  • Page 1 Network Camera Operation Manual DC-B1803 Powered by...

  • Page 2: Safety Symbols

    Before reading this manual This is a basic operation manual for use of an IDIS network camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product.

  • Page 3: Safety Precautions

    Before reading this manual Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1.

  • Page 4: Fcc Compliance Statement

    IDIS Co., Ltd. reserves all rights concerning this manual. Use or duplication of this manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this manual are subject to change without prior notice for reasons such as functionality enhancements.

  • Page 5: Table Of Contents

    Table of Contents Part 1 - Remote Setup ........7 Camera Protocol.
  • Page 6 Part 2 - IDIS Web ........

  • Page 7: Part 1 - Remote Setup

    - The DirectIP™ NVR also allows you to control all camera settings directly from the NVR, without the Launch the IDIS Discovery program and from the list, need for a computer. select a camera whose protocol you wish to change.

  • Page 8: Remote Setup

    Part 1 - Remote Setup Remote Setup Launch the IDIS Discovery program and then from the main screen, select a network camera whose settings you wish to change. Click on the Setup icon. Select Remote Setup from the Setup menu to load the Remote Setup screen.

  • Page 9: Quick Setup

    There may be some more settings that cannot be changed, too. If you want to change those settings, connect to the camera by using the IDIS Discovery program. Change the camera’s system information, add users/...

  • Page 10: Date/Time

    Part 1 - Remote Setup • Setup Date/Time - Load Default Setup: Restores all settings other than Date/Time to their factory defaults. Select Include Network Setup to load default network settings as well. For more information on network setup, refer to the Network on page 12. - Import Setup: Open a setup file and apply its settings to the camera.

  • Page 11: User/Group

    Part 1 - Remote Setup User/Group • User/Group settings can only be configured by users belonging to the Administrator group. • There is no default password for the Administrator group's admin user. • Standard groups (Administrator, Operator, and User) cannot be edited or deleted. Authorities assigned here apply identically to ONVIF protocol user groups.

  • Page 12: Network

    Part 1 - Remote Setup Network • Type: Select the type of network you are using. If this option has been changed, click Save to apply the current settings, and then restart Remote Setup. If you do not restart Remote Setup, the changes afterwards will not be applied.

  • Page 13: Fen

    IDIS Web program. The FEN Server operated by IDIS is a service to its clients and may go offline without notice for server update purposes or due to an unexpected failure.

  • Page 14: Port/Qos

    Web ports are enabled by default and cannot be disabled. By enabling IDIS Web and RTSP ports, you will be able to use the IDIS Web program or a media player that supports RTSP (Real-Time Streaming Protocol) service to connect to the camera. If this Click Apply to use the recommended port numbers.

  • Page 15: Bandwidth Control

    – Via Mobile Device: Launch the web browser and then enter http://IP Address:IDIS Web Port Number/ (If Use HTTPS has been enabled, enter https instead of http). Camera's IDIS Web port number and RTSP port number must be configured correctly in order to establish a connection this way.

  • Page 16: Security

    Part 1 - Remote Setup Security • SSL: Select this option to enable SSL (Secure Sockets Layer). Enabling this option applies SSL protocol protection on data transmitted out. However, programs and systems that do not support SSL will not be able to connect to the camera. If this option has been changed, click Save to apply the current settings, and then restart Remote Setup.

  • Page 17: Ieee 802.1X

    Part 1 - Remote Setup Video IEEE 802.1X Select the IEEE 802.1X option to enable IEEE 802.1X network connection authentication. Configure Camera, Streaming, Webcasting, MAT, and Privacy Masking options. • Certificates: Upload a certificate or a private key. You may be prompted to enter a password for the private key.

  • Page 18: Camera

    Part 1 - Remote Setup Camera • Backlight Compensation: Enable/disable the Backlight Compensation feature. - OFF: Disables the BLC function. - ON: When images are too bright overall due to Image Sensor backlight, objects are exposed brighter under backlight circumstances. Configure Image Sensor settings.
  • Page 19 Part 1 - Remote Setup White Balance Exposure Configure White Balance settings. Configure Exposure settings. • IRIS: Select the lens IRIS type. • Preset: Use preconfigured white balance settings. - Off: Select this if a manual IRIS lens is mounted on - Auto: Allow the system to adjust the white the camera.
  • Page 20 Part 1 - Remote Setup • Local Exposure: Activate Local Exposure. Use Local • Shutter Speed Control: Adjust Shutter Speed. This Exposure on images that appear too dark due to option is available only when Anti-Flicker and Slow Shutter are both set to Off. backlighting conditions and on images containing over-exposed sections.
  • Page 21 Part 1 - Remote Setup • IR Cut Filter: IR Cut Filter blocks out the infrared Day & Night spectrum. You can ensure clear images at all times by Configure Day & Night settings. blocking out the infrared spectrum in high-lighting conditions and allowing the infrared spectrum to pass through in low-lighting conditions.
  • Page 22 Part 1 - Remote Setup Pan/Tilt Driver Miscellaneous Configure Pan/Tilt Driver settings. Configure Miscellaneous settings. • Product/ID:Specify the mounted pan/tilt driver’s • Video Output: Select a video output signal format. model and then set up an ID. Click Port and enter the pan/tilt driver’s port speed, data bit, stop bit, and parity values as per the driver manufacturer’s instructions.

  • Page 23: Streaming

    Part 1 - Remote Setup Streaming • Resolution: Choose a resolution setting for video streaming. The resolution varies depending on the camera model. The current stream resolution cannot be higher than the higher stream resolution. • Quality: Choose a quality setting for video streaming. •...

  • Page 24: Webcasting

    Part 1 - Remote Setup Select On and then specify the streaming area’s Webcasting resolution. Use the webcasting service to view live images from the camera on a web site. • HTML Code: Copy and paste the html code shown on the screen within the code of the web page you want the video to be displayed.

  • Page 25: Mat

    Part 1 - Remote Setup • Frame Rate: Designate the frame rate to be used between the end of the Inactivity Period and the next motion detection. When the slow shutter mode is Select the MAT option to use the MAT (Motion Adaptive enabled under Video >...

  • Page 26: Privacy Masking

    Part 1 - Remote Setup Audio Privacy Masking Select Privacy Masking to set up a privacy mask over Configure audio in/out settings. a specific area. The section on which a privacy mask is applied will appear as black when monitoring video. •...

  • Page 27: Audio

    Part 1 - Remote Setup Event Action In/Out Designate event detection alert actions. • Audio Codec: Select an audio codec. • Input: Select an option and then an audio input source (microphone or line-in). Adjust the volume. • Output: Select an option and then adjust the volume. Cameras do not feature built-in audio amplifier units and therefore require the user to purchase a speaker system with a built-in amplifier separately.

  • Page 28: Alarm Out

    Part 1 - Remote Setup Alarm out Email Select Email to send out emails. Select Alarm Out to enable alarm out. • SMTP Server/Port: Enter the SMTP server’s IP address • Dwell Time: Designate the alarm out duration. When (or domain name) and port number you received an event occurs, alarm out will be generated for the from the network administrator.

  • Page 29: Remote Callback

    Select Remote Callback to send callback messages to a Select Audio Alarm to generate audio. remote system. • Not supported from the IDIS Web program. • The camera must be registered to the remote system in order to use the Remote Callback feature.

  • Page 30: Ftp Upload

    Part 1 - Remote Setup FTP Upload Select FTP Upload to upload .jpg image of the event detected to an FTP server. - FTP Server: Enter the FTP server’s IP address (or domain name). - Upload Path: Designate the file upload path. - Port: Enter the FTP server’s port number.

  • Page 31: Record

    Part 1 - Remote Setup - Resolution/Quality: Choose the resolution and Record quality of the images to upload to the FTP server. Range of resolution settings you can use here can vary depe nding on the resolution setting applied Select Record to record video on the SD card. First, under Video >...
  • Page 32 • Recordings saved on the SD card can be searched resolution, quality, and frame rate settings can and played back from the IDIS Solution Suite cause the recording to exceed the 60MB limit and Compact program or remotely from the remote stop before the end of the specified recording program.

  • Page 33: Event

    Alarm In • Not supported from the IDIS Web program. • The camera must be registered to the remote system in order to use the Remote Callback Select Alarm In to enable alarm in event.

  • Page 34: Motion Detection

    • Not supported from the IDIS Web program. • The camera must be registered to the remote system in order to use the Remote Callback •...

  • Page 35: Trip-Zone

    • Not supported from the IDIS Web program. • The camera must be registered to the remote system in order to use the Remote Callback •...

  • Page 36: Audio Detection

    • Not supported from the IDIS Web program. • The camera must be registered to the remote system in order to use the Remote Callback feature.

  • Page 37: Tampering

    • Not supported from the IDIS Web program. • The camera must be registered to the remote system in order to use the Remote Callback feature.

  • Page 38: System Event

    Action must be configured correctly in order to send out emails and messages. • System Alive: Select to check the system status and • Remote Callback is not supported on IDIS Web. then set up a schedule. • The camera must be registered to the remote - Send Email: Select to send out an email when the system in order to use the Remote Callback feature.

  • Page 39: Part 2 - Idis Web

    – Tools → Internet Options → Advanced → Security → Use TLS 1.0 (select) • If connecting by entering an IP address and a port number, you can connect by entering just the IP address if IDIS Web connection port number has been set to 80 (443 when entering https).
  • Page 40 Run as administrator option. Otherwise, certain IDIS Web functions might not be available. • When running IDIS Web, the bottom section of the screen may get cut off if the address bar or the status bar is shown.

  • Page 41: Web Live Mode

    2013-05-29 16:25:22 2013-05-29 16:25:22 Press to terminate IDIS Web. Place the mouse pointer on the logo to check IDIS Web's version. TYPE 1 Displays the current time. Click to view the video in full screen. Press the ESC key on the keyboard to return to the previous screen.
  • Page 42 Part 2 - IDIS Web Shows login information. Indicates the camera's number. Used to control a PTZ camera at a remote location. Used to adjust live video quality. Click to control the alarm out device connected to the camera. Event status window at the bottom of the screen displays a list of events detected at remote locales.

  • Page 43: Web Search Mode

    113.49 NC-D320-IP & Press to terminate IDIS Web. Place the mouse pointer on the logo to check IDIS Web's version. TYPE 1 Displays time information of the video recording from the remote locale. Click to view the video in full screen. Press the ESC key on the keyboard to return to the previous screen.
  • Page 44 Part 2 - IDIS Web Click to switch over to Web Live mode. TYPE 1 Shows login information. Indicates the camera's number. Zoom in or out on the video. Adjust image brightness. Apply image filters (Sharpen, Blur, Equalizer, Interpolation, and Revert) to the images.
  • Page 45 Part 2 - IDIS Web Right-click on the screen to display the pop-up menu. • Change Camera Title: Used to change the camera's name. Renaming the camera in Web Search mode does not affect the camera's name on the remote system. If no name is entered for the camera, the name used at the remote locale is shown on the screen.

  • Page 46: Part 3 - Appendix

    Part 3 - Appendix Setup Menu Tree (Remote Setup) Remote Setup Quick Setup System Network Video Audio System General Date/Time User/Group Network IP Address Port/QoS Bandwidth Control Security IEEE 802.1X Video Camera Streaming Webcasting Privacy Masking Audio In/Out Event Action Alarm Out Email Remote Callback...

  • Page 47: Index

    Index ONVIF Protocol Bitrate Control Product/ID Camera Name Quality Compression Remote Port Date/Time Resolution DSCP RTSP Port FEN Name FEN Server Frame Rate Time Sync IDIS Web port IPFiltering Use FEN Use HTTPS User/Group Use UPnP Network Bandwidth Limit V1.1...
