WIRELESS KITS (DT01*, DS01*, DD01*)
DS01*
for additional assistance and explanation prior to ordering materials or cutting openings.
USE ONLY ONE DD01* PASSIVE INFRARED MOTION SENSOR (PIR) DOOR SWITCH
COMBINATION DEVICE AND/OR ONE DS01* TO ONE DIGISMART PTAC UNIT.
ATTENTION INSTALLING PERSONNEL
As a professional installer you have an obligation to know the product better than the customer.
Prior to actual installation, thoroughly familiarize yourself with this Instruction Manual.
it is possible to place yourself in a position which is more hazardous than when the unit is in operation.
Remember, it is your responsibility to install the product safely and to know it well enough
The precautions listed in this Installation Manual are intended as supplemental to existing practices.
However, if there is a direct conflict between existing practices and the content of this manual,
is a trademark of Maytag Corporation and is used under license to Goodman Company, L.P. All rights reserved.
®
November 2007
IO-644D
Due to policy of continued product improvement, the right is reserved to change specifications and design without notice.
PTAC
I
NSTALLATION
IO-644C~IO-644C~092007~4
The following installation instructions are for a typical installation.
Please contact your PTAC salesperson
This includes all safety precautions and related items.
Pay special attention to all safety warnings. Often during installation or repair
to be able to instruct a customer in its safe use.
Safety is a matter of common sense...a matter of thinking before acting.
Most dealers have a list of specific good safety practices...follow them.
the precautions listed here take precedence.
Goodman Company, L.P.
5151 San Felipe, Suite 500
www.amana-ptac.com
I
NSTRUCTIONS
•
Houston, TX 77056
•
© 2005 - 2007 Goodman Company, L.P.
AIR CONDITIONING SENSOR
DD01*
DT01*
Advertisement
Table of Contents
Related Manuals for Amana DT01 Series
Summary of Contents for Amana DT01 Series
- Page 1 Goodman Company, L.P. November 2007 • 5151 San Felipe, Suite 500 Houston, TX 77056 IO-644D • www.amana-ptac.com © 2005 - 2007 Goodman Company, L.P. Due to policy of continued product improvement, the right is reserved to change specifications and design without notice.
- Page 2 6. Mount antenna housing with two screws as shown in operation of either the DS01* remote RF thermostat or a ® figure. (NOTE: The Amana brand logo should be in the DD01* combination PIR motion sensor and door switch. lower right hand corner).
- Page 3 DD01* 2. Mount the back plate on the door trim directly above the door using the enclosed screws. Mount the DD01* as low as possible on the door frame to be as close to the DOOR TRIM moving part of the door as possible with out interfering with the door opening or closing.
- Page 4 Select one of the three slots that places the magnet ½” from the sensor mounting plate on the door frame. See expamples below. The door frame and door usually will not align. Place holder on the door and select the slot that places the magnet as close as possible to the ½”...
- Page 5 Binding of RF Devices DO NOT ATTEMPT TO BIND MORE THAN ONE ROOM AT A TIME AT THE SAME PROPERTY!!! RF TRANSMITS THROUGH WALLS. The wireless devices (DS01* and or DD01*) must be bound to the PTAC DT01* control for proper in-room communication. Ensure the unit is powered but in the OFF position.
-
Page 6: Configuration Settings
Configuration Settings The PTAC control will automatically self-configure to work with the wall thermostat (DS01* Kit) if installed. The PTAC control will automatically self-configure to activate pre-configured energy management routine when the DD01* is installed and bound to the PTAC. Additionally, the setback times and setback temperatures can be changed using the configuration settings. - Page 7 Setback Temps - DD01* The DD01* and the DigiSmart control can be programmed for 3 different times to activate temperature setbacks. The current factory default temperature setbacks in v2.5 * software release are: 2º from set point in 30 minutes, 3º in one (1) hour, and 6º...
- Page 8 9. Press HEAT key to scroll to third unoccupied setback time. Press either the up or down arrow to the desired third unoccupied setback time. 10.. To exit configuration mode: Press the OFF key. NOTE: Configuration feature mode will also automatically exit if no keys are pressed for a period of two (2) minutes.
