Roll Cover (Inside); Carriage - Canon imageprograf ipf780 User Manual

iPF780
g Cleaning Brush
When cleaning inside the printer under the Top Cover, use this brush to sweep away paper dust on the Platen.

Roll Cover (Inside)

Roll Cover (Inside)

a Roll Holder
Load the roll on this holder.
b Holder Stopper
Secure rolls on the Roll Holder with this part.
c Roll Loading Slots
Slide the Roll Holder along these slots.
d Roll Holder Slot
Load the Roll Holder into this holder slot.

Carriage

Carriage

a Angle Adjustment Lever
Use this lever to fine-tune the printer to correct misalignment of printed lines.
User's Guide
Roll Cover (Inside)
