CORDLESS
IMPACT
DRIVER
18V Li-ion
INSTRUCTION MANUAL

SPECIFICATIONS

Input:
18V
Chuck Size:
6.35mm Hex Drive
No Load Speed:
0-2000/min
Impact Rate:
0-3000/min
Max. Torque:
150Nm
Battery:
1.3Ah Li-ion
Charge time:
3 - 5 hours
Weight with Battery:
1.5kg
ozito.com.au
WHAT'S IN THE BOX
Cordless Impact Driver
18V Battery x 2
Sockets x 4
Charging Cradle
Charging Adaptor
LID-6100

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LID-6100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ozito LID-6100

  • Page 1 INSTRUCTION MANUAL SPECIFICATIONS Sockets x 4 Input: Chuck Size: 6.35mm Hex Drive No Load Speed: 0-2000/min Impact Rate: 0-3000/min Max. Torque: 150Nm Charging Cradle Battery: 1.3Ah Li-ion Charge time: 3 - 5 hours Weight with Battery: 1.5kg ozito.com.au Charging Adaptor LID-6100...
  • Page 2 KNOW YOUR PRODUCT SETUP & PREPARATION CORDLESS IMPACT DRIVER 1. BATTERY 1 Drive Bit Retaining Ring 4 Forward/ Reverse Lever 2 LED Light 5 Battery 18V This charger is recommended for use with a residual current 3 Variable Speed Trigger 6 Battery Release Button device with a rated residual current of 30mA or less.
  • Page 3 2. KEYLESS CHUCK 2. KEYLESS CHUCK CONT. Installing a Hex Drive Socket or Driver Bit Installing a Socket Adaptor (Not Supplied) 1. Pull the drive 1. Pull the drive retaining ring retaining ring forward. forward. 2. Insert the hex shank of a 1/4”...
  • Page 4 7. Slowly increase pressure on trigger to appropriate torque for reverse rotation, push fwd/rev lever hard right. circumstances until screw or bolt is tightened. Note: Do not force the driver or apply side pressure to elongate the hole. Let the impact driver do the work. LID-6100...
  • Page 5 Ensure the battery is properly charged. It will take 4-5 charging cycles before the battery reaches optimum charge and run time. On the initial Note: Ozito Industries will not be responsible for any damage or charge, the battery requires 5 hours of charging. Subsequent charging injuries caused by repair of the impact driver by an unauthorised only requires 3-5 hours.
  • Page 6 Tool: 18V Li-ion Impact Driver SPARE PARTS Model No. LID-6100 The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No. 18V Li-ion Battery Pack SPLCD5000-16 Charging Adaptor &...
  • Page 7 Replace the extension lead if damaged or defective. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric shock.
  • Page 8 • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 1212...
