28" Rotary Brush Head Assembly Drawing And Parts List - Nilfisk-ALTO SCRUBTEC R 571 Operator's Manual And Parts List

571 Rotary Brush Head Assembly Drawing and Parts List 3/08
1, 1A, 1B, 1C
28
29
27
26
25
24
22
23
21
Ref Part No. Description
1 40904B Motor, Dual Gear Box
1A 915102 Key
1B 40968A Carbon Brush/Spring Set (4 of ea.)
1C 41048A Gearbox Asm.
2 962244 Bolt, 3/8 - 16 x 3/4 Hex
3 170883 Washer, Lock 3/8
4 980645 Washer, 3/8 Flat
5 61722A Plate, Auto Side Squeegee
61497A Plate, Manual Side Squeegee
6 85613A Screw, 8 - 32 x 7/8 PH SS
7 55451A Keeper, Latch
8 61570A Spacer, Keeper
9 962803 Screw, 5/16-18 x 1 1/2 FH
10 53838A Wheel, Guide 4"
11 920108 Nut, 8 - 32 ESNA SS
12 55721A Latch, Brush Housing
13 30535A Housing, 28" Brush Right Main
14 962030 Screw, 8 - 32 x 3/8" FHCS
Page -52-
Nilfisk ALTO
SCRUBTEC R 571 SCRUBTEC R 571 SCRUBTEC R 571 SCRUBTEC R 571 SCRUBTEC R 571
Drawing #10697A
2
3
5
4
20
19
Ref
Qty
16
1
17
2
18
1
19
2
20
12
21
2
22
2
23
1
24
1
25
4
26
2
27
2
28
1
29
1
30
4
NI
2
NI
1
4
NI = Not illustrated
NOTE:
last publication of this manual.
Nilfisk ALTO
6
7
8
9
10
30
16
2
17
18
.
Part No. Description
980638 Washer, 3/8 Lock
59856A Washer, Rubber
61658A Collar, Brush Driver
962714 Screw, Gimbal Mount
34400B Gimbal, Motor
962989 Screw, 1/4 - 20 x 1 1/2 PH
34705A Hose, Solution
170915 Screw, 1/4 - 20 x 3/4 Hex HD
782002 Clamp, Manifold
38014A Splitter, Solution
61546A Frame, 28" Brush Motor
30536A Housing, 28" Brush Left Main
81104A Nut, 1/4 Nylock
77091A Label, Moving Parts
81109A Nut, 8-32 ESNA SS
30536A Housing, 28" Left Brush
30535A Housing, 28" Right Brush
indicates a change has been made since the
