Summary of Contents for Ozito PXIDS-300
- Page 1 WHAT’S IN THE BOX CORDLESS IMPACT DRIVER Impact Driver 18V Lithium Ion INSTRUCTION MANUAL Battery & Charger SPECIFICATIONS sold separately Voltage: No Load Speed: 0-2700/min Chuck Size: 6.35mm (1/4”) Hex Impact Rate: 0-3200/min Max. Torque: 120Nm Weight: 1.4kg ozito.com.au PXIDS-300...
-
Page 2: Know Your Product
KNOW YOUR PRODUCT SETUP & PREPARATION CORDLESS IMPACT DRIVER 1. ASSEMBLY 1 Drive Bit Retaining Ring 4 Belt Hook 2 Tri-Beam LED Light 5 Forward/ Reverse Lever WARNING! ENSURE THE TOOL IS SWITCHED OFF AND 3 Variable Speed Trigger THE BATTERY IS REMOVED BEFORE PERFORMING ANY OF THE FOLLOWING TASKS. - Page 3 2. BATTERY & CHARGING (sold separately) Charging your lithium ion battery - Eco Charger CAUTION: THE CHARGER FOR THIS PRODUCT SHOULD 1 Connect the charger into a mains power outlet. BE PROTECTED BY A RESIDUAL CURRENT DEVICE (RATED AT 30MA OR LESS). 2 The charger LED will flash green showing power Charging your lithium ion battery - Fast Charger...
-
Page 4: Operation
6 Slowly increase pressure on trigger to appropriate torque for circumstances until screw or bolt is tightened. Note: Do not force the driver or apply side pressure to elongate the hole. Let the impact driver do the work. PXIDS-300... -
Page 5: Troubleshooting
CARING FOR THE ENVIRONMENT location not within the reach of children. Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the impact driver by an unauthorised Power tools that are no longer usable should not be disposed of person or by mishandling of the impact driver. -
Page 6: Electrical Safety
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. The power supply for this products charger should be protected by a residual current device (rated at 30mA or less). -
Page 7: Warranty
AND ANSWER ANY QUESTIONS YOU MAY the terms of this warranty. You have the option to register your HAVE RELATING TO THE WARRANTY POLICY product with Ozito on www.ozito.com.au/registrations for an OR PROCEDURE. extended warranty of 2 years within four weeks of purchase. The...
Need help?
Do you have a question about the PXIDS-300 and is the answer not in the manual?
Questions and answers
I want to reduce the Drive bit to fit a small drill.
The Ozito PXIDS-300 impact driver has a 6.35mm (1/4”) hex chuck. To use a smaller drill bit, you need a hex shank drill bit adapter that fits into the 1/4” hex chuck and holds the smaller drill bit securely. Ensure the adapter is compatible with your required drill bit size.
This answer is automatically generated
