9600 Compressor Installation, Operation, and Maintenance

General

Specification
Part Numbers
Input Power Cable
(Customer Supplied)
Nominal Helium Pressure
Ambient Operating
Temperature Range
Interface
Gas Supply Connector
Gas Return Connector
Remote Control Receptacle
Adsorber Service Schedule
P/N 8040540
The information in Table 1-4 provides general Compressor operating
specifications.

Table 1-4: General Compressor Operating Specifications

600 VAC
10 Gauge, 3 conductor wire with ground
Must conform to local electrical codes
Refer to Table 4-1
50 - 100º F (10 - 38º C)
Cryopump Power Receptacles: mates with the
CTI-CRYOGENICS supplied cryopump power cable for
single pump use.
Mates with remote junction box power cable for multiple
cryopump use.
1/2 in. Aeroquip self-sealing coupling
1/2 in. Aeroquip self-sealing coupling
24VAC, 2.7A inductive mates with P5 connector P/N
MS3106A*
3 Years
* Supplied by CTI-CRYOGENICS
NOTE: The 9600 Compressor is designed for continuous operation and
should remain ON when the cryopumps are in a regeneration cycle.
-
C TI CRYOGENICS
HELIX TECHNOLOGY CORPORATION
Values
1-7
