Specifications - Fender KXR 200 Service Manual

Product Release No.:
Power output:
Distortion at 200 watts:
Rated Load Impedance:
Input impedance:
Sensitivity:
DELTACOMP Range:
PREAMP SECTION:
Input Impedance:
Senitivity for 200 watts:
Channel and master
Volume at maximum, all
Tone controls at "0"
Equalizer:
Sensitivity for channel
Inserts, Master volume
At maximum setting
Sensitivity for Master
Volume and FX return
Control at maximum
Dimensions:
Weight:
KXR 200

SPECIFICATIONS

PR 286 (This is not a model number)
200 Watts RMS
Less than .1% @ 1kHz, below compression
Less than 1% @ 1kHz, maximum compression
4 Ω
22K Ohms
1.03V RMS
20dB
XLR – 1.82K Ω
Phone – 18.2k Ω
XLR – 2.9mV RMS
Phone – 29mV RMS
For 3-band-EQ sections:
+/- 12dB at 130,540 and 4200 Hz
500mV RMS (-6dBV)
130mV RMS (-18dBV)
Height: 29 3/4"
Width: 21 11/16"
Depth: 12"
88 lbs.
Product specifications are subject to change without notice
(75.6 cm) (w/o casters)
(55.1 cm)
(30.5 cm)
(40.0 kg)
