Load Record - Microhard Systems IPN4G Operating Manual

4.0 Configuration
4.7.6 GPS > Load Record
Data that has been recorded and saved by the IPn4G can then be viewed or sent to a remote
server.
Check the boxes next to the records listed above that are to be sent
to the server.
Specify the data format / protocol type for the data to be sent.
Enter the address or IP address and port number of the remote
server to which the data is to be sent.
© Microhard Systems Inc.
Image 4-7-7: GPS > GPS Load Record
Record Time Range
Values (selection)
(no default)
Send Mode / Protocol
Values (selection)
NMEA via UDP
NMEA via TCP
GpsGate via UDP
GpsGate via TCP
Plain Text via UDP
Plain Text via TCP
Server Address/IP / Port
Values (IP/Port)
nms.microhardcorp.com
30175
102
