Installing and Operating
Passport ARN Routers
Part No. 114200-E Rev 00
October 2000
600 Technology Park Drive
Billerica, MA 01821-4130

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Passport ARN Routers and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nortel Passport ARN Routers

Summary of Contents for Nortel Passport ARN Routers

  • Page 1 Installing and Operating Passport ARN Routers Part No. 114200-E Rev 00 October 2000 600 Technology Park Drive Billerica, MA 01821-4130...

  • Page 2: Statement Of Conditions

    Nortel Networks NA Inc. does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
  • Page 3 EC Declaration of Conformity This product conforms (or these products conform) to the provisions of Council Directive 89/336/EEC and 73/23/EEC. Japan/Nippon Requirements Only Voluntary Control Council for Interference (VCCI) Statement Taiwan Requirements Bureau of Standards, Metrology and Inspection (BSMI) Statement Canada Requirements Only Canadian Department of Communications Radio Interference Regulations This digital apparatus (ARN router) does not exceed the Class A limits for radio-noise emissions from digital...
  • Page 4 Canada Requirements Only Repairs to certified equipment should be coordinated by a representative designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment. Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together.

  • Page 5: Fcc Part 68 Compliance Statement

    FCC. If you experience trouble with the unit, please contact the Nortel Networks Technical Solutions Center in your area for service or repairs. Repairs should be performed only by service personnel authorized by Nortel Networks.
  • Page 6 Software is provided will be free from defects in materials and workmanship under normal use for a period of 90 days from the date Software is first shipped to Licensee. Nortel Networks will replace defective media at no charge if it is returned to Nortel Networks during the warranty period along with proof of the date of shipment.
  • Page 7 Licensee will immediately destroy or return to Nortel Networks the Software, user manuals, and all copies. Nortel Networks is not liable to Licensee for damages in any form solely by reason of the termination of this license. 8. Export and re-export. Licensee agrees not to export, directly or indirectly, the Software or related technical data or information without first obtaining any required export licenses or other governmental approvals.

  • Page 9: Table Of Contents

    Preface Before You Begin ...xix Text Conventions ... xx Acronyms ...xxi Hard-Copy Technical Manuals ... xxiii How to Get Help ...xxiv Chapter 1 Installing the ARN Preparing to Install the ARN ...1-1 Verifying Shipment Contents ...1-2 Additional Equipment ...1-4 Cables ...1-4 Management Console ...1-4 Mounting Hardware ...1-4 Verifying Site Requirements ...1-5...
  • Page 10 Connecting to the ISDN Interface ...1-17 Connecting to the 56/64K DSU/CSU Interface ...1-18 Connecting to the FT1/T1 DSU/CSU Interface ...1-18 Connecting to the E1/FE1 DSU/CSU Interface ...1-19 Connecting to the Integrated V.34 Modem ...1-20 Connecting to the X.25 PAD Interface ...1-21 Connecting a Management Console ...1-23 Connecting a PC Console ...1-23 Connecting a Terminal Console ...1-25...
  • Page 11 Ethernet 100BASE-Fx LEDs ...3-4 Token Ring LEDs ...3-4 Expansion Module LEDs ...3-5 Ethernet LEDs ...3-5 Token Ring LEDs ...3-5 Serial LEDs ...3-6 Adapter Module LEDs ...3-6 Serial LED ...3-6 ISDN BRI LEDs (S/T or U Interfaces) ...3-7 56/64K DSU/CSU LEDs ...3-7 FT1/T1 and FE1/E1 DSU/CSU LEDs ...3-8 X.25 PAD LEDs ...3-8 V.34 Modem LEDs ...3-8...
  • Page 12 Enabling and Disabling Interfaces with ifconfig ... A-6 Examples of ifconfig Commands ... A-6 Using the bconfig Command ... A-7 Format for the bconfig Command ... A-7 Examples of bconfig Commands ... A-8 Verifying Your Configuration ... A-8 Appendix B Using Local Boot (the Quick-Start Procedure) Before You Run Quick-Start ...
  • Page 13 Appendix D Requirements for European Operation ARN Ethernet Base Model Safety Status ... D-1 ARN 10/100BASE-T Ethernet Base Model Safety Status ... D-2 ARN Token Ring Base Model Safety Status ... D-2 ARN Expansion Modules Safety Status ... D-3 Synchronous Cabling Requirements ... D-3 Serial Adapter Module Requirements ...
  • Page 15 Figure 1-1. Accessories in the ARN Shipping Container ...1-3 Figure 1-2. Options for Attaching Flange Brackets to Rack-Mount the ARN ...1-7 Figure 1-3. Installing the ARN in an Electronic Enclosure Rack ...1-8 Figure 1-4. ARN Module Locations ...1-9 Figure 1-5. Connecting an AUI Cable ...1-11 Figure 1-6.
  • Page 16 Figure 3-2. ARN Power Switch ...3-11 Figure 3-3. ARN Reset Button ...3-12 Figure 3-4. Removing an ARN Flash Memory Card ...3-13 Figure 3-5. Memory Card Read/Write Protect Switch ...3-14 Figure 4-1. Location of Adapter Module Slots 1 and 2 ...4-3 Figure 4-2.
  • Page 17 Table 1-1. Installation Space Requirements ...1-5 Table 1-2. V.34 Front-Panel Modem Adapter Module Defaults ...1-21 Table 1-3. Console Parameters ...1-26 Table 1-4. Console Modem Defaults ...1-27 Table 2-1. Summary of Initial Startup Options ...2-2 Table 2-2. Supported Boot Options by Interface ...2-3 Table 3-1.
  • Page 18 Table C-2. Network Interfaces Available on ARNs ... C-4 Table C-3. AUI Pin Assignments ... C-6 Table C-4. 10BASE-T and 10/100BASE-Tx Interface Pin Assignments ... C-7 Table C-5. Token Ring STP Interface Pin Assignments ... C-8 Table C-6. Token Ring UTP Interface Pin Assignments ... C-9 Table C-7.

  • Page 19: Preface

    The Passport Networks ® line of communications products. The ARN provides two WAN adapter slots to support a broad array of primary and backup connectivity options. In addition, the ARN supports up to two LAN and five serial interfaces. This guide describes installing, starting, and operating an ARN router. Before You Begin Before installing the ARN, ensure that all network wiring has been installed on the premises using standard cable-system practices.

  • Page 20: Text Conventions

    Text Conventions This guide uses the following text conventions: angle brackets (< >) bold text braces ({}) brackets ([ ]) ellipsis points (. . . ) Indicate that you choose the text to enter based on the description inside the brackets. Do not type the brackets when entering the command.

  • Page 21: Acronyms

    Indicates system output, for example, prompts and system messages. Example: Set Nortel Networks Trap Monitor Filters Shows menu paths. Example: Protocols > IP identifies the IP option on the Protocols menu. Separates choices for command keywords and arguments.
  • Page 22 CCITT CHAP CSMA/CD DLCMI HDLC IEEE ISDN ITU-T NBMA NEMA NVFS xxii International Telegraph and Telephone Consultative Committee (now ITU-T) challenge handshake authentication protocol carrier sense multiple access with collision detection channel service unit clear to send data carrier detect data communications equipment Data Collection Module Data Link Control Management Interface...

  • Page 23: Hard-Copy Technical Manuals

    OSPF PCMCIA RLSD RMON SMDS SNMP TCP/IP Hard-Copy Technical Manuals You can print selected technical manuals and release notes free, directly from the Internet. Go to the for which you need documentation. Then locate the specific category and model or version for your hardware or software product. Use Adobe Acrobat Reader to open the manuals and release notes, search for the sections you need, and print them on most standard printers.

  • Page 24: How To Get Help

    How to Get Help If you purchased a service contract for your Nortel Networks product from a distributor or authorized reseller, contact the technical support staff for that distributor or reseller for assistance. If you purchased a Nortel Networks service program, contact one of the following...

  • Page 25: Installing The Arn

    This chapter describes how to install the Passport ARN router, as follows: Topic Preparing to install the ARN Installing the ARN Understanding the ARN module locations Connecting communications cables Connecting a management console Connecting back-panel modem interfaces Connecting the power cables Installing the flash memory card Where to go next Note: The installation instructions in this chapter assume that wiring is...

  • Page 26: Verifying Shipment Contents

    Verifying Shipment Contents You should inspect all items for shipping damage. If you detect any damage, do not install the ARN. Call the Nortel Networks Technical Solutions Center in your area, as described in “How to Get Help.” In addition to the ARN and this guide, your shipping container should contain several other hardware accessory items.

  • Page 27: Accessories In The Arn Shipping Container

    Console/Modem Cable (DB-9 Receptacle to DB-25 Plug Cable) Figure 1-1. Accessories in the ARN Shipping Container 114200-E Rev 00 Power Cable DB-25 Receptacle Null Modem Adapter Two Flange Brackets Eight #6 Phillips Screws Four Cage Nuts Four #10 Cagenut Screws and Washers Four Rubber Feet ARN0048B...

  • Page 28: Additional Equipment

    Additional Equipment To install the ARN, you may need some additional items that are not part of the ARN accessory package. Before installing the ARN hardware, ensure that you obtain all the cables, tools, and other equipment that you need. Cables Unless they were specifically ordered, the cables necessary for your network configuration are not part of the ARN accessory package.

  • Page 29: Verifying Site Requirements

    Verifying Site Requirements The installation site must provide a certain amount of free space around the ARN to dissipate heat, as detailed in Table 1-1. Width 22.5 in. (57.2 cm) In addition, the installation site must meet the electrical and environmental specifications listed in Appendix C.

  • Page 30: Rack-Mounting The Arn

    Rack-Mounting the ARN For this procedure, you need: • Two flange brackets and eight #6 Phillips screws (shipped with the ARN) • A Phillips screwdriver • An electronic enclosure rack. If the rack does not have threaded rail holes, you must attach the four cage nuts shipped with the ARN.
  • Page 31 Screws (4 places) Figure 1-2. Options for Attaching Flange Brackets to Rack-Mount the ARN If the holes in the rack’s vertical supports are not threaded for cagenut screws, insert a cage nut in four locations 114200-E Rev 00 Screws (4 places) Front panel Front panel ARN0004B...
  • Page 32 Figure 1-3. Insert a cagenut screw through each bracket hole and into the corresponding holes in the rack. Tighten each cagenut screw with a Phillips screwdriver. 10BaseT ISDN BRI RLSD3 COM3 withNT1 RLSD4 RLSD5 Ethernet 2 RLSD 10BaseT Serial Base Expansion Boot Adapter1...

  • Page 33: Understanding The Arn Module Locations

    Understanding the ARN Module Locations The ARN is designed to scale to your needs. In addition to either an Ethernet or token ring base module, the ARN can contain an optional LAN expansion module and up to two WAN adapter modules Adapter modules ISDN BRI withNT1...

  • Page 34: Connecting Communications Cables

    Connecting Communications Cables Gather the communications equipment and cabling that you will attach to the ARN. If you do not have the proper cables, contact your network administrator or see the Cable Guide. Note: For cable interface descriptions, see Appendix C. Then, complete the steps in the applicable sections: •...

  • Page 35: Connecting To The Aui

    Connecting to the AUI The AUI interface provides broadband, baseband, fiber, and shielded twisted pair (STP) support, depending on the transceiver and cables you use. Caution: Connecting the ARN AUI interface directly to the AUI interface on an Ethernet station violates IEEE 802.3 standards. The AUI interface is designed only for connection to a transceiver.

  • Page 36: Connecting To The Utp Interface

    Connecting to the UTP Interface To connect an unshielded twisted-pair (UTP) cable to the base module or expansion module Ethernet interface, insert the UTP jack into the RJ-45 receptacle connector, as shown in ISDN BRI withNT1 RLSD Serial Ethernet network Figure 1-6.

  • Page 37: Connecting To The Fiber Interface

    Connecting to the Fiber Interface To connect a fiber cable to the base module or expansion module Ethernet interface, insert the fiber cable jack into the interface as shown in ISDN BRI withNT1 RLSD Serial Link Figure 1-8. Connecting an Ethernet 100BASE-Fx Cable Connecting to a Token Ring Interface You can connect a token ring cable to any ARN base module or expansion module that contains a token ring interface option.

  • Page 38: Connecting To The Stp Interface

    Connecting to the STP Interface To connect a token ring shielded twisted pair (STP) cable to the base module or expansion module token ring interface: Attach the 9-pin D-SUB plug to the token ring STP interface ISDN BRI withNT1 RLSD Serial Token Ring 1 Token Ring...

  • Page 39: Connecting To A Serial Interface

    The serial interfaces automatically configure the desired electrical interface when used with standard keyed cables. For information about cables available from Nortel Networks, see the Cable Guide. Note: The Cable Guide refers to serial cables that transmit synchronous data as “synchronous” cables.

  • Page 40: E Rev

    ISDN BRI withNT1 RLSD Serial Figure 1-11. Connecting Serial Cables to an Expansion Module Connector numbering on expansion module serial interfaces begin with COM3. RLSD Figure 1-12. 1-16 10BaseT RLSD3 RLSD4 RLSD5 Ethernet 2 10BaseT Base Boot Adapter1 Fail Adapter2 Ethernet 1 RS-232, RS-422,...

  • Page 41: Connecting To The Isdn Interface

    Serial adapter modules, labeled COM, can be in position 1 or 2. These interfaces are COM1 and COM2. Secure the cable to the interface using the capture screws on the cable. Connect the remote end of each cable to the appropriate communications equipment.

  • Page 42: Connecting To The 56/64K Dsu/Csu Interface

    Connecting to the 56/64K DSU/CSU Interface You connect 56/64K DSU/CSU service to the connector on an installed 56/64K DSU/CSU adapter module. To connect to the 56/64K DSU/CSU interface: Insert the 56/64K DSU/CSU cable connector into the DSU/CSU interface labeled DDS digital line wall jack Figure 1-14.

  • Page 43: Connecting To The E1/Fe1 Dsu/Csu Interface

    T1device Figure 1-15. Connect the other end of the cable to a T1 communications device. Connecting to the E1/FE1 DSU/CSU Interface You connect E1/FE1 service to the connector on an installed E1/FE1 adapter module. To connect to the E1/FE1 interface: Insert the RJ-48C cable connector into the E1/FE1 interface (Figure Figure 1-16.

  • Page 44: Connecting To The Integrated V.34 Modem

    Connecting to the Integrated V.34 Modem You connect dial services to the connector on an installed V.34 Modem adapter module. To connect a telephone cable to the integrated V.34 modem: Connect the RJ-11 telephone cable to the V.34 modem interface (Table 1-17).

  • Page 45: Connecting To The X.25 Pad Interface

    Table 1-2. Modem Signal/Parameter Clear To Send (CTS) Data Terminal Ready (DTR) Data Carrier Detect (DCD) or received line signal detection (RLSD) Data Set Ready (DSR) Ready to Send (RTS) Synchronous/Asynchronous Mode AutoAnswer Local Character Echo Supervisory Functions Baud Rate Data Bits Stop Bits Parity...
  • Page 46 Connecting a Breakout Box to the X.25 PAD Interface Connect the appropriate WAN cabling to each of the eight DB-25 interfaces on the breakout box that you will use. For information on cables available from Nortel Networks, see the Cable Guide. 1-22 (Figure 1-18).

  • Page 47: Connecting A Management Console

    Connecting a Management Console You can use the back-panel console ports to connect one or both of the following management devices: • PC or terminal • External modem or telephone connection to optional integrated V.34 modem Using a local console, you can monitor the results of the ARN startup diagnostics and set the boot configuration.

  • Page 48: Figure 1-20. Attaching The Null Modem Crossover Adapter

    Figure 1-19. Attach the null modem crossover adapter to the other end of the console cable (Figure Rotate to tighten screw Figure 1-20. Connect the other end of the null modem crossover adapter to the 25-pin plug connector on a standard AT serial cable. Connect the complete cable unit to the communications interface at the back of the PC 1-24...

  • Page 49: Connecting A Terminal Console

    Redundant Power 100-240~ 1.2A 50-60Hz Figure 1-21. Connecting a PC Console to an ARN Connecting a Terminal Console To connect a terminal console to the ARN, you need both of these pieces in the ARN console/modem cable kit (Order No. 110310): •...
  • Page 50 When you have the appropriate equipment, complete the following steps: Turn on and configure the terminal, using the parameters in and the terminal user guide. Table 1-3. Parameter Baud Rate Data Bits Stop Bits Parity Turn off the terminal. Insert the 9-pin receptacle end of the console cable into the ARN Console connector.

  • Page 51: Connecting A Console Modem

    Connecting a Console Modem A modem provides a system administrator with remote access to the ARN. It is a good idea to connect a modem in case the ARN experiences system problems. Note: To use the Netboot, Directed Netboot, or Local Boot software configuration options, you must connect a console the first time you power up the ARN.

  • Page 52: Connecting An External Console Modem

    Connecting an External Console Modem To connect an external modem to the ARN back panel, you need an AT or Hayes compatible modem and the modem cable (Order No. 110307) that came in the ARN console/modem cable kit. Note: Do not use the null modem crossover adapter (Order No. 110308) in the ARN cable kit to connect to a modem.

  • Page 53: Connecting The Power Cable

    Figure 1-24. Connecting the Power Cable Danger: Be sure that the power switch on the ARN back panel is in the OFF (0) position before you connect the power cable. To connect the power cable to the ARN, complete these steps: Connect the power cable to the power connector on the left side of the ARN back panel 114200-E Rev 00...

  • Page 54: Figure 1-25. Connecting The Power Cable To The Arn

    Installing and Operating Passport ARN Routers Power switch (off) Redundant Power 100-240~ 1.2A 50-60Hz To power outlet To redundant power supply ARN0017A Figure 1-25. Connecting the Power Cable to the ARN Connect the remote end of the power cable to a grounded outlet.

  • Page 55: Installing The Flash Memory Card

    Installing the Flash Memory Card Nortel Networks ships the router software on a PCMCIA flash memory card (Figure 1-26). The flash memory card provides storage for the Nonvolatile File System (NVFS) in the ARN. Figure 1-26. Before starting the ARN, install the flash memory card supplied with the router: Position the card with the label facing up and the INSERT arrow pointing toward the card receptacle.

  • Page 56: Where To Go Next

    Where to Go Next Use the following table to determine where you want to go next. For information about Starting the ARN Operating the ARN Configuring the ARN for Netboot and Directed Netboot Using Local Boot (the Quick-Start Procedure) ARN Technical Specifications 1-32 Go to Chapter 2...

  • Page 57: Starting The Arn

    The default configuration file is named config. Nortel Networks ships the executable and default configuration files on a PCMCIA flash card, but the ARN can also obtain them over the network. Getting a file over the network is called network booting, or netbooting. Getting a file from the router file system, stored in flash memory, is local booting.
  • Page 58 When you start the ARN for the first time, it completes an initial startup procedure to boot and connect to the network using either a default configuration file or one already customized and available on the network. You use one of four boot options to complete the initial software startup. summarizes the four options;...
  • Page 59 You may not be able to use all methods described in this chapter to boot over some interfaces on your router. For example, you cannot netboot over an FT1/T1 interface. In some cases, you may use one interface to boot your router and then switch to a different interface (such as the FT1/T1 DSU/CSU) to establish your initial IP network connection to the management workstation.

  • Page 60: Starting The Arn For The First Time

    Starting the ARN for the First Time The ARN factory defaults are set to find the image file and configuration file from the following locations: • Image file -- on the local PCMCIA flash memory card • Configuration file -- over the network These default settings work with the default EZ-Install procedure.

  • Page 61: Using Ez-Install

    Using EZ-Install EZ-Install is the default installation option provided by Nortel Networks. This option requires that your network administrator has set up the network so that you can start the EZ-Install procedure. In addition, this option requires that you: •...

  • Page 62: Using Netboot, Directed Netboot, Or Local Boot

    Using Netboot, Directed Netboot, or Local Boot When you netboot or local boot the ARN, you must use a command line interface that accesses the router software. To use a command line interface, you can: • Wait for the ARN to local boot (that is, wait for the router to fail EZ-Install and then attempt to boot using its local configuration file).

  • Page 63: Logging In To The Command Line Software

    While the router is running the EZ-Install procedure, issue a break sequence from the management console. The ARN monitor login prompt appears. Note: Be sure to issue a break sequence before the boot process completes. Break sequences can vary, depending on the console type. Some management consoles have specific “Break”...

  • Page 64: Continuing With Netboot

    • Verify that the network is set up for the netboot procedure, as described in the Configuring Remote Access for AN and Passport ARN Routers guide. • Provide you with the parameter arguments to the interface configuration...
  • Page 65 Your network administrator can refer to Configuring Passport Remote Access to troubleshoot any problems. If you need additional assistance, contact your local Nortel Networks Technical Solutions Center. Note: After connecting the ARN to the network, you can replace the local management console with a modem connection to enable remote dial-in access.

  • Page 66: Continuing With Directed Netboot

    However, this guide assumes that you are using either the ARN monitor or the Technician Interface. To manage the ARN from a remote site, refer to Configuring Remote Access for AN and Passport ARN Routers. 2-10 you will use in Step 1.
  • Page 67 To use the directed netboot feature: At the command line prompt, enter the by your network administrator and press the Return key. The following is a sample command: ifconfig com1 9.0.0.2 255.0.0.0 9.0.0.3 For more information about the Command” on page A-2. Enter the and press the Return key.
  • Page 68 $ getcfg Boot Options Netboot Parameters: Figure 2-1. getcfg correct and reenter the assistance, contact your network administrator. Type the following command and press the Return key to boot the ARN: boot Note: If the ARN cannot find a software image file or a configuration file using the directed netboot procedure, it attempts to netboot once.

  • Page 69: Continuing With Local Boot (The Quick-Start Procedure)

    To troubleshoot any problems, your network administrator can refer to Configuring Passport Remote Access. If you need additional assistance, contact your local Nortel Networks Technical Solutions Center. Note: After connecting the ARN to the network, you can replace the management console connection with a modem connection to enable remote dial-in access.
  • Page 70 Type the following command and press the Return key to boot the ARN: boot Note: If the ARN tries to local boot and cannot find a software image file or a configuration file, it attempts to netboot once. If both attempts fail, the ARN continues to local boot and netboot until it boots successfully.

  • Page 71: Where To Go Next

    To troubleshoot any problems, your network administrator can refer to Configuring Passport Remote Access. If you need additional assistance, contact your local Nortel Networks Technical Solutions Center. Note: After connecting the ARN to the network, you can replace the management console connection with a modem connection to enable remote dial-in access.

  • Page 73: Operating The Arn

    This chapter describes how to operate the Passport ARN router, as follows: Topic Understanding LED descriptions Ensuring a successful installation Powering on and off the ARN Resetting the ARN Removing a flash memory card Protecting memory card files Where to go next Understanding the ARN LEDs Light-emitting diodes (LEDs) on the ARN provide information about how the ARN is operating.

  • Page 74: Base Module Leds

    Base Module LEDs The base module includes diagnostic LEDs and LAN interface LEDs, visible on the front panel of the ARN. Diagnostic LEDs The base module diagnostic LEDs itself. All of these LEDs light briefly when you turn on the ARN power switch. ISDN BRI withNT1 RLSD...

  • Page 75: Ethernet 10Base-T Leds

    Table 3-1. Base Adapter1 Adapter2 Expansion PCMCIA Ethernet 10BASE-T LEDs Table 3-2 describes the base module Ethernet 10BASE-T LEDs. Table 3-2. Tx (Transmit) Rx (Receive) Cl (Collision) 114200-E Rev 00 Base Module Diagnostic LEDs Meaning Lights and remains on when the redundant power supply (optional) is operating.

  • Page 76: Ethernet 10/100Base-Tx Leds

    Ethernet 10/100BASE-Tx LEDs Table 3-3 describes the base module Ethernet 10/100BASE-Tx LEDs. Table 3-3. TX (Transmit) RX (Receive) CL (Collision) Link Ethernet 100BASE-Fx LEDs Table 3-4 describes the base module Ethernet 100Base-Fx LEDs. Table 3-4. TX (Transmit) RX (Receive) Link Token Ring LEDs Table 3-5 describes the base module token ring LEDs.

  • Page 77: Expansion Module Leds

    Expansion Module LEDs When the ARN has an installed expansion module, its interface LEDs are visible on the front panel. For the location of the optional ARN expansion module, see Figure 1-4 on page 1-9. Note: The ARN base module boots to a fully operational state before bringing up expansion module interfaces.

  • Page 78: Serial Leds

    Serial LEDs Table 3-8 describes the expansion module serial interface LEDs. Table 3-8. RLSD3 (Received Line Signal Detection 3) RLSD4 (Received Line Signal Detection 4) RLSD5 (Received Line Signal Detection 5) Adapter Module LEDs When the ARN/DC has an optional adapter module installed, its interface LEDs are visible on the front panel.

  • Page 79: Isdn Bri Leds (S/T Or U Interfaces)

    ISDN BRI LEDs (S/T or U Interfaces) Table 3-10 describes the ISDN adapter module LEDs. Table 3-10. S/T Interface Unlabeled LED U Interface (D-channel; 16-KB Management Channel) (Data Detect) (B-Channel #1; 64-KB Data Channel) (B-Channel #2; 64-KB Data Channel) 56/64K DSU/CSU LEDs Table 3-11 describes the 56/64K DSU/CSU adapter module LEDs.

  • Page 80: Ft1/T1 And Fe1/E1 Dsu/Csu Leds

    FT1/T1 and FE1/E1 DSU/CSU LEDs Table 3-12 describes the FT1/T1 and FE1/E1 DSU/CSU adapter module LEDs. Table 3-12. Red ALM Yellow ALM Loop Synch X.25 PAD LEDs Table 3-13 describes the X.25 PAD adapter module LEDs. Table 3-13. (Transmit Data) (Receive Data) V.34 Modem LEDs Table 3-14...

  • Page 81: Ensuring A Successful Installation

    Table 3-14. (Transmit) (Receive) RLSD (Received Line Signal Detection) (Data Terminal Ready) Ensuring a Successful Installation After connecting the ARN to the network, you can ensure a successful installation by checking the diagnostic LEDs on the front panel of the base module (refer to Figure 3-1 When you power on the ARN, the following sequence of front panel LED activity should occur:...
  • Page 82 If the LEDs do not light in this sequence, your network administrator can refer to Configuring Remote Access for AN and Passport ARN Routers to help troubleshoot the problem. Note: If the ARN does not contain an expansion module, an adapter module, a redundant power supply, a data collection module, or a flash card, the LEDs associated with these components remain off.

  • Page 83: Powering On And Off

    If the ARN does not turn on, check the power cable connections. See “Connecting the Power Cable” on page 1-29 for information. If the ARN will not power on, contact the Nortel Networks Technical Solutions Center. To power off the ARN, press the power switch to the OFF position (0).

  • Page 84: Resetting The Arn

    Resetting the ARN The Reset button is set inside the ARN back panel and resides next to the flash card slot, as shown in 100-240~ 1.2A 50-60Hz Figure 3-3. ARN Reset Button To press the Reset button, insert a small pointed object (for example, a paper clip) into the Reset button hole.

  • Page 85: Removing A Flash Memory Card

    Removing a Flash Memory Card To remove a memory card from an ARN: Press the eject button next to the card receptacle on the back panel. The card pops out slightly. Pull the memory card out of the card receptacle. Figure Caution: Do not remove the flash memory card while the router is operating.

  • Page 86: Protecting Memory Card Files

    Protecting Memory Card Files Nortel Networks ships each memory card with its read/write protect switch in the unprotected position and saving your configuration, you may want to write-protect the memory card for backup purposes. Note: You typically do not operate the ARN with a write-protected memory card.

  • Page 87: Where To Go Next

    Where to Go Next Use the following table to determine where you want to go next. For information about Installing the ARN Configuring the ARN for Netboot and Directed Netboot Using Local Boot (the Quick-Start Procedure) ARN Technical Specifications 114200-E Rev 00 Go to Chapter 2 Appendix A...

  • Page 89: Installing A Wan Adapter Module

    Preparing for Installation Before installing the module, examine the contents of your adapter module upgrade kit. If any parts appear damaged, call the Nortel Networks Technical Solutions Center immediately. 114200-E Rev 00 Installing a WAN Adapter Module...

  • Page 90: Downloading New Boot And Diagnostic Code

    Downloading New Boot and Diagnostic Code When installating an adapter module as an upgrade to your existing hardware configuration, you must verify that the ARN contains the minimum required version of programmable read-only memory (PROM) code for the module you are installing.

  • Page 91: Removing The Filler Panel

    Determine which of the two front-panel adapter module slots to use (Figure Figure 4-1. Remove the installed adapter module or the slot filler panel. • To install the adapter module in an empty slot, go to “Removing the Filler • To replace an installed adapter module, go to “Removing an Adapter Removing the Filler Panel...
  • Page 92 Metal tab on filler panel Figure 4-2. Grasp the metal tab on the filler panel and pull forward to remove the panel. Set the filler panel aside. To operate the ARN without an adapter module in this slot, you must reinstall the filler panel.

  • Page 93: Removing An Adapter Module

    Removing an Adapter Module To remove a WAN adapter module: Using a Phillips screwdriver, remove the screw that secures the adapter module you want to remove ISDN DSU/CSU Figure 4-3. Pull the adapter module toward you to detach it from the base module connector in the ARN chassis.

  • Page 94: Installing An Adapter Module

    Installing an Adapter Module To install a WAN adapter module: Hold the adapter module with the components facing up Base module connector Figure 4-4. Slide the adapter module into the slot, making sure that the slot guides engage both sides of the adapter module Figure 4-5.

  • Page 95: Figure 4-6. Securing The Adapter Module To The Front Panel

    Push the adapter module in until its connector pins align with the base module connector socket in the ARN chassis. Using a Phillips screwdriver, insert and tighten the screw ISDN DSU/CSU Figure 4-6. Remove the antistatic wrist strap. Connect the appropriate WAN cabling to the new interface. For cabling information, see the module-specific Supplement and the Nortel Networks Cable Guide.

  • Page 96: What To Do Next

    What to Do Next Before you can use the WAN adapter module after installation, you must start the router on the network and modify its configuration file to include the new interface. See your module-specific Supplement for a list of software installation tasks and related documentation.

  • Page 97: Appendix A Configuring The Arn For Netboot And Directed Netboot

    Configuring the ARN for Netboot and This appendix describes how to configure the Passport ARN router for Netboot and Directed Netboot, as follows: Topic ifconfig Using the bconfig Using the Verifying your configuration ifconfig netboot. Use the i • network. You need this information to complete the procedure in “Continuing with Netboot”...

  • Page 98: Using The Ifconfig Command

    Using the ifconfig Command A router interface cannot communicate in an IP network without an IP address. Because an ARN netboots over one of its serial, 56/64K DSU/CSU, Ethernet, or token ring links, the netboot interface must have a valid IP address. You use the interface configuration command •...
  • Page 99 WAN configurations in the following order until it finds the correct type for the router connection to the network: 1. Nortel Networks HDLC encapsulation (also referred to as Nortel Networks Standard Point-to-Point) with external clocking 2. Frame Relay Annex D 3.

  • Page 100: Configuring An Ethernet Interface For Network Booting

    Table A-1. Setting <subnet_mask> <next_hop_ address> Configuring an Ethernet Interface for Network Booting To configure any ARN Ethernet interface for network booting, use the following command format: ifconfig Table A-2 describes the Ethernet interface. Table A-2. Setting <interface> <IP_address> <subnet_mask> <next_hop_ address>...

  • Page 101: Configuring A Token Ring Interface For Network Booting

    Configuring a Token Ring Interface for Network Booting To configure an ARN token ring interface for network booting, use the following command format: ifconfig [ <next_hop_address> ]] Table A-3 describes the token ring interface. Table A-3. Setting <speed> <interface> <IP_address> <subnet_mask>...

  • Page 102: Enabling And Disabling Interfaces With Ifconfig

    Enabling and Disabling Interfaces with ifconfig To enable or disable an ARN interface for the network boot process, use the following command formats: ifconfig -disable <interface> ifconfig -enable <interface> Table A-4 describes the interfaces for network booting. Table A-4. Setting <...

  • Page 103: Using The Bconfig Command

    Using the bconfig Command You use the • To use netboot, you use the boot configuration command that the ARN software image file or configuration file resides on the network. • To use directed netboot, you use the address of the server and the full pathname to the software image and configuration file.

  • Page 104: Examples Of Bconfig Commands

    Examples of bconfig Commands 1. Configure the default netboot procedure. Use a local image file and look for the configuration file over the network using BootP. bconfig -d image bconfig -d config 2. Use netboot for both the image file and the configuration file. bconfig image network bconfig config network 3.
  • Page 105 The following sample response shows the settings for an ARN with one Ethernet, one token ring, and five serial interfaces: Boot Options boot image=local boot config=network Netboot Parameters: MAU1...None XCVR2..None COM1...EZ-Install COM2...EZ-Install COM3...EZ-Install COM4...EZ-Install COM5...EZ-Install 114200-E Rev 00...

  • Page 107: Using Local Boot (The Quick-Start Procedure)

    Using Local Boot (the Quick-Start Procedure) This appendix describes how to complete a local boot by running the Quick-Start script, as follows: Topic Prepare to run Quick-Start Understand Quick-Start connector names and numbers Fill out Quick-Start sample worksheets Run the Quick-Start script This appendix explains how to local boot the ARN and create an initial Internet Protocol (IP) interface using the Quick-Start procedure to get the ARN router up and running on the network.

  • Page 108: Before You Run Quick-Start

    Before You Run Quick-Start To aid you in answering Quick-Start prompts, some sample worksheets are provided. Fill them out with assistance from your network administrator. The worksheets contain options that appear at each prompt when configuring a serial interface, and space for you to enter your own information. If you are configuring an interface other than the serial interface, the prompts will differ from what is shown in the sample worksheets.

  • Page 109: Global Information Worksheet

    Table B-1 provides the connector names and numbers you should use during the Quick-Start procedure. Table B-1. Interface* Ethernet Token Ring Serial 56/64K, FT1/T1, or FE1/E1 DSU/CSU * The Quick-Start script does not support initial ISDN, X.25 PAD, or V.34 interface configuration.
  • Page 110 RIP. Fill out one Wide Area Protocol worksheet. This worksheet lists specific options for Nortel Networks (proprietary) Point-to-Point Protocol (PPP), frame relay, Standard PPP, and switched multimegabit data service (SMDS) configurations. For example, if you select frame relay as your wide area protocol, you need to fill out only the frame relay worksheet.

  • Page 111: Global Information Worksheet

    Global Information Worksheet This section contains the prompts and possible options relating to all ARN serial configurations. Write your selection in the “Your Response” column. Global Information Worksheet Step Requested Information Enter the module number [1]: Driver Type: 114200-E Rev 00 Options The script lists the available modules that you can use to...
  • Page 112 Global Information Worksheet Step Requested Information Enter connector number [1]: Enter clock source number [2]: Enter clock speed number [10]: Enter circuit name [S#]: (continued) Options If there is only one connector on the module you chose, the script automatically assigns a connector number and bypasses this prompt.
  • Page 113 Enter the subnetwork mask for the COM interface IP address. y(es) n(o) 1. RIP 2. OSPF 3. Static Route to Site Manager 1. Nortel Networks Point-to-Point Protocol (Proprietary) 2. Frame Relay 3. Point-to-Point Protocol (PPP) Standard 4. Switched Multimegabit Data...

  • Page 114: Router Protocol Worksheets

    Global Information Worksheet Step Requested Information Do you want to enable TI TELNET (y/n) [n]: Do you wish to save this configuration to a file? (y/n) [y] Enter filename [ startup.cfg ]: Do you wish to set up another port/module? (y/n) [y] Router Protocol Worksheets This section contains requested information and possible options relating to the routing protocol choices on the Global Worksheet.
  • Page 115 RIP Worksheet (continued) Requested Information Specify the version of RIP . The default is to run RIP1. Rip2 runs RIP2 without the automatic aggregation of subnets that RIP1 provides. RIG2_AGGR provices the automatic aggregation of subnets for RIP2. Enter Routing Protocol Number [1]: OSPF Worksheet Requested Information Enter OSPF router ID in dotted...
  • Page 116 Enter decimal value for Router Priority [1]: (For Broadcast, NBMA, or Point-to-MultiPoint) B-10 Options 1. Default 2. Ethernet size (Nortel Networks Series 5 compatible) 3. User Defined MTU 1. Broadcast 2. NBMA 3. Point-to-Point 4. Point-to-Multipoint (Proprietary) 5. Point-to-Multipoint (Per OSPF...
  • Page 117 OSPF Worksheet (continued) Requested Information Enter decimal value in seconds for Poll Interval [120]: (For NBMA only) Enter IP address of neighbor in dotted decimal notation or enter q to quit: (For NBMA only) Enter IP address of neighbor in dotted decimal notation: (For PPP only) Static Route to Site Manager Worksheet...

  • Page 118: Wide Area Protocol Worksheets

    (y/n) [n]: Wide Area Protocol Worksheets This section contains requested information and possible options relating to wide area protocol choices on the Global Worksheet. Nortel Networks Proprietary PPP Worksheet Requested Information Enter BofL (Breath of Life) timer value (1-60) [5]:...
  • Page 119 Nortel Networks Proprietary PPP Worksheet Requested Information Enter Remote Address selection [3]: Frame Relay Worksheet Requested Information Enter Management type [3]: Enter addressing type [4]: Enter address field length [2]: Enter DLCI number [30]: (For DLCMI None, LMI Switch, Annex...
  • Page 120 Note: If you answer y(es), the router requests the PAP ID and password for the remote interface. y(es) n(o) Note: Link Quality Monitoring on a Nortel Networks Series 5 router is not compatible with this feature. Your Response (continued) 114200-E Rev 00...
  • Page 121 PPP Standard Worksheet Requested Information Enable use of the Remote Peer router’s LQR Timer? (y/n) [y]: (For LQR Protocol only) Number of seconds (1-120) [3]: (For LQR Protocol only) Enter [inbound] success rate percentage (1-100) [90]: Enter [outbound] success rate percentage (1-100) [90]: 114200-E Rev 00 (continued)

  • Page 122: Running The Quick-Start Script

    SMDS Worksheet Requested Information Enter 10-digit individual address: Enter 10-digit group address: Enter 10-digit arp address: Running the Quick-Start Script The Quick-Start script is called inst_arn.bat and you run it as part of the Local Boot process. Note: Before you run the Quick-Start script, make sure you have the completed worksheets with you.
  • Page 123 Type the following command and press the Return key: run inst_arn.bat Follow the script online, using your worksheets when responding to its prompts. The list of commands in Quick-Start script. Table B-2. Task Accept a default value Repeat a step (for example, if you make a mistake) Stop the Quick-Start...

  • Page 124: Technician Interface

    Name and save the configuration file. The script begins to test the configuration on the new IP interface (Figure Testing local IP interface ping -IP 192.32.00.000 -r5 IP ping: IP ping: IP ping: IP ping: IP ping: This test attempts to ping the Site Manager workstation. NOTE: If routing has not yet converged, an attempt to ping the Site Manager workstation may fail.

  • Page 125: Arn Technical Specifications

    This appendix provides technical specifications and a product overview of the ARN and its interface options, as follows: Topic Physical specifications Electrical specifications Environmental specifications Hardware communications options Physical Specifications The dimensions and weight of the ARN are as follows: •...

  • Page 126: Electrical Specifications

    If you are installing your ARN in an electronic equipment rack, make sure that the rack meets the following specifications: • Heavy-duty steel construction • Electronic Industries Association (EIA) standard hole-spacing • Width of 19 in. (48.26 cm) • Depth of 24 in. (60.96 cm) Electrical Specifications Your installation site must meet the following power requirements: •...

  • Page 127: Hardware Communications Options

    Hardware Communications Options The ARN is designed to scale to your needs. In addition to either an Ethernet or token ring base module, you can add an optional expansion and up to two optional adapter modules to the ARN. The ARN is available in the following base module configurations: •...
  • Page 128 • One ISDN BRI U interface • One V.34 modem interface • One 56/64K DSU/CSU interface • One FE1/E1 DSU/CSU interface • One FT1/T1 DSU/CSU interface • One X.25 PAD interface Table C-2 describes each interface. Table C-2. Network Interfaces Available on ARNs Network Interface Description...
  • Page 129 Table C-2. Network Interfaces Available on ARNs Network Interface Description Serial Provides WAN connectivity. ARN models can have up to five serial ports (three on an expansion module and up to two adapter modules). Each port can operate independently with RS-232, RS-422, RS-449, RS-530, V.28, V.35, and X.21 cables.

  • Page 130: Ethernet Attachment Unit Interface (Aui

    Ethernet Attachment Unit Interface (AUI) The ARN Ethernet 10BASE-T base module, Ethernet expansion module, and Ethernet/tri-serial expansion modules contain a 10BASE-T standard 802.3 AUI DB-15 receptacle with a slide lock. Note: The AUI is designed only for connection to a transceiver. Connecting the AUI directly to an AUI on an Ethernet station (without a transceiver) violates IEEE 802.3 standards.

  • Page 131: Ethernet 10Base-T And 10/100Base-Tx Interfaces

    Ethernet 10BASE-T and 10/100BASE-Tx Interfaces The Ethernet 10BASE-T and 10/100BASE-Tx interfaces provide UTP support. Table C-4 identifies the pin locations and function assignments for these interfaces. Table C-4. Pin Assignment 12345678 114200-E Rev 00 10BASE-T and 10/100BASE-Tx Interface Pin Assignments Pin No.

  • Page 132: Token Ring Stp Interface

    Token Ring STP Interface The token ring STP interface provides shielded twisted-pair support. The ARN token ring base module, token ring expansion module, and token ring/tri-serial expansion modules contain this standard 802.5 DB-9 receptacle. Table C-5 shows the pin assignments for the standard 9-pin STP receptacle on the ARN base or expansion module and identifies its pin locations.

  • Page 133: Token Ring Utp Interface

    Token Ring UTP Interface The token ring UTP interface provides unshielded twisted-pair support. The ARN token ring expansion module and token ring/tri-serial expansion modules contain this receptacle. Table C-6 shows the RJ-45 pin assignments for the UTP interface and identifies the pin locations.

  • Page 134: Serial Interface Pin Assignments

    • RS-422 connections (Order No. 7318) • RS-232 connections (Order No. 7826) • RS-530 connections (Order No. AE0018012) Table C-7 shows the signal and pin assignments for these connectors. Table C-7. Serial Interface Pin Assignments Pin Assignment Pin 15 Pin 30 Pin 44 C-10 Pin No.

  • Page 135: Isdn Bri U Interface

    ISDN BRI U Interface The ARN supports the BRI standard for ISDN using an optional ISDN/BRI adapter module. The integrated ISDN BRI functionality allows you to connect directly to the ISDN network, through a U interface, as opposed to connecting over a terminal adapter.

  • Page 136: Isdn Bri S/T Interface

    ISDN BRI S/T Interface The ARN supports the BRI standard for ISDN using an optional ISDN/BRI adapter module. The integrated ISDN BRI functionality allows you to connect to the ISDN network over a terminal adapter through an S/T interface. The BRI implementation supports two dial service applications: dial-on-demand and dial backup.

  • Page 137: 56/64K Dsu/Csu Interface

    56/64K DSU/CSU Interface The ARN supports direct synchronous access to either a 56K dataphone digital service (DDS) or 64K Clear Channel dedicated services using an optional 56/64K DSU/CSU adapter module. The 56/64K DSU/CSU interface uses an 8-pin RJ-45 connector as shown in Table C-10 lists the 56/64K DSU/CSU interface pin assignments.
  • Page 138 Table C-11 lists the ARN FT1/T1 DSU/CSU connector pinouts. Table C-11. Pin Assignment 12345678 C-14 RJ-48C Connector Pinouts Pin No. Signal Receive Data RING Receive Data TIP No Connect Send Data RING Send Data TIP No Connect No Connect No Connect 114200-E Rev 00...

  • Page 139: X.25 Pad Connections

    X.25 PAD Connections The ARN provides X.25 PAD functions that enable the router to access X.25 services through the 8 ports of an attached breakout box. The PAD establishes and maintains links with the packet switch network, assembles and disassembles packets, communicates with the character terminal, and handles special control processes for the character terminal.

  • Page 140: Interface (For V.34 Modem

    RJ-11 Interface (for V.34 Modem) The ARN supports a V.34 modem connection using an optional V.34 modem adapter module. The V.34 functionality allows you to connect directly to a phone line, as opposed to connecting over an external modem. This solution reduces equipment costs and simplifies connection to a wide area network.

  • Page 141: Service Modem Connections

    The connector pin assignment described in assignments for the Console port. Table C-14. Pin Assignment Pin 1 Service Modem Connections The ARN back panel contains one modem service interface, labeled Modem; its DB-9 plug connector provides an RS-232-D serial connection. You use this local console port to connect the ARN to any Hayes compatible modem for remote dial-in access.
  • Page 142 The connector pin assignment described in assignments for the modem port. Table C-15. Pin Assignment Pin 1 C-18 Table C-15 Service Modem Port DB-9 Pin Assignments Pin No. Signal Name DCD (Data carrier detect) TXD (Transmit data) RXD (Receive data) DSR (Data set ready) DTR (Data terminal ready) Pin 9...

  • Page 143: Requirements For European Operation

    Requirements for European Operation This appendix provides information required for operating the ARN in Europe, cabling requirements for synchronous (serial) connection, and information about using the serial adapter module (Order No. CV0004001) and ISDN BRI adapter module (Order No. CV0004002) in Europe. ARN Ethernet Base Model Safety Status Table D-1 lists the safety status of interconnection points to the connection of...

  • Page 144: Arn 10/100Base-T Ethernet Base Model Safety Status

    ARN 10/100BASE-T Ethernet Base Model Safety Status Table D-2 lists the safety status of interconnection points to the connection of other equipment. Table D-2. Port Location Console ARN Token Ring Base Model Safety Status Table D-3 lists the safety status of interconnection points to the connection of other equipment.

  • Page 145: Arn Expansion Modules Safety Status

    ARN Expansion Modules Safety Status ARN expansion modules are upgrade options that provide an additional synchronous interface. These options can be installed in any ARN model. Table D-4 lists the safety status of the interconnection point (COM3, COM4, COM5, COM6, COM7, COM8, and COM9) provided by each of the expansion modules (Order Nos.

  • Page 146: Figure D-1. Cable 7837 (V.28 Compliant

    44-position D-Sub plug with screw locks (ground shield connected to backshell) Figure D-1. Cable 7837 (V.28 Compliant) Table D-5. WAN Interface (Order No. 7837) Nortel Networks Termination Signal Frame Ground Send Data+ Receive Data+ Request to Send+ Clear to Send+...

  • Page 147: Figure D-2. Cable 7934 (V.28 Compliant

    Pin 26 50-position 0.8-mm plug (ground shield connected to internal shell) Figure D-2. Cable 7934 (V.28 Compliant) Table D-6. WAN Interface (Order No. 7934) Nortel Networks Termination Signal Frame Ground Send Data+ Receive Data+ Request to Send+ Clear to Send+...

  • Page 148: Figure D-3. Cable 7220 (V.35 Compliant

    Pin 1 Pin 16 Pin 31 44-position D-Sub plug with screw locks (ground shield connected to backshell) Figure D-3. Cable 7220 (V.35 Compliant) Table D-7. V.35 Interface (Order No. 7220) Nortel Networks Termination Signal VSD+ VSD- VRT+ VRT- VST+ VST- VRD+...

  • Page 149: Figure D-4. Cable 7932 (V.35 Compliant

    Table D-7. V.35 Interface (Order No. 7220) Nortel Networks Termination Data Carrier Detect+ Signal Ground Pin 19 > 20 > 23 > 7 Pin 41 > 42 > 43 Pin 13 > 28 Pin 14 > 29 Pin 1 Pin 26 50-position 0.8-mm plug...
  • Page 150 Table D-8. V.35 Interface (Order No. 7932) Nortel Networks Termination VST- VRD+ VRD- Data Set Ready+ Data Terminal Ready+ Request to Send+ Clear to Send+ VTT+ VTT- Frame Ground Data Carrier Detect+ Signal Ground Pin 7 > 30 > 31 > 34 Pin 46 >...
  • Page 151 44-position D-Sub plug with screw locks (ground shield connected to backshell) Figure D-5. Cable 7224 (X.21 Compliant) Table D-9. X.21 Interface (Order No. 7224) Nortel Networks Termination Signal Send Data+ Send Data- Request to Send+ Request to Send- Receive Data+...

  • Page 152: Figure D-6. Cable 7936 (X.21 Compliant

    Pin 26 50-position 0.8-mm plug (ground shield connected to internal shell) Figure D-6. Cable 7936 (X.21 Compliant) Table D-10. X.21 Interface (Order No. 7936) Nortel Networks Termination Signal Send Data+ Send Data- Request to Send+ Request to Send- Receive Data+...

  • Page 153: Serial Adapter Module Requirements

    Serial Adapter Module Requirements The serial adapter module (Order No. CV0004001) is approved only for installation in a host, and with host attachments, which are either type approved for such apparatus or, if supplied after 1st March 1989, are marked with or supplied with a statement that the host is supplied under the terms of General Approval Number NS/G/1234/J/100003.

  • Page 154: Isdn Bri Adapter Module Requirements

    ISDN BRI Adapter Module Requirements The ISDN BRI adapter module (Order No. CV0004002) is approved only for installation in a host, and with host attachments, which are either type approved for such apparatus or, if supplied after 1st March 1989, are marked with or supplied with a statement that the host is supplied under the terms of BABT General Approval Number NS/G/1234/J/100003.

  • Page 155: Power Requirements For Isdn Bri And Serial Adapter Modules

    Power Requirements for ISDN BRI and Serial Adapter Modules The ISDN BRI and serial adapter modules obtain power from the host chassis and have the power requirements shown in Table D-14. Voltage +5 V +12 V -12 V The power drawn from the host chassis combined with that required for any other cards and accessories must be within the power rating of the host chassis.
  • Page 156 SELV cards Figure D-7. Table D-15. Clearance (X) 2.0 mm 2.6 mm 4.0 mm 4.0 mm D-14 ISDN Module Baseboard Clearance and Creepage Distances for ISDN BRI and Serial Adapter Modules Clearance and Creepage Distances for ISDN BRI and Serial Adapter Modules Voltage used or generated by other parts Creepage (Y)
  • Page 157 The creepage distances apply to the normal office environment. When the local environment within the host chassis is subject to conductive pollution or dry nonconductive pollution that could become conductive due to condensation, the creepage distances shown in parentheses in The clearance and creepage distance between adjacent points should be checked as follows: •...
  • Page 159 Numbers 10/100BASE-Tx pin assignments, C-7 100BASE-Fx, 1-9 interface, connecting to, 1-13 10BASE-T interface, connecting to, 1-12 7934, 50-pin to RS-232 cable, D-5 acronyms, xxi adapter modules connecting to DSU/CSU interfaces, 1-18, 1-19, 1-21 ISDN interfaces, 1-17 serial interfaces, 1-17 V.34 interface, 1-20 DSU/CSU LEDs, 3-7, 3-8 interface options, 1-9, C-3 ISDN LEDs, 3-7...
  • Page 160 B-channel #2 (B2) LED, 3-7 bconfig command default netboot settings, A-8 described, 2-10 directed netboot, A-8 examples, A-8 format, A-7 local boot, A-8 using, A-7 boot command directed netboot, 2-12 local boot, 2-14, B-16 netboot, 2-9 getcfg command display, A-9 interrupting, 2-6 options, described, 2-2 Boot LED, 3-2...
  • Page 161 connecting 100BASE-Fx cables, 1-13 10BASE-T cables, 1-12 AUI cables, 1-11 communications cables, 1-10 DSU/CSU cables, 1-18, 1-19, 1-21 Ethernet cables, 1-10, 1-12, 1-13 ISDN cables, 1-17 management console cables, 1-23 to 1-24 modem cables back panel, 1-28 front panel, 1-20 PC console cables, 1-23 power cables, 1-30 serial cables, 1-15...
  • Page 162 AUI, 1-9 base module, 1-9 expansion module, 1-9 interfaces configuring, A-4 connecting to, 1-10, 1-12, 1-13 ifconfig settings, A-4 pin assignments 10/100BASE-Tx, C-7 AUI, C-6 European operating specifications, D-1 to D-15 Expansion LED, 3-3 expansion module Ethernet interface 10BASE-T, 1-9 AUI, 1-9 Ethernet LEDs, 3-5 interface options, 1-9, C-3...
  • Page 163 serial, 1-9 token ring STP, 1-9 UTP, 1-9 internal clocking, setting, A-3 address settings DSU/CSU, A-3 Ethernet, A-4 serial, A-3 token ring, A-5 connector settings DSU/CSU, A-3 Ethernet, A-4 ring speed, A-5 serial, A-3 token ring, A-5 default settings DSU/CSU, A-3 Ethernet, A-4 serial, A-3 token ring, A-5...
  • Page 164 1-30 specifications, C-2 switch, 3-11 Power (Pwr) LED, 3-2 powering on the ARN, 3-11 PPP protocol, Nortel Networks proprietary, B-12 PPP wide area protocol, worksheet for, B-14 Index-6 preparing for installation, 1-1 to 1-8 product support, xxiv publications...
  • Page 165 A-7 space requirements, C-1 specifications electrical, C-2 environmental, C-2 European, D-1 to D-15 physical, C-1 Standard protocol, Nortel Networks, A-3 startup options, displaying, A-8 cables, connecting, 1-14 interfaces connecting to, 1-14 pin assignments, C-8 support, Nortel Networks, xxiv...
  • Page 166 warm boot, 3-12 wire fault (WFLT) LED, 3-4, 3-5 wiring, 1-1 X.21 connections, C-9, D-3 Index-8 114200-E Rev 00...

Table of Contents
