CODELOCKS Pushbutton 500 Series Installation Insrtuctions page 3

MODEL 500/505 INSTALLATION INSTRUCTIONS
The model 500/505 is intended to replace the conventional door furniture fitted
to an existing mortice latch, or an existing mortice lock which has both a spring
latch and a deadbolt. The square follower should be 8mm square. Any lock and
key mechanism is retained to operate the deadbolt. The latchbolt will only
operate by code, and NOT by key.
A mortice lock case should have holes for fixing bolts to pass through on either
side of the square latch follower and sometimes, additionally, a hole below the
follower. See figure 1 and confirm that your lockcase is compatible with the
500/505 lock plates.
8mm latch follower
'B'
Through fixing holes
either side of the follower
'A'
Through fixing hole
below the follower
FIGURE 1 – lockcase
step 2
Take the 2-part spindle, with
the springs in place. Note that
one has a RED coloured face,
and the other a BLUE face. If
your door is hinged on the
right, viewed from outside,
then fit the BLUE spindle into
the latch follower on the
outside, with the colour on
TOP. Fit the RED spindle to
the inside, again with the
colour on TOP. For a left hand
hung door fit the spindles the
other way around, with the
colours on TOP.
IF YOUR LOCKCASE HAS A
HOLE BELOW THE
step 3
FOLLOWER (FIGURE 1 'A'),
Check that the lever handles
PROCEED AS FOLLOWS:
are correctly fitted for the
hand of door. To change the
step 1
hand of a lever handle, loosen
the grub screw with the small
Hold one of the black
Allen key, reverse the lever
neoprene seals against the
handle and fully tighten the
door, perfectly vertically, with
grub screw.
the large hole accurately over
the follower. Mark the top and
step 4
bottom holes on the door
face, and repeat the
Cut two of the black socket
procedure on the other side
head screws to the required
of the door. Remove the lock.
length for your door.
At both points drill a 12mm
hole through the door. Drill
Approximate overall length
from both sides for greater
should be door thickness plus
accuracy and to avoid
25mm, to allow about 10mm
splintering out of the door
of threaded bolt to enter the
face. Check that the existing
outside plate.
spindle hole is at least 18mm
diameter. Replace the lock.
step 5 IF YOUR LOCKCASE ONLY
HAS HOLES ON EITHER
Apply the front and back
SIDE OF THE FOLLOWER
plates, with the neoprene
(FIGURE 1 'B'), PROCEED
seals in position, against the
AS FOLLOWS:
door, over the protruding
ends of the spindle.
step 1
step 6
Hold one of the black
neoprene seals against the
Fix the two plates together
door, perfectly vertically, with
using the socket head bolts,
the large hole accurately over
starting with the top fixing.
the follower. Mark the top hole
Ensure that the two plates are
and the holes on either side
truly vertical and then tighten
of the follower, and then
the bolts using the 'T' shaped
repeat the procedure on the
Allen key. Do not use
other side of the door.
excessive force.
Remove the lock.
step 7
Drill the 3x 12mm holes from
Before closing the door,
both sides for greater
enter the code and ensure
accuracy, and to avoid
that the latchbolt will retract
splintering out of the door
when the lever handle is
face. Check that the existing
depressed. Now check the
spindle hole is at least 18mm.
operation of the inside lever
handle. If there is any binding
step 2
of the handles or latch then
Take the 2-part spindle, with
loosen the bolts slightly and
reposition the plates slightly the springs in place. Note that
until the correct position is one has a RED coloured face,
and the other a BLUE face. If
found, and then re-tighten
your door is hinged on the
the bolts.
right, viewed from outside,
then fit the BLUE spindle into
the latch follower on the
outside, with the colour on
TOP. Fit the RED spindle to
the inside, again with the
colour on TOP. For a left hand
hung door fit the spindles the
other way around, with the
colours on TOP.
