9600 Compressor Installation, Operation, and Maintenance

Section 2 - Unpacking and Inspection

Introduction

Shipping Carton Inspection

Removal from Shipping Carton

P/N 8040540
The 9600 Compressor is shipped in a shipping carton incorporating a ramp
system which makes removing the Compressor from the carton safe and
easy.
Inspect the exterior of the shipping carton for visible signs of damage
before opening the shipping carton. Report any damage to the shipping
company at once.
1. Cut the two straps on the exterior of the shipping pallet.
2. Lift the cardboard carton straight up and remove it from the
pallet.
3. Cut the tape which holds the ramp in the vertical position.
4. Swing the ramp down until the end touches the floor as shown in
Figure 2-1.
5. Remove any excess shipping material from around the Compressor.
Be certain to maintain control over the movement of the Compressor
as it rolls down the ramp. Injury to personnel may result if the
Compressor is allowed to roll freely down the ramp.
Be certain to maintain control over the movement of the Compressor
as it rolls down the ramp. Damage to the Compressor may
result if the Compressor is allowed to roll freely down the ramp.
6. Unlock the swivel casters as shown in Figure 2-1.
7. Carefully roll the Compressor down the ramp and onto the floor as
shown in Figure 2-1.
WARNING
CAUTION
-
C TI CRYOGENICS
HELIX TECHNOLOGY CORPORATION
2-1
