Call Display compatible. To display the caller's name and phone
number, you must subscribe to Call Display service.
PLEASE READ BEFORE USE AND SAVE.
Charge the battery for 6 hours before initial use.
For assistance, please call 1-800-561-5505 or visit us at www.panasonic.ca
