Advanced series of full-function keypads that give complete control to wet fingers!
Aeware's® new series of keypads features a high profile with a large LCD display, menu-driven interface that let users easily control
all in.xm™ functions and programming directly from spa side, creating a true and unique user experience.
Description
Operation Mode
Menu title
Information Display
Time, temperature
& message digits
Progress bar icon
Status
icons
Main functions
This menu allows control of all
pumps, blower and spa light, as
well as the activation of the Eco-
nomy and Standby modes. Every
time a device is on, its animated
icon is displayed. All pump activi-
ty can be stopped at once by
activating the Standby mode.
Starting all accessories
• Press the Quick On/Off button
to start all accessories (pumps
and turbines) in high speed.
• Press the Quick On/Off button
again to stop all accessories
(pumps and turbines). There is
an integrated 120 minute timer.
(120 minute built-in timer)
Quick Reference Card
Please consult your spa user manual for complete info on the features of your spa system.
in.k600
Lock icon
Light
icons
Pump
icons
AM/PM
Service
(˚F/ ˚C)
icon
• Press Mode key to display
the mode Selection window.
Starting Pump 1
• Select Pump 1 to turn Pump 1 on.
• Select Pump 1 repeatdely to
control pump 1 speeds.
(20 minute built-in timer)
™
"Soft" Key 1,
2, 3, 4
"Left" Multifunction
Key goes back to
previous parameter
setting or increases
Water temperature setting
• Select Spa to view Spa menu.
• Press Plus/Minus key to select
• Press OK key or wait 5 seconds
Starting Pump 2*
Starting Pump 3*
• Select Pump 2 to turn Pump 2 on.
• Select Pump 3 to turn Pump 3 on.
• Select Pump 2 repeatdely to
• Select Pump 3 once more to
control pump 2 speeds.
(20 minute built-in timer)
(20 minute built-in timer)
"Plus" Key increases
"Ok" Key
parameter setting
"Minus" Key
decreases par-
ameter setting
parameter value
Starting Light
• Select Light key to turn light on.
water temperature setting.
• Select Light key repeatedly to
to confirm new setting.
The "Set Point" prompt
(120 minute built-in timer)
indicates the desired
temperature NOT the current
water temperature.
Next menu page
• Press Next key to display the
turn pump 3 off.
Goes to blower option
* option available depending upon factory settings
"Mode" Key
selects mode of
operation: Spa,
Audio, Options
"Right"
Multi-
function
Key
"Next" Key goes
to menu page
control light intensity. A final
selection turns light off.
next page in the spa menu.
