DESCRIPTION OF THE DEVICE

Features

Compact colour-changer
• Colour-wheel with 10 dichroic colour-filtres + white + closed
• Rainbow-effect with adjustable speed in both directions
• Manual focus
• DMX-control only via DMX-Wizard
• 2 DMX-control-channels required
• 1 channel for the colour wheel and a second one for the electronic dimmer
• Sound-controlled via built-in microphone
• Microphone-sensitivity adjustable via rotary-control
• Sound-controlled colour-wheel via DMX adjustable
• Master/Slave-function
• EHJ 24 V/250 W G-6.35 lamp included in the delivery

Overview

(1) Mounting bracket
(2) Fixation screw
(3) Venting slots
(4) Housing cover
(5) Housing screws
(6) Objective-lens/Focus
(7) Control Board
1 2
19/52
3 4 5
51785875_V_1_2.DOC
6 7
