- Page 1 MU 1705 Compact Mixers...
-
Page 2: Safety Precautions
Your Phonic MU1705 was carefully packed in the factory and the packing box was de signed to protect the unit from rough handling. We recoMUend that you care ful ly examine the packaging and its con tents for any signs of physical damage, which may have oc curred in transportation. -
Page 3: Table Of Contents
2T RTN ............12 SYSTEM BLOCK DIAGRAM....21 APPENDIX:.........22 1: SUGGESTED READING....22 2: GLOS SA RY........23 Phonic reserves the right to improve or alter any information supplied within this document without prior notice. V2.2 Jun. 8, 2004 MU1705 USER’S MANUAL Page 3... -
Page 4: Introduction
GETTING STARTED Congratulations on your purchase of the MU 1705 Check the AC voltage before connecting the Mixer. The MU 1705 is built of rug ged con struc tion, plug. This product is equipped with a 3- it can be mounted on a stan dard 19-inch ack, which wire ground ing type plug;... -
Page 5: Converting To Rackmount Mode
1-6. on a stan dard 19” rack. It is simple to install the rack 2. Install the mixer on the rack. mount kit by the fol low ing procedure: MU1705 USER’S MANUAL Page 5 PHONIC CORPORATION... -
Page 6: Connecting It Up
CONNECTING IT UP CONNECTING IT UP Page 6 MU1705 USER’S MANUAL PHONIC CORPORATION... -
Page 7: Typical Connecting Leads
TYPICAL CONNECTING LEADS TYPICAL CONNECTING LEADS MU1705 USER’S MANUAL Page 7 PHONIC CORPORATION... -
Page 8: Unbalanced & Balanced
2 connected units are not identical. This means the sys tem is much easierto experience noise interference.Running long ca bles is easy for a balanced system but dif fi cult for an Page 8 MU1705 USER’S MANUAL PHONIC CORPORATION... -
Page 9: Channel Strip Description
“0” po si tion and lo cat ed PRE EQ, noise gen er at ed avoid ex ces sive ly cutting/boost ing by the ex ter nal equip ment may be MU1705 USER’S MANUAL Page 9 PHONIC CORPORATION... -
Page 10: Aux / Efx Section
LOW CUT (CH1~5 only) This en sures the best possible signal- Slide down the dip-switch, insert the 18dB per octave 75Hz low cut fi lter in the signal path. This low Page 10 MU1705 USER’S MANUAL PHONIC CORPORATION... -
Page 11: L/R Or Gp (Routing Switch)
A long-throw 60MU linear fad er de ter mines the pro por tion of the chan nel in the mix and provides a clear visual in di ca tion of chan- nel level. MU1705 USER’S MANUAL Page 11 PHONIC CORPORATION... -
Page 12: Stereo Channels 6-11
L/R. When you would like to mon i tor the signal from the 2T RTN, sim ply de press the PFL button, the in put sig nal will be fed into CTRL RM. Page 12 MU1705 USER’S MANUAL PHONIC CORPORATION... -
Page 13: Master Section Description
GROUP 1/2 faders. 15. GROUP 1/2 FADER A long-throw 60mm linear fader de ter mines the proportion of the group signal in the mix and provides a clear visual in di ca tion of MU1705 USER’S MANUAL Page 13 PHONIC CORPORATION... -
Page 14: Master Display
+48V master switch is on. Page 14 MU1705 USER’S MANUAL PHONIC CORPORATION... -
Page 15: Initial Set Up
Set EQ control to the cen ter position. Set PAN and BALANCE knobs to the center position. You need headphones to continue. Apply a typical performance level signal, mon i tor ing the level on the LED meter. MU1705 USER’S MANUAL Page 15 PHONIC CORPORATION... -
Page 16: Applications
APPLICATIONS APPLICATION1: LIVE SOUND REINFORCEMENT Page 16 MU1705 USER’S MANUAL PHONIC CORPORATION... -
Page 17: 2:Sub Mix Ing
APPLICATIONS APPLICATION2: SUB MIXING MU1705 USER’S MANUAL Page 17 PHONIC CORPORATION... -
Page 18: 3:Music Club
APPLICATIONS APPLICATION3: MUSIC CLUB Page 18 MU1705 USER’S MANUAL PHONIC CORPORATION... -
Page 19: Dimensions
DIMENSIONS Measurements are shown in MU/inch. MU1705 USER’S MANUAL Page 19 PHONIC CORPORATION... -
Page 20: Specfications
SPECIFICATIONS Due to continually improving product performance, specifi cations are subject to change without notice. Page 20 MU1705 USER’S MANUAL PHONIC CORPORATION... -
Page 21: System Block Diagram
SYSTEM BLOCK DIAGRAM MU1705 USER’S MANUAL Page 21 PHONIC CORPORATION... -
Page 22: Appendix
APPENDIX APPENDIX 2: GLOSSARY APPENDIX 1: SUGGESTED READING AFL (After-Fader-Listening) Phonic recoMUends the following books for those interested in advanced audio engineering and Acronym for after fader listen, also known as post- sound system operation: fader solo function. Sound System Engineering by Don and Caro-... -
Page 23: 2: Glos Sa Ry
2 signals. Signals that reinforce each other are In- phase; signals that cancel each other are out-of the phantom power supply for channel mic inputs, for phase. condenser microphones and active DI boxes. MU1705 USER’S MANUAL Page 23 PHONIC CORPORATION...
