Adjusting Line Length
Additionally, two modes are available in both AdjustmentPrint and Change Settings : A:High or B:Standard/
Draft. Choose the mode that suits your particular printing application.
A:High
•
This setting is applied when Highest or High is selected in Print Quality in the printer driver.
B:Standard/Draft
•
This setting is applied when Standard or Fast is selected in Print Quality in the printer driver.
• Always check the Adj. Priority values before using Adjust Length. (See "Selecting a Feed Amount Adjustment
Method.")
Note
• Use paper of the same type and size for adjustment as you will use for printing.
Paper to Prepare
When Using Rolls
When Using Sheets
Perform adjustment as follows.
1
Load the paper.
Attaching the Roll Holder to Rolls
•
Loading Rolls in the Printer
•
Loading Sheets in the Printer
•
Important
2
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to
select the Settings/Adj. tab (
Note
3
Press the OK button.
The Set./Adj. Menu is displayed.
4
Press ▲ or ▼ to select Adjust Printer, and then press the OK button.
5
Press ▲ or ▼ to select Feed Priority, and then press the OK button.
6
Press ▲ or ▼ to select Adjust Length, and then press the OK button.
7
Press ▲ or ▼ to select AdjustmentPrint or Change Settings, and
then press the OK button.
488
When you select AdjustmentPrint, a test pattern is printed for you to
measure the scale and calculate the discrepancy. The scale bar prints
Millimeter in 50 mm increments and Inch in 1-inch increments.
P.483
➔
•
An unused roll at least 10 inches wide
•
High-precision ruler
•
One sheet of unused paper of at least A4/Letter size
•
High-precision ruler
P.339
➔
P.356
➔
• Always make sure the loaded paper matches the type of paper specified. Adjustment cannot be comple-
ted correctly unless the loaded paper matches the settings.
).
• If the Tab Selection screen is not displayed, press the Menu button.
P.336
➔
