Summary of Contents for Ozito 12V DC
- Page 1 WHAT’S IN THE BOX IMPACT WRENCH Impact Wrench 12V DC INSTRUCTION MANUAL 4 x Drive Sockets SPECIFICATIONS Voltage: 12V DC Power: Max Torque: 260Nm Drive Shaft: 1/2” (12.7mm) 12V Socket Connector Weight: 1.7kg ozito.com.au 12V Battery Adaptor IWA-2100...
-
Page 2: Know Your Product
KNOW YOUR PRODUCT SETUP & PREPARATION 12V IMPACT WRENCH 1. CHANGING ACCESSORIES 1 1/2” Drive Shaft 3 Forward/Reverse Lever 2 Operating LED 4 On/Off Trigger WARNING! ENSURE THE TOOL IS SWITCHEd Off ANd dISCONNECTEd fROM THE POWER SUPPLy bEfORE PERfORMING ANy Of THE fOLLOWING ASSEMbLy. Attaching Accessories 1 Align the socket with the drive shaft... -
Page 3: Operation
Connecting to a 12V outlet Switching On & Off 1 To start the impact 1 Connect the 12V wrench depress the socket to a 12V DC on/off trigger outlet which can be found in your vehicle. Note: Once the on/off trigger is pressed the operating LED will glow to help illuminate the working area. - Page 4 4. OPERATING THE IMPACT WRENCH 5. REPLACING THE FUSE 1 Attach the correct The 12V socket is fitted with a 10A fuse to protect the impact wrench. socket to the drive If the impact wrench has stopped working and the LED does not shaft. illuminate, the fuse may need to be replaced. 1 Unscrew the top of the 12V socket to expose the fuse. 2 Select the desired forward/ reverse setting for the job.
-
Page 5: Maintenance
No load speed reciprocation per minute The impact wrench Impact wrench not Connect the 12V does not start connected to the power socket to a 12V DC Diameter Warning outlet I nsufficient supply Try another 12V Read instruction manual Regulator compliance mark... -
Page 6: Impact Wrench Safety Warnings
GENERAL POWER TOOL SAFETY WARNINGS - PERSONAL SAFETY Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. WARNING! Read all safety warnings and all instructions. -
Page 7: Warranty
• Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0714...
