- Page 1 DC-B Series Installation Manual DC-B1001 / DC-B1101 DC-B1103 / DC-B1203 DC-B1303 Powered by...
-
Page 2: Safety Symbols
Before reading this manual This is a basic installation manual for use of an IDIS netework camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this manual carefully before use and heed to the warnings and precautions contained herein while using the product. -
Page 3: Safety Precautions
Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1. -
Page 4: Fcc Compliance Statement
IDIS Co., Ltd. reserves all rights concerning this manual. Use or duplication of this manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this manual are subject to change without prior notice for reasons such as functionality enhancements. -
Page 5: Table Of Contents
Table of Contents Part 1 – Introduction ......... 6 Product Features . -
Page 6: Part 1 - Introduction
In addition, the • Remote monitoring via web browser or remote embedded web server (IDIS Web) lets you remotely view software live video or scan recorded video using a web browser. Alternatively, you can use the provided remote access •... - Page 7 • Redundant firmware and auto recovery features for improved system stability Remote monitoring and recording via multistreaming are available using the IDIS Solution Suite Compact • Network-based integrated management of multiple program. For more information on using IDIS Solution network cameras Suite Compact, refer to its operation manual.
-
Page 8: Accessories
Part 1 – Introduction Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. External appearances and colors of the accessories may vary depending on the model. Network Camera C-Mount Ring Installation Parts Protective Cover (attaches to camera) Ferrite Core Open Source Guide... -
Page 9: Overview
Part 1 – Introduction Overview Side Product color and design may vary depending on the model. Front Protective Cover C-Mount Ring Back Focus Adjustment Ring Mount Bracket SD Card Slot DC-B1103 / DC-B1203 / DC-B1303 only DC-B1103 / DC-B1203 / Built-in Microphone DC-B1303 only •... -
Page 10: Top
Part 1 – Introduction • Mount Bracket This bracket can be installed on either top or bottom of the camera. Use 1/4–20 UNC (20-thread), 2.5mm +/- 0.2mm (ISO standard) or 0.197 (ASA standard) screws to attach the mount. • SD Card Slot DC-B1103 / DC-B1203 / DC-B1303 only Pull on the connection cover and then insert a GND 3... - Page 11 Release the button and then gently pull on the wire to on or using the IDIS Discovery program from a remote ensure a secure connection. To disconnect the cable, location. A factory reset will reboot the system. For more press down on the button again and pull the cable out.
-
Page 12: Back
Part 1 – Introduction Back I/O Connector DC-B1103 / DC-B1203 / DC-B1303 only VIDEO DC 12V FGND NETWORK GND 3 Grounding Auto Iris Lens Connector Audio Out Audio Video Out Grounding Power Audio In Network Port Grounding Alarm Out (Active Low - Network LED Alarm Open Collector Output) - Page 13 Powered on images from a remote computer over the network. For more information on network connection setup, Not connected to Network LED refer to the IDIS Discovery operation manual. network Power LED/ Flashing Software upgrade • Network LED...
-
Page 14: Installation
Part 1 – Introduction Installation DC Type Auto Iris Lens The lens must be purchased separately. If you'd like to purchase a lens, contact your camera retailer. This Solder on the lens connection line to the connector camera supports manual iris lenses and DC type auto iris socket, if necessary. -
Page 15: Cs-Mount Lens
Part 1 – Introduction CS-Mount Lens Dimensions Front 75.62 mm Remove the protective cover from the camera. Turn the lens in clockwise direction and mount it on the camera. C-Mount Lens Side 129.32 mm 125.82 mm Remove the protective cover from the camera. Turn the mount ring in clockwise direction and mount the ring on to the camera. -
Page 16: Part 2 - Camera Connection
Part 2 - Camera Connection Use the camera by connecting to DirectIP™ NVR or non DirectIP™ NVR, VMS such as IDIS Solution Suite Compact. With DirectIP™ NVR-based Layout Audio In Audio Out Power Alarm Out Sensor In Network Camera Monitor Out... -
Page 17: With Non Directip™ Nvr-Based Layout
Alarm In/Out, Audio In/Out and SD card recording are supported by models only. The contents in the camera operation manual are only for users using the camera with non DirectIP™ NVR connection or VMS connection such as IDIS Solution Suite Compact. -
Page 18: Part 3 - Appendix
ID and password as a safety precaution. camera. Unable to launch IDIS Web. If the IDIS Web login screen is not loading, check which version of Microsoft Internet Explorer you are using. IDIS Web may not launch properly on versions 8.0 or below. -
Page 19: Specifications
Part 3 - Appendix Specifications These product specifications may change without prior notice. Camera DC-B1001 / DC-B1101 DC-B1103 / DC-B1203 / DC-B1303 Image Sensor 1/4” CMOS DC-B1103 / DC-B1203: 1/2.7” CMOS DC-B1303: 1/3” CMOS Lens (optional) Manual iris, DC type auto iris (megapixel... - Page 20 DC-B1303: 352x240, 704x480, 1280x720, 1920x1080, 2304x1296 Bitrate Control DC-B1001: H.264 – CBR / VBR (up to 4 Mbps) DC-B1103: H.264 – CBR / VBR (up to 8 Mbps) DC-B1101: H.264 – CBR / VBR (up to 8 Mbps) DC-B1203 / DC-B1303: H.264 – CBR / VBR...
- Page 21 RJ-45 RS485 Serial Port Terminal Block Use these ports for previewing video and not monitoring video. General DC-B1001 / DC-B1101 / DC-B1103 / DC-B1203 / DC-B1303 Exterior Dimensions 75.62mm x 61.02mm x 129.32mm (W x H x D) Packaging Dimensions...
- Page 22 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
