- Page 1 PTAC DIRECT SALES, INC. 185 S. KIMBALL AVE., SUITE 130 SOUTHLAKE, TX 76092 877.454.7822 Amana PTAC DS01(x) Wireless Thermostat Pairing...
- Page 2 1. Remove the Amana PTAC inside front cover to access the splash pad cover. Splash Pad...
- Page 3 2. Using a ¼ inch nut driver or slotted head screwdriver remove the 3 screws from splash pad cover. Remove the splash pad from the Amana PTAC unit. Splash Pad Screws Splash Pad...
- Page 4 3. Press and hold the pairing button for 5 seconds, then release the button. The blue LED light will flash slowly. This action puts the PTAC unit into RF (radio frequency) pairing mode. The unit will remain in RF pairing mode for 90 seconds.
- Page 5 4. Remove the mounting plate of the Amana DS01(x) thermostat. Insert the 2 provided AA batteries. Press and release the white pairing Pairing Button button. Pairing Button...
- Page 6 5. The thermostat display will respond with 00 once it pairs to 6. Once pairing is confirmed. Place Amana PTAC unit. Confirm the wall thermostat on the mounting this by pressing the MODE button plate. Reinstall the splash pad and on the thermostat.
