9600 Compressor Description
Specifications
Dimensions
19.52 IN.
(496 MM)
14.4 IN.
(366 MM)
1-4
The dimensions of the Compressor are shown in Figure 1-2.
23.36 IN.
(593 MM)
Figure 1-2: 9600 Compressor Dimensions
Do not place a weight greater than 75 lbs. (34Kg) on top of the
Compressor.
21.50 IN.
(546 MM)
3.18 IN.
(81 MM)
CAUTION
-
C
TI
CRYOGENICS
HELIX TECHNOLOGY CORPORATION
1.28
(32MM)
P/N 8040540
