Firenzo ROYALE Installation Manual

Freestanding clean air woodburner
Hide thumbs Also See for ROYALE:

Advertisement

Quick Links

See also: Manual
Please read this booklet and keep for future reference for the safe installation
and operation of your:
ROYALE
Freestanding Clean Air Woodburner
All installations must be in accordance with these instructions. Consult with the
building authority having jurisdiction to determine the need for a permit prior to
commencing the installation. Failure to follow these instructions may also void
your home insurance and warranty.
Please leave this manual with the owner when installation is
complete.
Please complete and return your warranty registration card which is enclosed.
Please leave these instructions with owner when installation is complete.
