Summary of Contents for Phonic MU 502

  • Page 1 V1.0 2004/2/9...
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions before operating this apparatus. ������� 2. Keep these instructions for future reference. ���� �� �������� ����� �� ��� ���� 3. Heed all warnings to ensure safe operation. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, 4.
  • Page 3: Table Of Contents

    CONTROLS AND SETTINGS..... 8 14. Line/Mic Gain Control........8 15. High Frequency Control........8 16. Middle Frequency Control ..8 (MU 802 and 1002) 17. Low Frequency Control........8 18. High-Pass Filter (75 Hz) ...8 (MU 502 and 1002) 19. EFX Control .......8 (MU 802 and 1002)
  • Page 4: Introduction

    INTRODUCTION GETTING STARTED Thank you for choosing one of Phonic’s many quality 1. Ensure all power is turned off on your mixer. compact mixers. The MU series of Mixers – designed To totally ensure this, the AC cable should not be by the ingenious engineers that have created a variety connected to the unit.
  • Page 5: Channel Setup

    0 dB. 6. This channel is now ready to be used; you can stop making the audio signal. 7. You can repeat the same process for other channels. Or not, it’s your call. PHONIC CORPORATION MU 502/802/1002 USER’S MANUAL Page 5...
  • Page 6: Making Connections

    MAKING CONNECTIONS electronic keyboards, guitars and external signal proces- Inputs and Outputs sors or mixers. On the MU 502, the first stereo channel (mic 2-3) features both a 3-pin XLR microphone input 1. XLR Microphone Jacks and two 1/4” phone jacks, therefore can be used as...
  • Page 7: Efx Send (Mu 802 And 1002)

    Main L and R or the Phones mixing bus. The 2 trim controls, featured on the MU 502 model only, control the input sensitivity of the RCA and mini stereo jacks, ensuring total control over audio levels and quality.
  • Page 8: Controls And Settings

    21.Pan / Balance Controls the audio. The middle frequency control is featured on This alternates the degree the MU 802 and 1002. The MU 502 features High and or level of audio that the left Low Frequency controls on channel 1 only.
  • Page 9: Peak Indicator

    The Peak indicator is on channel 1 only their liking, before sending the signal elsewhere. of the MU 502 mixer, however on both channels 1 and 2 of the MU 802 and 1002. 27. EFX Cue Button (MU 802 and 1002) And now for one of the handiest buttons you will ever 23.
  • Page 10: Main L-R Control

    30. Main L-R Control This control is final level control for the main left and right audio feed, sent to the Main L and R output. The MU 502 features a rotary-style level control, whereas the MU 802 and 1002 both feature a 60 mm fader.
  • Page 11: Applications

    Recording Application PHONIC CORPORATION MU 502/802/1002 USER’S MANUAL Page 11...
  • Page 12 Live Sound Application Using an External Signal Processor With MU 1002 Page 12 MU 502/802/1002 USER’S MANUAL PHONIC CORPORATION...
  • Page 13: Dimensions

    DIMENSIONS All measurements are shown in millimeters / inches PHONIC CORPORATION MU 502/802/1002 USER’S MANUAL Page 13...
  • Page 14: Specifications

    190 x 56 x 233 mm (7.48" x 2.2" x 9.17") 190 x 56 x 233 mm (7.48" x 2.2" x 9.17") 155.6 x 50.5 x 244 mm (6.12" x 1.99" x 8.82") Page 14 MU 502/802/1002 USER’S MANUAL PHONIC CORPORATION...
  • Page 15: Block Diagrams

    MU 502 BLOCK DIAGRAM PHONIC CORPORATION MU 502/802/1002 USER’S MANUAL Page 15...
  • Page 16 MU 802 BLOCK DIAGRAM Page 16 MU 502/802/1002 USER’S MANUAL PHONIC CORPORATION...
  • Page 17 MU 1002 BLOCK DIAGRAM PHONIC CORPORATION MU 502/802/1002 USER’S MANUAL Page 17...
  • Page 20 Information in this document is subject to change without notice.
