Cabinet Assembly; Miscellaneous - Fender KXR 200 Service Manual

QTY PART #
1 048971000 HEAT SINK EXTRUDED BXR 200
28 048835000 KNOB CTL SUCTOM DBL BLK/OFFWHT
2 069393000 NUT 6-32 HEX EXT LOCK
1 022004000 NUT KEPS #8-32 ZINC
1 048500000 PANEL FRONT KXR 200
1 048501000 PANEL REAR KXR 200
2 047523000 RECEPTACLE W/TAB .250 18-14 GA
6 017716000 SCREW M 8-32X1/2 PHP BLX
4 037568000 SCREW M 6-32X3/4 PHP ZI LW
2 039367000 SCREW M 6-32X3/8 PHPS SS ITLW
4 031184000 SCREW M 6-32X1/4 PHPS BLX ITLW
2 031868000 SCREW PLASTITE 4X1/4 PHP BLX
2 037990000 SCREW PLASTITE 6X3/5 PHP BLX
4 037997000 SCREW TF 10-32X5/8 HWHS BLX
5 027636000 SCREW TF 8-32X5/8 HWH BLX
1 049524000 SHIELD KXR 200
4 031241000 STANDOFF HX M/F AL 6-32X3/8
1 040582000 SWITCH DPST .250 TAB GLOBAL
1 048960000 XFMR DOMESTIC BXR 200
1 041122 XFMR PWR EXPORT
QTY PART #
1 048498000 CAB ASSY KXR 200
1 047120000 CABLE REVERB 1450MM
4 023513000 CASTER SWIVEL
0.48 026317000 CLOTH GRILLE BLACK PVC
6 031867000 CORNER 2 HOLE W/ NOTCH BLK PWDR
2 03184000 CORNER 3 HOLE BLK PWDRD
4 029821000 EYELET RFLNGD .215ODX.315L
2 049564000 GASKET HANDLE
1 02888500 GASKET HORN DUAL PIEZO
4 02784900 GLIDE CAB 1.24X.335 BLX WAX
1 048498001 GRILLE ASSY KXR 200
2 048958000 HANDLE RECESSED KXR/BXR
1 028813000 HORN DUAL PIEZO (ADD 028885)
4 019275000 INSERT GLIDE CUSHION 1.27 DIA
4 023505000 MTG PLATE – SWIVEL CASTER
1 011298000 NAMEPLATE FENDER SMALL
8 021972000 NUT T 10-32X3/4 STR 3 PRNG BLX
1 028055000 REVERB UNIT 800 OHM 8EB2C1B DN
REF 026570000 TOLEX BLACK LT WEIGHT
6 029527000 WSHR FNSH 8-5/8 FLNGD BLX WX
QTY PART #
048502000 MANUAL OWNER KXR 200
048493 SCHEM REDU W/SVC KXR200 PRE
048840 SCHEM REDU W/SVC PA BXR/KXR 200
CHASSIS ASSEMBLY (CONT)
DESCRIPTION

CABINET ASSEMBLY

DESCRIPTION
DESCRIPTION
KXR 200

MISCELLANEOUS

REFERENCE DESIGNATION
GROUND LUG MOUNT
BRIDGE RECTIFIER MOUNT
HATSINK TO CHASSIS MOUNT
PWR AMP PCB MNT
PREAMP PCB MOUNT
SHIELD MOUNT
FEMALE XLR MOUNT (FRONT)
MALE XLR MOUNT (REAR)
TRANSFORMER MOUNT
HEATSINK TO TRANSISTOR BAR
@ PREAMP
SHIELD MOUNT
POWER SWITCH
T1 (120V DOMESTIC ONLY)
T1 (100/120/230V)
REFERENCE DESIGNATION
ENTIRE CABINET
FRONT AND TOP/REAR
BOTTOM/REAR
REVER PAN MOUNT
STEEL ONLY
COMPLETE GRILLE
COMPLETE HORN)
RUBBER ONLY
CASTER SOCKET
LOGO
SPEAKER MOUNT
REVERB PAN
CHASSIS MOUNT
REFERENCE DESIGNATION
PREAMP
POWER AMPLIFIER
