(8) Sensitivity-control
(9) DMX-In socket
(10) DMX-Out socket
(11) Fuseholder
(12) Power supply
(13) Safety eyelet
(14) Lamp system
(15) Enter-button
(16) Down-button
(17) Up-button
(18) No-button
(19) Yes-button
(20) Display
(21) Control LED

INSTALLATION

Installing/Replacing the lamp

For the installation, you need one EHJ 24 V/250 W G-6,35 lamp.
13
DANGER TO LIFE!
Only install the lamp with the device switched off!
Unplug from mains before!
CAUTION!
The lamp has to be replaced when it is damaged
or deformed due to the heat!
20/52
Sensitivity
8
9
10
11
12
Power supply
230 V AC/ 50Hz
14
