OkiLAN 6120i
User's Guide
High Performance 10/100 Base-T Ethernet
Network Print Server

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OkiLAN 6120i and is the answer not in the manual?

Questions and answers

Related Manuals for Oki OkiLAN 6120i

Summary of Contents for Oki OkiLAN 6120i

  • Page 1 ® OkiLAN 6120i User’s Guide High Performance 10/100 Base-T Ethernet Network Print Server...
  • Page 2 Every effort has been made to ensure that the information in this document is complete, accurate, and up-to-date. Oki Data assumes no responsibility for the results of errors beyond its control. Oki Data also cannot guarantee that changes in products made by other manufacturers and referred to in this handbook will not affect the applicability of the information in it.

  • Page 3: Table Of Contents

    Section I contains and installation instructions for the OkiLAN 6120i print server. Section II contains information about management features, an extremely valuable set of OkiLAN 6120i management tools for network administrators. The Network Operating System (NOS) and protocol sections are found in Sections III through VI.
  • Page 4 Organization and Contents Section IV: TCP/IP ... IV-1 Chapter 1: Introduction ... IV-5 Chapter 2: Configuring the OkiLAN 6120i ... IV-7 Chapter 3: TCP/IP Configuration and Printing ... IV-14 Chapter 4: OkiNet for TCP/IP ... IV-23 Chapter 5: Web Configuration ... IV-42 Chapter 6: Telnet Configuration ...

  • Page 5: Network Operating Systems

    Network Operating Systems Network Operating Systems Overview OkiLAN 6120i simultaneously supports several network protocols in various combinations. Below is a list of supported network protocols accompanied with NOS/OS requirements. TCP/IP and Windows NT TCP/IP, FTP and Remote LPD protocols. Simple Network Management Protocol (SNMP) and Windows NT are supported in this environment.

  • Page 6: Service Information

    Your Dealer Consult the store where you purchased your OkiLAN 6120i, or call 1-800-OKI-DATA (1-800-654-3282) for the location of the nearest authorized Oki Data service dealer. Have your ZIP code ready. • Proof of purchase is required for warranty work. Be sure to retain your purchase documents.
  • Page 7 1-800-OKI-DATA (1-800-654-3282). Please be sure that you are calling from a telephone close to your printer, so you can describe your problem accurately. Our customer service representatives are trained on all current Oki Data products They can answer your questions regarding: • Installation •...
  • Page 8 2735 Matheson Blvd. East, Unit 1 Mississauga, Ontario, Canada L4W 4M8 Tel: 1-800-654-3282 Fax: 1-905-238-4427 MEXICO Oki Data de Mexico, S.A. de C.V. Mariano Escobedo No. 748 - 8 Piso Col Anzures, e. p. 11590 Mexico, DF Tel: (525) 263-8780 Fax: (525) 263-8785 BRAZIL Oki Data do Brasil, Ltda.
  • Page 9 • OkiLAN model number • Serial number • Configuration sheet settings • Type of network cable connected to the OkiLAN 6120i • Printer(s) make and model numbers • Computer and network adapter card make and model numbers • Network Operating System and version number Please write these numbers down in the space provided below for future reference.
  • Page 10 Technical Support OKI OkiLAN 6120i User’s Guide...

  • Page 11: Section I: Hardware Installation

    Section I: Hardware Installation...
  • Page 12 Section I - Hardware Installation I - 2 OKI OkiLAN 6120i User’s Guide...
  • Page 13 Section I - Hardware Installation Contents Installing the OkiLAN 6120i ...I-5 Powering On the OkiLAN 6120i ... I-7 Printing a Configuration Sheet ...I-8 Installing the Network Software ...I-9 Removing the OkiLAN 6120i ... I-12 Hardware Troubleshooting ...I-14 OKI OkiLAN 6120i User’s Guide...
  • Page 14 Section I - Hardware Installation I - 4 OKI OkiLAN 6120i User’s Guide...

  • Page 15: Installing The Okilan 6120I

    Section I - Hardware Installation The OkiLAN 6120i Print Server enables Ethernet network users to connect to a printer with an OKI SIDM port. The OkiLAN 6120i supports 10/100-megabit networks and most popular network operating systems and SIDM printers. Before using the parallel port, you must remove the OkiLAN 6120i from the printer—see page I-12 for...
  • Page 16 4. Pry off the breakaway panel next to the interface connector with a screwdriver or knife 5. Insert the OkiLAN 6120i by sliding it along the rails in the recess of the printer, until it is plugged into the socket in the rear of the recess.

  • Page 17: Powering On The Okilan 6120I

    Powering On the OkiLAN 6120i Turn printer power on. The red and green indicators on the OkiLAN 6120i will blink during self-test. When self- test completes successfully, the red indicator will go off and the green indicator will stay on.

  • Page 18: Printing A Configuration Sheet

    Printing a Configuration Sheet To print configuration information, press the Test button on the front of the OkiLAN 6120i. You can also print configuration information using the utility program provided on the CD. Note: By default, the configuration sheet prints in ASCII text.
  • Page 19 Oki LPR Oki LPR Utility allows you to print directly to a printer on the network without a print server. It creates an Oki Printer Port, and installs a pop-up status box so you can monitor printer status.

  • Page 20: Installing The Software In Windows

    Section I - Hardware Installation Installing the Software in Windows 1. Click the Network Software button on the OKI Menu Installer screen. 2. Click the button for the software you want to install. 2a. If you select OkiNet Utilities: When the Setup screen appears, select the utility group for the network environment you have, then click Next.
  • Page 21 Note: The OkiLAN Utilities CD is designed for more than one type of OkiLAN print server and includes features that do not apply to the OkiLAN 6120i. Specifi- cally, Apple EtherTalk is supported by other OKI print servers but not by the OkiLAN 6120i.

  • Page 22: Removing The Okilan 6120I

    2. Unplug the power cord. 3. Unplug the 10/100Base-T UTP cable from the receptor on the back of the OkiLAN 6120i. 4. Slide the OkiLAN 6120i out of the printer and store it in a safe place for future network requirements. I - 12...
  • Page 23 5. Attach the interface cable to the parallel interface connector. Attach the other end of the cable to your computer. 6. Plug the power cord into the power outlet. OKI OkiLAN 6120i User’s Guide Section I - Hardware Installation I - 13...

  • Page 24: Hardware Troubleshooting

    LED Display Green indicator flashing very rapidly Problem The OkiLAN 6120i has not detected the presence of a network cable. Solution a) Remove the network cable. Plug the network cable back in until you hear a positive click. Check the other end of the cable in the same manner.
  • Page 25 Problem The printer server has failed the Power On Self Test. Solution The OkiLAN 6120i will try to print a configuration sheet on the printer with more information. Failing the self test can be caused by any of the follow- ing: a) The printer is malfunctioning.
  • Page 26 Section I - Hardware Installation I - 16 OKI OkiLAN 6120i User’s Guide...

  • Page 27: Section Ii: Advanced Management Features

    Section II: Advanced Management Features...
  • Page 28 Installing a Windows NT Printer for the OkiLAN 6120i ... II-8 Obtaining Diagnostic Information from the OkiLAN 6120i ... II-9 Chapter 4 OkiLAN 6120i Web Configuration ...II-10 Overview ... II-10 Connecting to the OkiLAN 6120i ... II-10 Configuration ... II-12 Status ...

  • Page 29: Simple Network Management Protocol (Snmp)

    An agent can also send an unsolicited message Trap to a manager when it encounters an unusual condition. The OkiLAN 6120i is a fully functional SNMP agent and supports, to the extent of open industry standards such as RFC 1759, any standard SNMP management platform, including: •...

  • Page 30: Traps

    OkiLAN 6120i. If genConfigDirty is set to yes, then the cmdReset variable should also be set to yes. This will cause the OkiLAN 6120i to reset, make all configuration changes active on the OkiLAN 6120i and set both the cmdReset and genConfigDirty variables to no.

  • Page 31: Chapter 1: Snmp

    6120i must have bi-directional status enabled. Extended Status can be enabled through the OkiLAN 6120i Configuration utility (telnet) from the Configure Port option. You can also enable OkiNet Alert through OkiNet for TCP/IP or IPX from the Output Port file tab.

  • Page 32: Chapter 2: Hp Jetadmin Support

    HP JetAdmin Support Overview This section contains instructions and information on how to configure and obtain diagnostic information from your OkiLAN 6120i using the Hewlett-Packard JetAdmin software. Software Requirements • JetAdmin 2.4, 2.5, or 3.02 • Windows 95/98 or Windows NT/2000...
  • Page 33 4. Enter the Apple Talk name and click OK. Obtaining Diagnostic Information Using JetAdmin 1. From the main JetAdmin screen, select the OkiLAN 6120i port on which you wish to view diagnostic information. 2. Select Properties from the Device menu.

  • Page 34: Chapter 3: Hp Web Jetadmin Support

    3. In the Specify the device address… field, enter the print server IP address, followed by a comma and then the output port number. For example, to install a printer for output port 2 of an OkiLAN 6120i with an IP address of 10.10.10.2, enter “10.10.10.2,2”. II - 8...

  • Page 35: Obtaining Diagnostic Information From The Okilan 6120I

    Obtaining Diagnostic Information from the OkiLAN 6120i 1. From the main Web JetAdmin page, select the OkiLAN 6120i port on which you wish to view diagnostic information. 2. Click the Diagnose button. 3. From the Properties page, select the appropriate diagnostic category name to view information.

  • Page 36: Chapter 4: Okilan 6120I Web Configuration

    Section 2 - Chapter 4 - OkiLAN 6120i Web Configuration Chapter 4 OkiLAN 6120i Web Configuration Overview This section contains instructions and information on how to configure and manage your OkiLAN 6120i using a standard Web browser. Software Requirements TCP/IP Protocol Netscape Navigator 2.0 or greater and Microsoft...
  • Page 37 Section 2 - Chapter 4 - OkiLAN 6120i Web Configuration Note: As a layer of security, the TCP port number that the device uses to communicate with browsers, called the HTTP port, can be modified from a default of 80. If the port is...

  • Page 38: Section 2 - Chapter 5 - Additional Management Features

    Note: All values (except as noted on the following pages*) are configured exactly the same as in the OkiNet utility. Please refer to the OkiLAN 6120i User’s Guide Section IV - TCP/IP, Chapter 4 - OkiNet for TCP/IP for instructions on configuration.
  • Page 39 Section 2 - Chapter 4 - OkiLAN 6120i Web Configuration 5. A Request Results page will appear indicating one of the following: • Configuration Successfully Set: The values have been successfully saved to the print server. Go to another page to continue configuration or exit the browser.
  • Page 40 • HTTP Port - This field is used to specify the TCP port that the HTTP protocol will listen on. The default HTTP port is 80, but can be changed to provide added security. II - 14 OKI OkiLAN 6120i User’s Guide...

  • Page 41: Status

    Section 2 - Chapter 4 - OkiLAN 6120i Web Configuration Status The home page for the print server shows general status information including the status of all printers currently attached. For more detailed status information, select the View Cnfg Sheet link under the Status menu. This will show information similar to what is printed on the print servers configuration sheet.

  • Page 42: Reset

    Restore All Protocols button. OkiLAN 6120i Server Discovery An HTML file containing links to all OkiLAN 6120i print servers on the network can be created using the OkiNet utility for TCP/IP. Complete the following steps to create the HTML file: 1.

  • Page 43: Troubleshooting

    Section 2 - Chapter 4 - OkiLAN 6120i Web Configuration Troubleshooting Server Connection • The print server only supports two simultaneous HTTP connections. If your browser fails to connect to the print server, the browser may be trying to open more than two connections.

  • Page 44: Chapter 5: Additional Management Features

    This information can be observed in real time via the utilities or can be interpreted by the OkiLAN 6120i to generate traps to your SNMP management utility of choice: HP OpenView or the OKI OkiNet Alert utility.

  • Page 45: Okinet For Nds

    For more information, see the Windows Printing section of this manual. Printer Security for TCP/IP Printing The OkiLAN 6120i print server has a Printer Security for TCP/IP Printing feature which allows the printers to only be accessed from a specified list of IP addresses.

  • Page 46: Okinet Web Configuration Utility

    Section 2 - Chapter 5 - Additional Management Features OkiNet Web Configuration Utility This subsection contains instructions and information on how to configure and manage your OkiLAN 6120i using the OkiNet Web Configuration Utility. The OkiNet Web Configuration Utility is a Java applet which...
  • Page 47 OkiNet.htm file from the directory where the OKI Java files are installed. The Security Warning dialog box appears on your browser. 2. Click Yes on the Security Warning dialog. The Oki Data Discovery Applet is installed. The OkiNet Web Configuration Utility screen appears: 3.
  • Page 48 In this case, the menu items normally shown in the left pane can be accessed by using the menu links that appear at the bottom of the page. II - 22 OKI OkiLAN 6120i User’s Guide...
  • Page 49 Help Use the Help button to access the utility’s online help pages. Configuration Refer to Section II, Chapter 4, OkiLAN 6120i Web Configuration for information on configuring your network printer using the Web Configuration Utility. OKI OkiLAN 6120i User’s Guide...

  • Page 50: Section Iii: Netware

    Section III: NetWare...

  • Page 51: In This Section

    Mode ... III-5 Chapter 2 OkiNet for NetWare ...III-6 Overview ... III-6 Running OkiNet for NetWare ... III-7 Configuring the OkiLAN 6120i Using OkiNet for NetWare ... III-7 NetWare Configuration Options ... III-8 NetWare Queues Configuration Options ... III-9 NetWare Port Configuration Options ... III-10 TCP/IP Configuration Options ...
  • Page 52 Windows 3.x ... III-26 Installing OkiNet for NDS for Novell NetWare 4.x, NetWare 5.x, Windows 95/98 and Windows NT/2000 ... III-27 Creating a New OkiLAN 6120i Object ... III-28 Printing with an OkiLAN 6120i Print Server ... III-29 Configuring the OkiLAN 6120i Using OkiNet for NDS ...

  • Page 53: Chapter 1: Introduction

    Section 3 - Chapter 1 - Introduction Chapter 1: Introduction Overview This section contains instructions and information on how to configure your OkiLAN 6120i in the NetWare environment. There are three environments in which to configure the OkiLAN 6120i: • Bindery (NetWare 3.x) •...

  • Page 54: Selecting Pserver Or Rprinter/Nprinter Mode

    Your OkiLAN 6120i supports both PServer and NPrinter mode. There are several factors to consider when choosing which mode to use. In PServer mode, the OkiLAN 6120i operates as the print server. It services specified queues on the network. In RPrinter mode, the NetWare Print Server NLM or EXE is in control.

  • Page 55: Chapter 2: Okinet For Netware

    Chapter 2 OkiNet for NetWare Overview This chapter contains information about how to configure the OkiLAN 6120i in Bindery and NDS environments using the OkiNet for NetWare utility. Note: OkiNet for NetWare contains minimal NDS configuration support. For more extensive configuration options, use the OkiNet for NDS utility described in Chapter 3.

  • Page 56: Running Okinet For Netware
