Garudan GP-510-143 User Manual And Spare Parts List

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User manual and
Spare Parts List
GP-510- 143
GP-510- 143i
ANITA B, s.r.o.
Průmyslová 2453/7
680 01 Boskovice
Czech Republic
tel: +420 516454774, 516453496
fax: +420 516452751
e-mail:
info@anita.cz

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP-510-143 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Garudan GP-510-143

Summary of Contents for Garudan GP-510-143

  • Page 1 User manual and Spare Parts List GP-510- 143 GP-510- 143i ANITA B, s.r.o. Průmyslová 2453/7 680 01 Boskovice Czech Republic tel: +420 516454774, 516453496 fax: +420 516452751 e-mail: info@anita.cz...
  • Page 3 GP-510-143 1 Safety Measures Do not put the machine into operation until an appropriate preparation is carried out by a specialist or an authorised person, and until you get acquainted with safety measures. 1. Any sewing machine may be operated only by a properly trained operator.
  • Page 4 GP-510-143 Putting the machine into operation Following instructions must be observed to avoid risk of failures or damage to the machine: - clean the machine of preserving agents - drop 1-2 drops of oil into looper - remove the front cover and oil the ends of needle bar connecting-rod and of the cross-head slide of thread take-up.
  • Page 5 GP-510-143 Threading the Upper Thread Caution! Switch off the main switch and remove your feet from the pedals on the machine support before threading so that the machine may not be started by unintended treading on the pedal. When threading the thread from bobbin stand into needle follow figure 1 for single needle machine.
  • Page 6 GP-510-143 Inserting needles Caution ! Switch off the main switch and remove your feet from the pedals on the machine support before replacing needles so that the machine may not be started by unintended treading on the pedal. Fig.3 Having chosen the right thickness (size) of needle whose system coresponds to the prescribed kind (usually 134 LR) loosen screw (A,fig.3) on needle bar and insert needle (B) as far as it will...
  • Page 7 GP-510-143 Caution! Do not start the machine until you put the hook covers in working (protecting) position. Switch off the main switch and remove your feet from the pedals on the machine support before replacing the hook bobbin so that the machine may not be started by unintended treading on the pedal.
  • Page 8 GP-510-143 7 Adjusting Differential Feed Ratio (only for machines with driven presser foot) To ensure sewing of fabric layers without their displacement in the course of feeding it is possible to adjust different lengths of feeding driven by press-wheel and feeding by rotary feed dog.
  • Page 9 GP-510-143 The sewing machines are equipped with a safety clutch on the lower shaft (A) fig. 8 that allows the operator to turn the driving part of lower shaft (A) when the loopers or feed dogs are locked. The clutch consists of segment (B) engaging with.groove (C) in the disk on lower shaft by the pressure of two springs.
  • Page 10 GP-510-143 10 Switching Off and Switching On of the Main Switch The Main Switch are marked 0 and I or they have grey/green and red buttons. Pushing position of the button marked "0" (red) means: off, pushing position of the button marked "I"...
  • Page 11 GP-510-143 12 Bobbin Winder – Standard Built in Fig. 9 The thread passes from the bobbin stand through thread guide on the winder bracket (1) and between tension disks (2) and then following the direction of arrow (S) to the empty bobbin.
  • Page 12 GP-510-143 Instructions for adjustment 13 Basic condition a) Clearance between the throat plate and the bobbin case stopper. Fig.10 Condition : Clearance between the top end of the bobbin case resting groove on the throat plate and the top face of the bobbin case stopper of the hook : 1,4 mm .

  • Page 13: Table Of Contents

    TABLE OF CONTENTS anita-b GP-510-143 Spare Parts Lists Frame and Cover Parts, Thread Tension Mechanism ……………..14,15 Upper Shaft Mechanism………………………….………………..16,17 Lower Shaft and Clutch Mechanism……………………………….18,19 Timing Belt DrivingMechanism……………………………………20,21 Lower Feed Mechanism…………………………………………….22,23 Feed Shaft Mechanism……………………………………………...24,25 Stitch Adjuster Mechanism……………………….………………...26,27 Needle Bar and Presser Foot Mechanism…………………………...28,29 Thread Take-Up Lever Mechanism…………………………………30,31...

  • Page 14: A1 Frame And Cover Parts, Thread Tension Mechanism

    Frame and Cover Parts anita-b GP-510-143...
  • Page 15 Frame and Cover Parts anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part GP/ 5-1 A1- 1 Face Plate A1- 2 GP/ 108246 Screw (M5x0,8x25) GP/ 108234 A1- 3 Screw (M5x0,8x35) GP/ 168061 A1- 4 Thread Take-up Cover GP/ 210210...

  • Page 16: Upper Shaft Mechanism

    Upper Shaft Mechanism anita-b GP-510-143...
  • Page 17 Upper Shaft Mechanism anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part GP/ 119702-2 B- 1 Crank Cam GP/ 130224 B- 2 Screw (M5x0,8x12) GP/ 119702-3 B- 3 Screw (M7x1,0x22) GP/ 119702-4 B- 4 Screw (M7x1,0x16,5) GP/ 700510 B- 5...

  • Page 18: Lower Shaft And Clutch Mechanism

    Lower Shaft and Clutch Mechanism anita-b GP-510-143...
  • Page 19 Lower Shaft and Clutch Mechanism anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part GP/ 175025 C1- 1 Shaft GP/ 518250 C1- 2 Retaining Ring GP/ 119711 C1- 3 Shaft GP/ 175019 C1- 4 Coupler GP/ 341901 C1- 5...

  • Page 20: Timing Belt Drivingmechanism

    Timing Belt Driving Mechanism anita-b GP-510-143...
  • Page 21 GP-510-143 Q´ty Part No. Ref. No. Name of Part GP/ 119097 C2- 1 Plug GP/ 610300 C2- 2 Retaining Ring GP/ 018624 C2- 3 Ball Bearing GP/ 119707 C2- 4 Timming Belt Wheel GP/ 335902-1 C2- 5 Screw (M6x0,75x8)

  • Page 22: Lower Feed Mechanism

    Lower Feed Mechanism anita-b GP-510-143...
  • Page 23 Lower Feed Mechanism anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part D2- 1 GP/ 119795 Roller Bracket D2- 1-1 GP/ 119795-1 Roller Bracket D2- 1-2 GP/ 119795-2 Roller Bracket D2- 1-3 GP/ 119795-3 Screw D2- 1-4 GP/ 119795-4...

  • Page 24: Feed Shaft Mechanism

    Feed Shaft Mechanism anita-b GP-510-143...
  • Page 25 Feed Shaft Mechanism anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part GP/ 610280 D3- 1 Retaining Ring GP/ 119085 D3- 2 Washer GP/ 133283 D3- 3 Washer GP/ 215124 D3- 4 Needle Bearing GP/ 118600 D3- 5 Bushing...

  • Page 26: Stitch Adjuster Mechanism

    Stitch Adjuster Mechanism anita-b GP-510-143...
  • Page 27 Stitch Adjuster Mechanism anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part GP/ 175038 D4- 1 Connecting Rod GP/ 069060 D4- 2 Ball Bearing GP/ 175038A D4- 3 Crank Rod Set GP/ 215028 D4- 4 Needle Bearing GP/ 118612...

  • Page 28: E Needle Bar And Presser Foot Mechanism

    Needle Bar Feed and Presser Foot Mechanism anita-b GP-510-143...
  • Page 29 Needle Bar Feed and Presser Foot Mechanism anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part GP/ 175096 E- 7 Needle Bar GP/ 174173 E- 8 Screw(M3x0,5x4) E- 9 GP/ 175096-2 Thread Guide GP/ 175150 E- 10 GP/ 215028...

  • Page 30: Thread Take-Up Lever Mechanism

    Thread Take-Up Lever Mechanism anita-b GP-510-143...

  • Page 31: Screw (M5X0,8X8)

    Thread Take-Up Lever Mechanism anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part GP/ 118084 F- 1 Thread Take-up Assy GP/ 119009 F- 2 Take-up Lever Support Stud GP/ 168039 F- 3 Washer GP/ 215022 F- 4 Needle Bearing...

  • Page 32: Roller Presser Foot Mechanism

    Roller Presser Foot Mechanism anita-b GP-510-143...
  • Page 33 Roller Presser Foot Mechanism anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part GP/ 119803 G1- 1 Roller Preser Assy (Large) GP/ 119803-1 G1- 2 Roller Preser Assy (Middle) GP/ 119802 G1- 3 Roller Preser Assy (Small) GP/ 119469...

  • Page 34: Presser Foot Bar Mechanism

    Presser Foot Bar Mechanism anita-b GP-510-143...

  • Page 35: Cover

    Presser Foot Bar Mechanism anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part GP/ 119019 G2- 1 Presser Bar Bushing (Upper) GP/ 700785 G2- 2 Screw (M5x0,8x6) GP/ 119018 G2- 3 Presser Bar Bushing (Upper) GP/ 118530 G2- 4...

  • Page 36: Right Side Hook Mechanism

    Right Side Hook Mechanism anita-b GP-510-143 for version GP-510-143(i) hook without bobbin case available only as complete for version GP-510-143i hook without bobbin case available only as complete...

  • Page 37: Bracket

    Right Side Hook Mechanism anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part HPF -490A(5)TR H1- A* Hook comlete without bobbin case for GP-510-143i GP/ G400S H1- 1 Hook Complete With Bobbin Case H1- 1-1 GP/ G400S-589 Hook complete without cap...

  • Page 38: Right Side Hook Post Mechanism

    Right Side Hook Post Mechanism anita-b GP-510-143...
  • Page 39 Right Side Hook Post Mechanism anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part Srew/šroub(M3x0.5x6) I1- 2 GP/ 250084 GP/ 175267 I1- 3 Cover Plate Screw/šroub(M4x0,7x6) GP/ 700336 I1- 4 GP/ 175318 I1- 5 Stud/excentr Screw/šroub(M5x4.5) GP/ 330217 I1- 6...

  • Page 40: Lef Side Post Mechanism

    Left Side Post Mechanism anita-b GP-510-143...
  • Page 41 Left Side Post Mechanism anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part I3- 1 GP/ 119145 Cover Plate/kryt Screw/šroub(M3x0,5x6) I3- 2 GP/ 250084 Support Plate/levý sloupek I3- 3 GP/ SM5-4.9M Washer/podložka I3- 4 GP/ 119144 Screw/šroub(M5x0,8x12) I3- 5 GP/ 130224 Screw/šroub(m6x1,0x14)

  • Page 42: Needle Feed And Driven Roller Mechanism

    Needle Feed and Driven Roller Mechanism anita-b GP-510-143...

  • Page 43: Screw

    Needle Feed and Driven Roller Mechanism anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part Holder/držák GP/ SM5-11.1 K1- 1 Screw/šroub M5x12 DIN 912 GP/ M5x12 K1- 2 Screw/šroub M5x16 DIN 915 GP/ M5x16 K1- 3 Screw/šroub M5x30 DIN 915...
  • Page 44 Left Side Post and Lower Backtacking Feed Mechanism anita-b GP-510-143...

  • Page 45: Left Side Post And Backtacking Feed Mechanism

    Left Side Post and Backtacking Feed Mechanism anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part GP/ SM5-21.3 K2- 1 Rod/Rameno SB GP/ SM5-2.10 K2- 2 Rod/Rameno SJ GP/ SM5-2.12 K2- 3 Rod/rameno ZJ GP/ SM5-2.11 K2- 4 Rod/rameno ZB Screw/šroub M5x12 DIN 912...

  • Page 46: Upper Driven Roller Backtacking Feed Mechanism

    Upper Driven Roller Backtacking Feed Mechanism anita-b GP-510-143...

  • Page 47: Screw

    Upper Driven Roller Backtacking Feed Mechanism anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part Shaft-Set/hřídel úplná GP/ SM5-S31 K3- 1 Washer/kroužek GP/ SM5-31.37 K3- 3 Oil Felt/plstěný kroužek GP/ SM5-31.33 K4- 4 GP/ 130224 K3- 5 Washer/podl.dist. DIN 988,10x16/0,5(+0,3) Locking Plate/poj.kroužek BR19...

  • Page 48: Telescopic Shaft Driven Roller Mechanism

    Telescopic Shaft Driven Roller Mechanism anita-b GP-510-143...
  • Page 49 Telescopic Shaft Driven Roller Mechanism anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part Shaft/hřídel s kulovým kloubem GP/ SM5-31.29 K4- 1 Spring/tlačná pružina GP/ SM5-31.36 K4- 2 Shaft/hřídel GP/ SM5-31.31 K4- 3 Pin/kolík 2,5m6x12 DIN6325 GP/ 2,5m6x12 K4- 4 Clutch/kloubová...

  • Page 50: Upper Shaft Driven Roller Mechanism

    Upper Shaft Driven Roller Mechanism anita-b GP-510-143...
  • Page 51 Upper Shaft Driven Roller Mechanism anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part Holder/držák GP/ SM5-31.38 K5- 1 Crank/páka GP/ 119163 K5- 2 Link/táhlo GP/ 119507 K5- 3 Screw/šroub(M4x10) GP/ 174176 K5- 4 Oil Felt/plstěný kroužek GP/ 119087 K5- 5 Screw/šroub M5x12 DIN 912...

  • Page 52: Rods Lower Backtacking Mechanism

    Rods Lower Backtacking Mechanism anita-b GP-510-143...
  • Page 53 Rods Lower Backtacking Mechanism anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part GP/ SM5-21.8 Holder/držák Rod/páka GP/ SM5-21.2 Pin/kolík 5m6x25 DIN 12771A GP/ 5m6x25 Bracket/podpěra GP/ SM5-2.4 Screw/šroub M6x40 DIN 912 GP/ M6x40 GP/ SM5-2.8 Nut/matice Lever/táhlo GP/ SM5-S4.12 GP/ 4 Washer/podložka...

  • Page 54: Hand Lever Backtacking Mechanism

    Hand Lever Backtacking Mech.anism anita-b GP-510-143...
  • Page 55 Hand Lever Backtacking Mech.anism anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part GP/ 06050A1230 K7- 1 Hand lever GF/ SC-0186-4118 K7- 2 Screw GP/ 4m6x25 K7- 3 Pin 4m6x25 DIN 12771A GP/ M4x10 K7- 4 Screw M4x10 DIN 963A GP/ SM5-41.2...

  • Page 57: Bobbin Winder

    Bobbin Winder anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part GP/ GU-100T N1- 1 Bobbin Winder-Built in D/ D08082993000 N1- 2 Knife D/ D08028312900 N1- 3 Spring 283129 D/ D08028313000 N1- 4 Spring 283130 P/ P98002524800 N1- 5...

  • Page 58: N2 Accesories

    Accessories anita-b GP-510-143...
  • Page 59 Accessories anita-b GP-510-143 Q´ty Part No. Ref. No. Name of Part GP/ 123456 N2- 1 Accessory Bag N2- 2 GP/ 029836 Vinyl Cover GP/ 800110 N2- 3 Spanner GP/ 129915 N2- 4 Screw Driver (Small) GP/ 029946 N2- 5 Screw Driver (Middle)

This manual is also suitable for:

Gp-510-143i

Table of Contents
