HD AVC/H.264 Encoder with Multiplexer,
with 8x HDMI or 8x HD-SDI Input,
with ASI & IP Output
EMU-8220 with 8x HDMI Input
EMU-8230 with 8x HD-SDI Input
User's Manual
NMS Version: 2.2.5
SW: 0.17F
HW: 0.8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EMU-8220 and is the answer not in the manual?

Questions and answers

Related Manuals for Irenis EMU-8220

Summary of Contents for Irenis EMU-8220

  • Page 1 HD AVC/H.264 Encoder with Multiplexer, with 8x HDMI or 8x HD-SDI Input, with ASI & IP Output User’s Manual EMU-8220 with 8x HDMI Input EMU-8230 with 8x HD-SDI Input NMS Version: 2.2.5 SW: 0.17F HW: 0.8...

  • Page 2: Table Of Contents

    DIRECTORY Chapter 1 Product Introduction ......................1 1.1 Outline ..............................1 1.2 Main Features ........................... 1 1.3 Specifications ............................ 1 1.4 Principle Chart ........................... 2 1.5 Appearance and Illustration ......................3 Chapter 2 Installation Guide ........................5 2.1 Acquisition Check ..........................5 2.2 Installation Preparation ........................

  • Page 3: Chapter 1 Product Introduction

    8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 Chapter 1 Product Introduction 1.1 Outline The 8-in-1 MPEG-4 AVC/H.264 HD encoder is our newest professional HD audio & video encoding and multiplexing device with powerful functionality. It is equipped with 8 HDMI (or SDI) channels input supporting MPEG-4 AVC/H.264...

  • Page 4: Principle Chart

    8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 8×HDMI (or SDI) inputs Input 1 ASI input, BNC interface 1920×1080_60P, 1920×1080_50P 1920×1080_60i, 1920×1080_50i Resolution 1280×720_60P, 1280×720 _50P 720×576_50i, 720×480_60i Encoding MPEG-4 AVC/H.264 Video Bit-rate 0.8Mbps~19Mbps (each channel)

  • Page 5: Appearance And Illustration

    8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 1.5 Appearance and Illustration Front Panel Illustration: Indicate area: All indicators will light on when the device is on the current working state. LCD Screen Power Indicator...
  • Page 6 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 8 * HDMI/SDI Input Ports ASI Input Port 2 * ASI Output Ports Data Port (for IP Signal Output) NMS (Network Management Port) Power Switch and socket...

  • Page 7: Chapter 2 Installation Guide

    8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 Chapter 2 Installation Guide 2.1 Acquisition Check When users open the package of the device, it is necessary to check items according to packing list. Normally it should include the following items: ...
  • Page 8 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 Item Requirement When user installs machine frame array in one machine hall, the Machine Hall Space distance between 2 rows of machine frames should be 1.2~1.5m and the distance against wall should be no less than 0.8m.

  • Page 9: Wire's Connection

    8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 All the machine frames should be connected with protective copper strip. The grounding wire should be as short as possible and avoid circling. The area of the conduction between grounding wire and grounding strip should be no less than 25mm 2.2.5 Device Grounding...
  • Page 10 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 2.4.2 SDI input cable illustration: 2.4.3 ASI output cable illustration: 2.4.4 Network Cable illustration (CAT5): 2.4.5 HDMI input interface connection User can firstly find the HDMI interface on the device according to the connector mark described on the rear panel illustration, and then connect the HDMI cable (in the accessories).
  • Page 11 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 2.4.6 SDI input interface connection User can firstly find the SDI interface on the device according to the connector mark described on the rear panel illustration, and then connect the SDI cable (in the accessories). One end is connected to the head-end equipment while the other end to the encoder’s SDI input port.
  • Page 12 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 2.4.9 NMS Connection Users can firstly find the NMS interface on the device according to the connector mark described on the rear panel illustration, and then connect the network (CAT5). One end of the network cable is connected to the encoder’s NMS connecter, while the other end to the computer or the PC.

  • Page 13: Chapter 3 Operation

    8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 Chapter 3 Operation 8 in 1 MPEG-4 AVC/H.264 HD Encoder’s front panel is user operating interface. Before operating, user can decide whether directly use the default setting or customize the input and output parameters setting.

  • Page 14: Video Setting

    8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 ►1 Input Setting 2 ASI Setting 3 Output Setting 4 Network Setting ►5 Saving Config 6 Loading Config 7 Version 8 Language The option with “►” is the current selection, users can press the ENTER key to enter the specified submenu to modify the device parameter.
  • Page 15 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 0.8M~19M), the specific steps are displayed as follows: 1.1.1.1 Bitrate 8.000Mbps  Bitrate Mode User can choose CBR & VBR at this menu. CBR (Constant Bit-rate) means that the bit-rate will be a constant value.

  • Page 16: System Settings

    8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 1.1.2.1 Bit Rate 1.1.2.2 Format  Audio Bit Rate Setting User can set the input audio bit-rate by pressing the enter key to enter the main editing interface.
  • Page 17 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 ►1.1.3.5 PCR PID 1.1.3.6 IP Enable 1.1.3.7 Out Address 1.1.3.8 Out Port ►1.1.3.9 Null PKT Under this interface, users can set the corresponding system parameters, after the modification, users can press enter key to take the modification into effect.
  • Page 18 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230  Out Address/Out Port Setting User can modify the out address and out port in below interfaces. 1.1.3.7 Out Address 224.002.002.002 1.1.3.8 Out Port 1002  Null Packet 1.1.3.9 Null Packet...
  • Page 19 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 2.1 Parse ASI Prog Prog: 006 Out: 003 ► 001 HK1 √ 002 HK2 3.2.3 Output Setting By press the enter key in the main editing interface, use can set the device output parameter. The device will display the following page after users pressing the enter key.

  • Page 20: Asi Output

    8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 ► 3.3 IP Out Port 01001 3.2.3.4 Trans Stream ID Users can set the device TS ID in this interface after pressing the ENTER key to enter the main editing page.

  • Page 21: Network Setting

    8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 3.2.3.9 TS Package Num User can set the amount of TS packages by entering into below interface. 3.9 TS Package Num 01/02 3.9 TS Package Num 02/02 3.2.4 Network Setting...
  • Page 22 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 the router. 3.2.5 Saving Configuration Users can save the modification by pressing the enter key, and it will display the following interface when user press the enter key.

  • Page 23: Chapter 4 Snmp Operation

    8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 Chapter 4 SNMP Operation Network Management System SNMP Network management system is applied to digital TV equipment operation, control and management and parameters setting, etc. It centralizes digital TV equipment through network.
  • Page 24 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 User can create a device node tree in the left column by adding, modifying and deleting the device node. This software provides a powerful node operation function, and the user can edit various parameters in the device tree for management and classification.
  • Page 25 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 pull down menu on the menu row. The device will confirm the given frequency while user clicks User can also click right mouse key to pop up the short-cut menu in device tree or in the left blank column, then the corresponding dialog box will pop up by choosing Add Main Freq Point.
  • Page 26 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 User should follow the steps as below:  Inputting the device IP Address  Inputting the port  Inputting the Equipment Name  Choosing the connected equipment type in drop down list of “Equipment Type” by clicking the “▼”...

  • Page 27: Save Configuration

    8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 4.2.6 Delete Equipment User can choose the equipment to be deleted in the left column, and then click the “delete” item in the pull down menu which appears by clicking the right mouse key.

  • Page 28: In 1 Mpeg-4 Avc/ H.264 Hd Encoder Operation

    8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 button on the toolbar to popup the “save file” Alternatively, user can also click the dialog box, which gives prompts to save all the device’s parameters as binary files in the computer’s hard disk.
  • Page 29 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 4.3.1.1 General Parameters Set: to make the current parameters shown in the SNMP software activate. Get: to read the current device’s activating parameters and show them on SNMP software.
  • Page 30 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 This 16-bit field gives the label identifying the network ID of the originating delivery system. The value ranges from 0 to 0xFFFF.  Transport Stream ID This is a 16-bit field which serves as a label for identification of this TS from any other multiplex within the delivery system.
  • Page 31 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 Input channel selection area. The interface and setting principle of each channel are the same. Video Config Area: It is to configure video manually except resolution which automatically displays the resolution of source signal and it is read-only.
  • Page 32 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 CH01-CH08: The 8 HDMI Encoding Channels CH09: The 1 ASI Input Channel The programs in the left column represent all input programs and which port they come from, while the programs in the right column represent the output programs and from which port they are from.
  • Page 33 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 Select the target item and input the new value in the box below, then click to effect the modification. : The parsing overtime value 4.3.3 Tables 4.3.3.1 PID Filter Table Users can operate PID filter in this table by checking the check boxes of corresponding items and click CONFIRM to effect.
  • Page 34 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 Refresh: getting PID filter table from the device Setting: submitting the PID filter table to the device Check All: selecting all the selections of the list After user selects one PID in the table, then the corresponding output PSI/SI table will not be sent to the output stream.
  • Page 35 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 Input PID and Output PID The Old (Input) PID is the PID number in the TS from given Port. The correspondent New (output) PID number could be same as input PID number while it could be different if a PID remapping is needed.
  • Page 36 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 ：The parameter describes the output TS’s network ID ：The parameter describes the output TS’s network name. Insertion private description ：This checkbox will allow user to insert the private descriptor into the output TS.
  • Page 37 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 The interface will show as below after the NIT parameters being added： ：The “Modify” button will trigger a modify window and allow user to modify the selected items in the NIT.

  • Page 38: Other Settings

    8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 4.4 Other Settings 4.4.1 Difference between Set and Remote Save In many cases during the configuration of parameters in NMS, users save the modified configuration by clicking “Set”, in which way the configuration can only be saved temporarily and will restore the last saved configuration if the device reboots.
  • Page 39 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 confirm. Users can then note the indicator light turns red, which signifies the equipment has disconnected. Users then can refer to below prompts to edit the property by inputting the new IP to re-connect the equipment.
  • Page 40 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 When logging in, user will note that the default user name is admin and no password. User can add users and passwords as needed. User clicking “Setting” in the menu bar and selecting “User Setting” in the pull-down list, the below dialog box will pop out as shown below.

  • Page 41: Chapter 5 Web Nms Operation

    8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 Chapter 5 WEB NMS Operation User not only can use front buttons to set configuration, but also can control and set the configuration in computer by connecting the device to web NMS Port. User should ensure that the computer’s IP address is different from the encoder’s IP address;...
  • Page 42 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 Encode Setting From the menu on top of the webpage, clicking “Encode Setting”, it displays the information of the program from the 1 HDMI/SDI encoding channel as Figure-2.
  • Page 43 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 CH01-CH08: The 8 HDMI Reboot: It will Encoding Channels restart the device automatically. CH09: The 1 ASI Input Channel Input Area Output Area Figure-2 : Check this box the set the PID Mapping...
  • Page 44 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 Figure-3 : User can decide to bypass the inputting PID as needed. In some occasions, there are some PIDs which won’t belong to any program, such as EPG, NIT tables, and so on, but user just wants to pass them through the multiplexing module without changing anything.
  • Page 45 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 Figure-5 ：The parameter describes the output TS’s network ID ：The parameter describes the output TS’s network name. Insertion private description ：This checkbox will allow user to insert the private descriptor into the output TS. The private descriptor includes two parts.
  • Page 46 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 Users can copy a stream from the IP out streams (1 MPTS & 8 SPTS) to output through ASI. Figure-6 After setting the parameters, click “Apply” to save the setting.
  • Page 47 8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 Password When user clicks “Password”, it will display the password screen as Figure-8. Here user can change the Username and Password for login to the device. Figure-8 Network When user clicks “Network”, it will display the screen as Figure-9.

  • Page 48: Chapter 6 Troubleshooting

    8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 Chapter 6 Troubleshooting ISO9001 quality assurance system has been approved by CQC organization. For guarantee the products’ quality, reliability and stability. All our products have been passed the testing and inspection before ship out factory.

  • Page 49: Chapter 7 Packing List

    8 in 1 MPEG-4 AVC/H.264 HD Encoder User’s Manual IRENIS EMU-8220 / EMU-8230 Chapter 7 Packing list  IRENIS EMU-8220 or EMU-8230 Encoder 1 pce  User’s manual 1 pce  HDMI or SDI cable 8 pcs  ASI cable 1 pce ...
