  • Page 1 KILOTECH KWS 2200 Weighing scale Operation Manual V5.13 Contents Subject to Change without Notice ────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 2 Ce manuel est disponible en français à www.kilotech.com ou auprès de notre service à la clientèle au 1-800-694-4445. Ce manuel est disponible en Spanish à www.kilotech.com ou auprès de notre service à la clientèle au 1-800-694-4445. ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 3: Table Of Contents

    21. Enter Setup Mode: ................18   22. UPS world ship: ................. 18   23. Error codes and Troubleshooting ........... 18   24. Troubleshooting ................20   25. Display Character ................22   26. Packing List ..................23   ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 4 KWS 2200 weighing scale Operation Manual Thank you for purchasing the KWS 2200 weighting scale. Please read all operating instructions carefully before use and keep the following points in mind: * Avoid lengthy exposure to extreme heat or cold, your scale works best when operated at normal room temperature.
  • Page 5: Specifications

    1.4.6 Counting Mode; Percentage Working Mode 1.4.7 Data Comparison and indicator of High, OK and Low is available in Weighing mode, Parts Counting mode and Percentage Working mode. 1.4.8 Battery voltage is low and charging indicator ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 6 1.7.3 Humidity: 10 to 80% RH without condensation 1.8 Communication: 1.8.1 Serial port0: Full-duplex RS232 1.8.2 Serial port1: USB (Virtual RS232) 1.8.3 Baud Rate: Selectable: 1200-2400-4800-9600-19200-38400 bps 1.8.4 Data Output Format: 8N1, 7O1, 7E1 1.8.5 Protocol: programmable ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 7: Faceplate

    (weight, pieces or percent) is within the set limits 2.15 LO lights up when data compare is activated and current data (weight, pieces or percent) is below the set limit 2.16 lights up when battery is used or charged ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 8: Summary Of Key Function

    Display date or time mode, To set current date or time press down >3s Display voltage mode, To calibrate input voltage value press down >3s Display ADC code Select displaying code from no-filter, filter1, filter2 ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 9: Switch Between Operation Mode

    To access the secondary key function, you must press it for more than 3s. 4. Switch between operation mode Long press FUNC key, then use to choose and confirm to switch into weighing mode, counting mode or percentage mode ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 10: Normal Weighing Mode

    NOTE: (1) ZERO only be active when scale is stable and weight is in SAZSM setting range. (2) TARE only be active when scale is stable (3) Clear TARE weight or ZERO scale, make indicator to enter displaying GROSS mode (4) TARE weight, make indicator to enter displaying NET mode ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 11: Accumulation Mode

    Input piece weight from keypad: in counting mode, press UNIT key, When InP.PWt is shown, press TARE key to enter input piece weight mode. 8.5.1.1 When UNIT.KG is shown, use PRINT or ACC key to select the unit of piece weight, use TARE key to ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 12: Check Counts (Counts Compare)

    NOTE: If High number is 0 or is equal or less than low number, the comparison will be disabled. After the limitations have been set and check weight function is be active, one of annunciators HI, OK, LO will light up, and the beeper will sound according to its setting in USER-BEEP. ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 13: Percent Weighing Mode

    Before scale is stable, SPL.Hi will be flashed. After it is stable, it will go to next step. Press ZERO key to exit and back to percent weighing mode. 10.5.2.3 After INP.PCT being shown, 000000(position decimal point determined ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 14: Check Percent (Percentage Compare)

    UNIT key, and BMI and weight unit will be displayed at same time. 12.5 When current net weight is less than NLD.RNG, the indicator will go to display weight number if CONFIG-FUNC-ACCUMU= indicator will back original working mode CONFIG-FUNC-ACCUMU= Yes. ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 15: Hold Function

    USER-OTHER-NLD.RNG (zero 'dead' band ) can be held. To exit HOLD mode, press HOLD key again. If the time of scale being unstable is more than USER-HOLD-STB.TIM, STB.ER will be shown, press TARE key to start averaging again, or press HOLD key to exit. ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 16: Data Compare Function

    14.5 After Low being shown, last setting of low will be displayed, use PRINT, ACC, UNIT key to input new number of low and press TARE key to confirm. Annunciator of Lo will be shown in this step. Press ZERO ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 17: Accumulation

    15.5 To view total, when display number is zero, long pressing TOTAL key, and indicator will display accumulation times first, and then display total of number. NOTE: When HOLD function is enable, and scale is working in PEAK HOLD mode( CONFIG-HOLD=YES, USER-HOLD-HLD.MOD=PS.PEAK/NG.PEAK), Accumulation function will be automatically disabled!!! ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 18: View Or Set Time

    20.2 In this mode, press a key, the value of this key will be displayed on -- position and buzzer will beep whatever USER-BEEP-KEY item is set. 20.3 Press SETUP key to return to last menu item, press ON/OFF key to prepare to exit this mode ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 19: Enter Setup Mode

    ----- Calibration error, maybe input data or loaded weight is incorrect, unstable, un-linear 25.1.16 CAL.End ----- Calibration is end 25.1.17 OFF ----- Power OFF the indicator 25.1.18 STB.ER ------ Unstable time is lager than setting of USER-OTHER-NLD.RNG 25.1.19 AC.xxxx ----- Accumulation times is xxxx ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 20 25.1.30 PWT.ER --------- Piece weight is error, it’s too small (<0.5d). 25.1.31 SPL.PCT -------- Sample goods weight to calculate 25.1.32 INP.PCT --------- input percentage of weighted goods 25.1.33 PCT.ER ---------- Unit-Percentage -Weight is too small (<0.5d). ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 21: Troubleshooting

    Unit-Percentage -Weight is error, it’s too small (the weight of 1%, 0.1%, or PCT.ER 0.01%-determined by Use a greater weight for the sample. CONFIG-FUNC-PERCNT is less than 0.5d) ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 22 Load cell damage. Service required. Cannot display weight Unit not set to enable, or d≥5oz,when in desired weighing Enable unit in CONFIG-UNITS unit is lb:oz unit. Battery symbol is empty or Lo.bAt Batteries are discharged. Change batteries shown ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 23: Display Character

    25. Display Character ASCII LCD/LED Show ASCII LCD/LED Show ASCII LCD/LED Show ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
  • Page 24: Packing List

    26. Packing List CONTENT Indicator User manual Swivel bracket AC Adapter RS232 cable USB interface USB cable 1x CR2032 battery for RTC AA Alkaline batteries ──────────────────────────────────────────────────────── KILOTECH INC. www.kilotech.com...
