9600 Compressor Installation, Operation, and Maintenance

Supply and Return Water Line Connections

Hard Water Lines

Flexible Water Lines

P/N 8040540
NOTE: The water used for cooling the Compressor must meet the
specifications outlined in Section 1 - Compressor Description.
1. Apply a light coating of standard plumbing thread sealant to the
hard line pipe threads.
2. Install the Supply hard line into the INPUT connection on the rear
panel of the Compressor. Tighten the fitting by hand.
3. Install the Return hard line into the OUTPUT connection on the
rear panel of the Compressor. Tighten the fitting by hand.
Do not overtighten the ferrules. Damage to the input and output
connector threads may occur.
4. Using a wrench, tighten the fittings.
5. Allow water to flow and check for leaks at the rear of the
Compressor.
1. Apply a light coating of standard plumbing thread sealant to the
barbed fitting threads.
2. Install the barbed fittings into the INPUT and OUTPUT
connections on the rear panel of the Compressor.
Do not overtighten the barbed fittings. Damage to the INPUT and
OUTPUT connector threads may occur.
3. Using a wrench, tighten the barbed fittings.
4. Connect the Supply flexible water line to the INPUT barbed fitting
and secure with a hose clamp.
5. Connect the Return flexible water line to the OUTPUT barbed
fitting and secure with a hose clamp.
6. Allow water to flow and check for leaks at the rear of the
Compressor.
CAUTION
CAUTION
-
C TI CRYOGENICS
HELIX TECHNOLOGY CORPORATION
3-3
