  • Page 1 CDR-110 ORDERCODE D1253...
  • Page 2 Congratulations! You have bought a great, innovative product from DAP Audio. DAP Audio CDR-110 brings excitement to any venue. Whether you want simple plug-&-play action or a sophisticated show, this product provides the effect you need. You can rely on DAP Audio, for more excellent audio products.

  • Page 3: Table Of Contents

    Dap Audio Dap Audio CDR-110™ Product Guide Warning.................…...……………..…………………………….………..… Unpacking Instructions………………………………………………………………………………………………...….. Safety-instructions………………………………………………………………………………………………………...… Operating Determinations.……………………………………………………………………………………………..Return Procedure..............................Claims..................................Description................…...………………………………………….………..… Features and Overview ………………………………...….……………….………….……….……….…………..…… Frontside…………………………………………………...…...….……………….…………………...….……………...… Backside…………………………………………………...…...….……………….…………………...….………..…….. Installation..................................Set Up and Operation..............................Names and functions..............................Operations..................................Play Modes................................Selecting tracks forward............................Selecting tracks backwards..........................

  • Page 4: Warning

    Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: • DAP CDR-110 • IEC power cable (2,30m) • User manual...

  • Page 5: Operating Determinations

     Do not insert objects into air vents.  Do not connect this system to a dimmerpack.  Do not switch the system on and off in short intervals, as this would reduce the system’s life.  Do not open the device and do not modify the device. ...

  • Page 6: Return Procedure

    Connection with the mains Connect the device to the mains with the power-plug. Always pay attention, that the right color cable is connected to the right place. International EU (including UK) North America From April 2004 Brown Black Phase Blue White Neutral Green/Yellow...

  • Page 7: Description Of The Device

    CDR-110 is a CD/SD/MMC/USB compatible MP3 Player/ Recorder from DAP Audio. You can use the CDR-110 to record directly to either USB or SD/MMC card. If both media are present, the USB stick has priority as recording destination. • USB slot •...
  • Page 8 Remote Control Fig. 3 25) Direct Access Buttons 33) Stop Button 26) Folder Button 34) Prog (Program) Button 27) Folder Button 35) Find Button 28) Repeat Button 36) ESP Button 29) Display Button 37) Cue Skip Button 30) Eject Button 38) Rev (Reverse) Skip Button 31) Mute Button 39) Rec/ Del (Record/ Delete) Button...

  • Page 9: Installation

    Installation CDR-110 Installation Remove all packing materials from the device. Check that all foam and plastic padding is removed. Screw the device in a 19“ Rack. Connect all cables. Always disconnect from electric mains power supply before cleaning or servicing.
  • Page 10 When powering on the CDR-110 without a USB stick or a SD/MMC card inserted, the CDR-110 will start searching for a source, indicated by “USB” blinking in the display. If the CDR-110 does not detect a source within approximately 6 seconds, the display will show “No USB”. If you insert a USB stick or a SD/ MMC card, the display will look as shown in figure 4.

  • Page 11: Operations

    Operations 1. Play Modes Three different play modes are available: REPEAT, REPEAT ALL, REPEAT ALBUM When you press the Repeat (19, 28) button, you can choose between the following play modes: 1.Repeat: Repeats a single track several times. 2.Repeat All: Plays the complete medium several times. 3.Repeat Album: Plays the complete album several times.

  • Page 12: Starting Playback

    • Press the Find (17, 35) button again to browse through your folders. The display will look as shown in figure 6. Fig. 6 • You can browse through your folders by using the Rev (7, 38) and Cue (8, 37) buttons. •...

  • Page 13: Delete A Track

    TMAUX. In future the CDR-110 will store all files recorded from the Rec input (23) in this folder. The files will be named TMAUX001, TMAUX002 etc. as they are recorded.

  • Page 14: Maintenance

    Troubleshooting DAP Audio CDR-110 Recorder. This troubleshooting guide is meant to help solve simple problems. If a problem occurs, carry out the steps below in sequence until a solution is found. Once the unit operates properly, do not carry out following steps.

  • Page 15: Product Specifications

    Product Specifications Power supply: AC 230V - 50 Hz Power consumption: 50 Watt Input: USB memory stick, SD/MMC card slot RCA stereo audio signal Output: USB memory stick, SD/MMC card slot RCA stereo audio signal THD: 1kHz, < 0,3% S/N Ratio: >...
