1-Dual Purpose 125 7-09-2004
PNEUMATICO POSTERIORE
Marca e tipo (wre) ..................... Pirelli MT 83
Marca e tipo (sms) DUNLOP D207-TL (66W)
Dimensioni (wre) ......................... 120/90/18"
Dimensioni (sms) ........................ 150/60-17"
Pressione di gonfiaggio a freddo Kg/cm
Pressione di gonfiaggio
a freddo con passeggero .......... Kg/cm
DIMENSIONI, PESO, CAPACITÀ
Interasse................................. (wre) mm 1475
................................................(sms) mm 1470
Lunghezza totale................................(wre) mm 2250
.............................................................(sms) mm 2210
Larghezza massima ..................(wre) mm 825
..............................................................(sms) mm 825
Altezza massima ............................(wre) mm 1245
......................................................(sms) mm 1175
Altezza sella .............................(wre) mm 935
..................................................(sms) mm 870
Altezza minima da terra ...................(wre) mm 330
........................................................(sms) mm 265
Peso in ordine di marcia, senza carburante ...
................................................(wre) Kg 111,1
................................................(sms) Kg 113,5
Capacità serbatoio carburante.............. 10,2
(Compresa una riserva di l. 2,2)
Capacità serbatoio olio ........................... 0,8
Olio nel basamento ................................ 0,65
Liquido circuito di raffreddamento ............. 1
Olio in ogni stelo forcella .....................520 cc
24
10:24 Pagina 24
REAR TIRE
Make and type (wre) ................. Pirelli MT 83
Make and type (sms) DUNLOP D207-TL (66W)
Tire Size (wre) ..............................120/90/18"
Tire Size (sms) ............................150/60-17"
2
1,5 Cold tire pressure ........................Kg/cm
psi 21,3
Cold tire pressure
2
1,8 with passenger . ..........................Kg/cm
psi 25,5
DIMENSIONS, WEIGHT, CAPACITIES
Wheelbase.................................58.07 in. (wre)
.................................................57.87 in. (sms)
Overall length.....................................88.58 in. (wre)
...................................................................87 in. (sms)
Overall width ............................32.48 in. (wre)
..............................................................32.48 in. ((sms
Overall height ................................49.01 in. ((wre)
......................................................46.26 in. ((sms)
Saddle height .........................36.81 in. ((wre)
.................................................34.25 in. ((sms)
Minimum ground clearance 12.8 in. ..........13 in. ((wre)
.............................................................10.43(sms)
Kerb weight, without fuel ........244.9 ib. ( (wre)
................................................250.2 ib. ((sms)
Fuel tank capacity . ................2.24 Imp. Gall.
(1.9 Imp. Q.l. reserve included)
Oil tank capacity . .......................0.7 Imp. Qt.
Crankcase oil ............................0.57 Imp. Qt.
Coolant . ...................................0.88 Imp. Qt.
Oil in each fork rod.........................31.7 cu.in.
PNEU ARRIERE
Marque et type (wre) ..................Pirelli MT 83
Marque et type (sms) DUNLOP D207-TL (66W)
Dimensions (wre) .........................120/90/18"
Dimensions (sms) .......................150/60-17"
2
1.5 Pression de gonflage à froid ........Kg/cm
psi 21.3
Pression de gonflage
2
1.8 à froid avec passager ...................Kg/cm
psi 25.5
DIMENSIONS, POIDS, CAPACITE
Empattement.......................... (wre) mm 1475
................................................(sms) mm 1470
Longueur totale ................................(wre) mm 2250
.............................................................(sms) mm 2210
Largeur maxi .............................(wre) mm 825
..............................................................(sms) mm 825
Hauteur maxi ................................(wre) mm 1245
......................................................(sms) mm 1175
Hauteur selle ............................(wre) mm 935
..................................................(sms) mm 870
Garde au sol mini..........................(wre) mm 330
........................................................(sms) mm 265
Poids en orde de marche,sans carburant ......
................................................(wre) Kg 111,1
................................................(sms) Kg 113,5
Contenance réservoir d'essence .......... 10,2
(Comprise una réserve de l. 2,2)
Capacité réservoir d'huile ...................... . 0,8
Huile carter ........................................... 0,65
Liquide circuit de refroidissement . ........... . 1
Huile dans chaque fourreau.................520 cc
2
1,5
psi 21,3
2
1,8
psi 25,5
