Rear view

6
1
Ethernet connector
3
ExpressCard slot
5
Smart-card slot (available on some models)
7
Power connector
9
Thunderbolt™ 3 connector
11
USB 3.0 connector

Bottom view

1
Micro-SIM-card slot
3
Docking station connector
5
Battery

Status indicators

This topic presents the status indicators that show the status of the computer.
46
ThinkPad P50 Hardware Maintenance Manual
1
2
12
11
10
9
8
7
6
1
3 4 5
2
Fan louvers
4
Media-card slot
6
Fan louvers
8
HDMI connector
10
Ethernet connector
12
Always On USB 3.0 connector
2
3
2
Fan louvers
4
Keyboard drainage hole
