ELECRAFT K3 Installation Instructions Manual

High-performance 160 – 6 meter transceiver
Hide thumbs Also See for K3:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual, Instruction and Installation Manual
®
E
K3
LECRAFT
H
-P
160 – 6 M
IGH
ERFORMANCE
ETER
T
RANSCEIVER
KXV3 I
O
NTERFACE
PTION
I
I
NSTALLATION
NSTRUCTIONS
Rev B, October 30, 2007
Copyright © 2007, Elecraft, Inc.
All Rights Reserved

Advertisement

Table of Contents
loading

Related Manuals for ELECRAFT K3

Summary of Contents for ELECRAFT K3

  • Page 1 ® LECRAFT 160 – 6 M ERFORMANCE ETER RANSCEIVER KXV3 I NTERFACE PTION NSTALLATION NSTRUCTIONS Rev B, October 30, 2007 Copyright © 2007, Elecraft, Inc. All Rights Reserved...

  • Page 2: Table Of Contents

    Contents Introduction............................... 3 Customer Service and Support..........................3 Technical Assistance ............................3 Repair / Alignment Service ..........................3 Preventing Electrostatic Discharge Damage .................... 4 How ESD Damage Occurs..........................4 Preventing ESD Damage............................. 4 Preparing for Installation .......................... 5 Tools Required ..............................5 Parts Included..............................

  • Page 3: Introduction

    The KXV3 Interface provides a separate receive antenna input and output, inputs and outputs for use with an external transverter, and a buffered i.f. output. Complete details for using the KXV3 are included in the K3 Owner’s manual. This manual covers the installation of the KXV3 Interface option in your K3 transceiver.

  • Page 4: Preventing Electrostatic Discharge Damage

    How ESD Damage Occurs Whenever an object containing a static charge touches a circuit in your K3, current will rush into the circuit until the components reach the same voltage as the source of the static charge. If the voltage or current that passes through a component during that brief period exceeds its normal operating specifications, it may be damaged or destroyed.

  • Page 5: Preparing For Installation

    • If you choose to use a soldering iron to work on your K3 for any reason, be sure your iron has an ESD- safe grounded tip tied to the same common ground used by your mat or wrist strap.

  • Page 6: Parts Included

    Parts Included The following parts should be included in your kit. Check to ensure you have them all. If any parts are damaged or missing, contact Elecraft for replacements (see Customer Service and Support, page 3). ELECRAFT ILLUSTRATION DESCRIPTION QTY.

  • Page 7: Installation Procedure

    HOLDING TOP COVER. Figure 1. Removing K3 Top Cover. CAUTION: Touch an unpainted metal ground or wear a grounded wrist strap before touching components or circuit boards inside the K3. See Preventing ESD Damage on page 4 for more information.
  • Page 8 Remove the four jack screw nuts with their lock washers and the two black pan head screws from the KIO3 rear panel as shown in Figure 2. REMOVE THE FOUR JACK SCREW NUTS AND LOCK WASHERS REMOVE 4-40 SCREW REMOVE 4-40 SCREW SPACE RESERVED FOR KXV3 MODULE...
  • Page 9 Do not cut nearby jumpers W20 or W21! It is not necessary or desirable to unsolder the jumpers. Simply cut them with your diagonal cutters, taking care not to lose the bits of the jumper wire inside the K3, but be sure to cut the ends short.
  • Page 10 Inspect the white connector at the end of the TMP cable. The side nearest the connector holes must be smooth and flat. Use your diagonal cutters or a hobby knife to cut away any bumps or ridges (see Figure 6 ). TRIM AWAY ANY RIDGES OR BUMPS TO PROVIDE A FLAT, SMOOTH SURFACE...
  • Page 11 As you install components and reassemble your K3, be sure all the screws are in place and secure, but do not over tighten them. Failure to tighten all screws may result in poor shielding of sensitive components, resulting in possible noise or birdies in the receiver as well as other difficult-to-trace problems.
  • Page 12 SPECIAL NOTE TO KIT BUILDERS: If you were directed here to install your KXV3 module as part of the overall kit assembly, installation of the KXV3 module is complete. Return to the K3 Kit Assembly Manual where you left off.
  • Page 13 Figure 11. Check KIO3 Audio I/O Board Mating. Replace the KIO3 Main Board with the Audio I/O daughter board attached in the K3 as shown in Figure 12. The Audio I/O board fits just over the KXV3 board assembly and the TMP cable passes through the space between the edge of the KXV3 board and the KIO3 board.
  • Page 14 Figure 15. Connecting Speaker Cable. Position the top cover on the K3. Note that the tab on the back center goes under the rear lip of the K3 rear panel. Secure the top cover with the nine 4-40 3/16” (4.8 mm) black flat head screws you removed earlier.
