- Page 1 Swim spa solution ™ TechBook Make your swim spa installation more flexible!
-
Page 2: Table Of Contents
Swim Spa Solution™ table of contents Table of contents introduction .................. 3 in.xe™ error codes warnings ..................4 spa pack error codes summary Swim Spa™ overview - in.xe™ error codes ............27 - in.k600™ dimensions ........... 5 - Hr or Hr2 error condition ........... 30 - in.k100™... - Page 3 Swim Spa Solution™...
-
Page 4: Introduction
introduction Swim Spa Solution™ Swim Spa Solution ™ Make your swim spa installation more flexible! The control solution has been designed to be more flexible and support more outputs. The system includes two in.xe™ packs, one in.k600™ keypad with streamlined interface and an in.k100™ auxiliary keypad. -
Page 5: Warnings
warnings Swim Spa Solution™ WARNINGS: Before installing or connecting the unit, please read the following. * THIS PACK CONTAINS NO SERVICEABLE PARTS. CONTACT AN * FOR UNITS FOR USE IN OTHER THAN SINGLE-FAMILY AUTHORIZED SERVICE CENTER FOR SERVICE. DWELLINGS, A CLEARLY LABELED EMERGENCY SWITCH SHALL BE PROVIDED AS PART OF THE INSTALLATION. -
Page 6: In.k600 Dimensions
in.k600 dimensions Swim Spa Solution™ in.k600 dimensions: General specifi cations: Environmentals: Storage temperature: 85°C (185°F) to -30°C (-22°F) Operating temperature: 65°C (149°F) to -20°C (-4°F) Humidity: up to 95% condensing 4.230" Mechanical Specs: ( 107 mm) Weight: 0.4763 Kg (1.05 lbs) Dimensions (W x H x D): Front panel 8.726"... -
Page 7: In.k100™ Dimensions
in.k100 dimensions Swim Spa Solution™ in.k100 Dimensions: General specifi cations: Environmentals: Storage temperature: 70˚C (158˚F) to –30˚C (-22˚F) Operating temperature: 60˚C (140˚F) to –20˚C (-4˚F) " 11/16 Humidity: 100% condensing (42.9 mm) Mechanical Specs: " Weight: 0.41 kg (0.9 lbs) (130.2 mm) Dimensions (W x H x D): Front Panel:... -
Page 8: Keypad Installation & Connections
keypad installation & connections Swim Spa Solution™ Installation in.k600 Installation in.k100 Gasket with or without adhesive ∅ 7/16" 3.750" Optional wing nuts and spacers To install the in.k600 low profile, determine the mounting To install the in.k100 , determine the mounting location and cut location and cut out a rectangular shape opening of 7 .250"... -
Page 9: Plumbing
plumbing Swim Spa Solution™ Swim spa installation scheme flow spa filter flow water jet flow About 2' MASTER SLAVE in.xe™ in.xe™ * Requirers a minimum of 18 GPM... -
Page 10: Electrical Wiring North American Model In.xe
Swim Spa Solution™ electrical wiring North American model in.xe bonding lug For 240 VAC (4 wires) To install the wiring for the with a strain relief (1" NPT strain After making sure wire connec- Correct wiring of the electrical in.xe™ spa control, you'll need relief;... - Page 11 electrical wiring Swim Spa Solution™ Electrical wiring North American model in.xe - 1 breaker Master GFCI GREEN WHITE BLACK �� Main electrical box ��� �� �� �� �� �� Slave ��� ��� ��� ��� ��� GREEN ��� ����� WHITE ����� BLACK �����...
- Page 12 Swim Spa Solution™ electrical wiring Electrical wiring North American model in.xe - 2 breakers Main electrical box Main electrical box �� �� �� �� �� �� �� �� �� �� ��� ��� ��� ��� ��� ��� ��� ��� ��� ��� ���...
-
Page 13: Electrical Wiring European Model In.xe.ce
electrical wiring Swim Spa Solution™ Electrical wiring European model in.xe.ce - single phase Main electrical box RDC box Master �� �� �� �� �� �� �� GREEN ��� ��� ��� ��� ��� ��� ��� ������ BLUE ������ ����� ���� BROWN ������������... - Page 14 electrical wiring Swim Spa Solution™ Electrical wiring European model in.xe.ce - dual phases Main electrical box RDC box �� �� �� �� �� �� Master �� ������ ��� ��� ��� ��� ��� ��� ��� ������ ����� ���� GREEN ������������ BLUE BROWN ��...
- Page 15 electrical wiring Swim Spa Solution™ Electrical wiring European model in.xe.ce - three phases Main electrical box RDC box Master �� �� �� �� �� �� �� GREEN ��� ��� ��� ��� ��� ��� ��� BLUE ������ ������ BROWN ����� ����� BLACK �����...
-
Page 16: Power-Up & Breaker Setting
power-up & breaker setting Swim Spa Solution™ Make sure all accessories It's important to specify the The values displayed by the Use Up or Down button to are linked to the bonding current rating of the GFCI used system correspond to 0.8 of select the desired value. -
Page 17: Programming The In.xe
programming the in.xe™ Swim Spa Solution™ Programming the in.xe™ using the in.stik™ This feature is very useful on 4. The in.xe™ will then enter 7 . Use the Up/Down key to 1. Shut electrical power off. production lines to confi gure the low-level confi... - Page 18 Swim Spa Solution™ programming the in.xe™ Programming the in.xe™ using the keypad Although every in.xe™ spa is 1. Press and hold the Pump 1 3. Press the Prog. key to confi rm factory set, in certain cases key for 30 seconds. the selected confi...
-
Page 19: Low Level Configuration Selection Chart
connections Swim Spa Solution™ Low Level Configuration Selection Chart Heater Connection Config. # CP configuration Ozone configuration Filter Type Pump Diagram On during Filter cycle, with P1 Clean, P1L Page: 19 On during Filter cycle, with P1 Clean, P1L Page: 20 On during Filter cycle, with P1 Clean, P1L Page: 19... -
Page 20: Connection 4 Pumps System
connections Swim Spa Solution™ Confi guration 1 & 3 / 4 Pump System Pump 1 Pump 2 Ozonator Pump 3 Pump 4 in.power in.chant in.k100 in.k600 in.p3 CoolRays Master Slave Cable in.tr LV-LV-8KCO (9920-401316) CoolRays... -
Page 21: Connection 4 Pumps And Blower System
connections Swim Spa Solution™ Confi guration 2 & 4 / 4 Pump and Blower System Pump 1 Pump 2 Ozonator Pump 3 Pump 4 Blower in.power in.chant in.k100 in.k600 in.p3 CoolRays™ Master Slave Cable in.tr LV-LV-8KCO (9920-401316) CoolRays™... -
Page 22: Connection 5 Pumps System
connections Swim Spa Solution™ Confi guration 5 / 5 Pump System Pump 1 Pump 2 Ozonator Pump 3 Pump 4 Pump 5 Cable in.split (9920-401248) in.power in.chant in.k100 in.k600 in.p3 CoolRays™ Master Slave Cable in.tr LV-LV-8KCO (9920-401316) CoolRays™... -
Page 23: Connection 5 Pumps And Blower System
connections Swim Spa Solution™ Confi guration 6 / 5 Pump and Blower system Pump 1 Pump 2 Ozonator Pump 3 Pump 4 Pump 5 Cable in.split (9920-401248) Blower in.power in.chant in.k100 in.k600 in.p3 CoolRays™ Master Slave Cable in.tr LV-LV-8KCO (9920-401316) CoolRays™... -
Page 24: Connection 3 Pumps System
connections Swim Spa Solution™ Confi guration 7 / 3 Pump System Pump 1 Pump 2 Ozonator Pump 3 in.power in.chant in.k100 in.k600 in.p3 CoolRays™ Master Slave Cable in.tr LV-LV-8KCO (9920-401316) CoolRays™... - Page 25 programming the in.xe™ Swim Spa Solution™ in.xe™ programming fi eld options Output 1 Output 2 Output 3 Output 4 In the event where none of the pre-determined low level program confi gurations built into the in.xe™ system suits your spa equipment assembly, it's possible to customize the in.xe™...
- Page 26 programming the in.xe™ Swim Spa Solution™ Parameter Display Options Description CP Standard = 0 CP usage Usage of the circulation pump CP Always On = 1 Ozone with filtration = 0 Ozone usage Usage of the ozone generator Ozone Always On = 1 Circulation pump = 0 Ozone Pump Pump associated with the ozone generator...
- Page 27 programming the in.xe™ Swim Spa Solution™ Parameter Display Options Description Output 2 current 1 to 15 amperes Current draw of the accessory connected to the relay of Output 2A Output 3 current 1 to 15 amperes Current draw of the accessory connected to the relay of Output 3A Output 4 current 1 to 15 amperes Current draw of the accessory connected to the relay of Output 4A...
-
Page 28: In.xe™ Error Codes
Swim Spa Solution™ spa pack error codes summary in.xe error codes Hr: means the error comes from the MASTER pack. Hr2: means the error comes from the SLAVE pack. Error codes indicate a failure An internal hardware error has been detected in in.xe™. condition or a problem which needs to be corrected to ensure proper functioning of... - Page 29 spa pack error codes summary Swim Spa Solution™ in.xe™ error codes Prr: means the error comes from the MASTER pack. Pr2: means the error comes from the SLAVE pack. The Prr error message indicates a problem with regulation probe. The system is constantly verifying if temperature probe reading is within normal limits.
- Page 30 Swim Spa Solution™ spa pack error codes summary in.xe error codes ™ The pack on which the main keypad is connected is a SLAVE. LLXX Unable to select the desired low level (when you confirm it goes back into the low level menu). LLEr The selected configuration is not a swim spa configuration and a SLAVE pack has been detected.
-
Page 31: Hr Or Hr2 Error Condition
Hr or Hr2 error condition flow chart Swim Spa Solution™ An internal hardware error has been detected (MASTER pack). or or An internal hardware error has been detected (SLAVE pack). Flow chart Restart the Replace Spa Pack Spa Pack, and start if problem &... -
Page 32: Hl Or Hl2 Error Condition
HL or HL2 error condition flow chart Swim Spa Solution™ The system has shut down because the temperature at the heater has reached 119°F (48°C) (MASTER pack). The system has shut down because the temperature at the heater has reached 119°F (48°C) (SLAVE pack). Remove spa cover Wait until spa cools (even during the night) -
Page 33: Flo Or Fl2 Error Condition
FLO or FL2 error condition flow chart Swim Spa Solution™ The system did not detect any water flow while the primary pump was running (MASTER pack). The system did not detect any water flow while the primary pump was running (SLAVE pack). Follow Troubleshooting Flow Chart below to identify the problem: Make sure that the low-level programming has been properly set, with or without circulation pump (depending on your system configuration). -
Page 34: Oh Or Oh2 Error Condition
Swim Spa Solution™ OH or OH2 error condition flow chart Water temp. in the spa has reached 108°F (MASTER pack). Water temp. in the spa has reached 108°F (SLAVE pack). Remove spa cover Replace Add cold Flow chart and let Spa Pack, water and system cool... -
Page 35: Prr Or Pr2 Error Condition
Prr or Pr2 error condition flow chart Swim Spa Solution™ Regulation probe issue (MASTER pack). Regulation probe issue (SLAVE pack). Flow chart Verify if Replace Replace regulation heater if Spa Pack, probe is problem if problem properly persist. persist. connected. -
Page 36: Aoh Or Ao2 Error Condition
Swim Spa Solution™ AOH or AO2 error condition flow chart Temperature inside the spa equipment compartment is too high (MASTER pack). Temperature inside the spa equipment compartment is too high (SLAVE pack). Flow chart Remove spa skirt and let Replace system cool Spa Pack, down, until... -
Page 37: Upl Error Condition
UPL error conditions Swim Spa Solution™ No low level confi guration software in system! Note: this line is dedicated • New low level confi guration to assist authorized service software needs to be technicians and dealers only. downloaded into the in.xe™ spa system, without it the system will not be operable. -
Page 38: Er1 Error Condition
Swim Spa Solution™ Er1 error condition flow chart The communication between the MASTER and the SLAVE pack doesn't work. Flow chart Replace communication cable Verify the connection between the Run a visual 2 packs. Ensure inspection of that the in.link™ Try straightening the cable. -
Page 39: Sla Error Condition
SLA error condition flow chart Swim Spa Solution™ The main keypad is connected on the pack with a SLAVE configuration. Flow chart The main Change the keypad is connection connected of the main on the pack keypad to the with a SLAVE MASTER pack. -
Page 40: Llxx Error Condition
Swim Spa Solution™ LLXX error condition flow chart Unable to select the desired low level (when you confirm it goes back into the low level menu). Flow chart Unable to select the desired low Replace level (when SLAVE pack. you confirm it goes back in the menu). -
Page 41: Ller
LLEr error condition flow chart Swim Spa Solution™ The selected configuration is not a swim spa configuration and a SLAVE pack has been detected. Remove the SLAVE pack. Flow chart Is it really the configuration you want? Select another configuration. -
Page 42: Specifications
Swim Spa Solution™ specifications Electrical specifications UL CSA: Voltage Input: 120/240 VAC Current Input: 2 x 48 A or 1 x 60 A Master in.xe™ Slave in.xe™ Output Voltage Current Output Voltage Current Output 1A Pump 1 (2 speed) High 120/240V 20 FLA/70 LRA Output 1A Pump3 (1 speed) - Page 43 specifications Swim Spa Solution™ Electrical specifications TUV: Voltage Input: 230/400 VAC 3 phase or single Current Input: 3 x 20 A max or 1 x 60 A Master in.xe ™ Slave in.xe™ Output Voltage Current Output Voltage Current Output 1A Pump 1 (2 speed) 230V 15 FLA/60 LRA Output 1A Pump 3 (1 speed)
- Page 44 Swim Spa Solution™ specifications Environmental: • Operating temperature: 0 °C (32 °F) to 50 °C (122 °F) • Storage temperature: -20°C (-4°F) to 85°C (185°F) • Humidity: up to 85% RH, non condensing • Water ingress protection: IPx5 Mechanical: Weight: 4.76 kg (10.5 lbs) Dimensions (W x H x D): Chassis:...
- Page 45 Advanced electronics! Water resistance! Gecko Alliance 9919-101142 450 des Canetons, Quebec City (QC) G2E 5W6 Canada, 1.800.78.GECKO Rev. 04/11 9225 Stellar Court, Corona, CA 92883 USA , 951.667 .2000 © 2010 Groupe Gecko Alliance Inc. www.geckoalliance.com TM trade-marks of/marques de commerce de Groupe Gecko Alliance Inc.
