Firenzo KOMPACT User Manual

Insert clean air woodburner
Hide thumbs
Table of Contents

Advertisement

Quick Links

Please read this booklet and keep for future reference for the safe installation
and operation of your:
KOMPACT
Insert Clean Air Woodburner
All installations must be in accordance with these instructions. Consult with the
building authority having jurisdiction to determine the need for a permit prior to
commencing the installation. Failure to follow these instructions may also void
your home insurance and warranty.
Please leave this manual with the owner when installation is
complete.
Please complete and return your warranty registration card which is enclosed.
Kompact Guide Version 16/05/2013
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KOMPACT and is the answer not in the manual?

Questions and answers

Related Manuals for Firenzo KOMPACT

Summary of Contents for Firenzo KOMPACT

  • Page 1 Failure to follow these instructions may also void your home insurance and warranty. Please leave this manual with the owner when installation is complete. Please complete and return your warranty registration card which is enclosed. Kompact Guide Version 16/05/2013...

  • Page 2: Table Of Contents

    INDEX Page 1. Warnings 2. Installation Responsibilities KOMPACT FIREBOX IN A MASONRY ENCLOSURE 3. Floor Protector Requirements 2A. Solid Concrete Floor 2B. Heat Sensitive Floor 4. Mantel Clearances 5. Assembly Instructions 6. Insert Flue System Minimum Height of Flue Exit 7.

  • Page 3: Warnings

    1. WARNINGS THIS APPLIANCE SHOULD BE MAINTAINED AND OPERATED AT ALL TIMES IN ACCORDANCE WITH THESE INSTRUCTIONS. The Kompact is tested to Australian and New Zealand Standards AS/NZS 2918:2001. INCORRECT INSTALLATION OF THIS APPLIANCE MAY RESULT IN OVERHEATING OF HEAT SENSITIVE MATERIALS AND POSSIBLE FIRE.

  • Page 4: Kompact Firebox In A Masonry Enclosure

    Australian and New Zealand Standards. Any unfavourable outcomes that arise from tampering with the appliance will void any warranty claims. KOMPACT FIRE BOX IN A MASONRY ENCLOSURE 3. FLOOR PROTECTOR REQUIREMENTS According to AS/NZS 2918:2001...

  • Page 5: A. Solid Concrete Floor

    A 300mm from breast of fire to outer edge of concrete floor protector (hearth) B 30mm from heat sensitive floor to upper edge of concrete floor protector (hearth) The minimum width of floor protector must be 820mm and/or 410mm from the centre of the heater. Kompact Guide Version 16/05/2013...
  • Page 6 Minimum width of floor protector must be 820mm and/or 410mm from centre of heater. Before installing your Firenzo Kompact it is important to check the condition of your masonry chimney. Ensure any cracks are sealed, loose masonry repaired and the chimney swept. Check the dimensions of your fireplace opening are adequate to accept the new heater.

  • Page 7: Mantel Clearances

    4. MANTEL CLEARANCES If the mantel shelf on your masonry fireplace is of a combustible material the minimum distance from the floor protector is as follows. This may be reduced if a Firenzo Kompact Deflector is fitted. Diagram 3 DEFLECTOR...

  • Page 8: Assembly Instructions

    AS/NZ 2918 3.4.1.2 to assist air flow into the fire. This ventilation should not be taken/drawn from the room that the fire is installed in. Kompact Guide Version 16/05/2013...

  • Page 9: Insert Flue System

    CAUTION: Mixing of flue system components from different sources or modifying the dimensional specifications of components may result in hazardous conditions. Where such action is considered the flue manufacturer should be consulted in the first instance. Kompact Guide Version 16/05/2013...
  • Page 10 3 metres of it, or 1 metre above the roof penetration if more than 3 metres from the ridge. 3. No part of the building, or any adjacent building may be in or above a circular area of a horizontal radius of 3 metres from the flue exit. Kompact Guide Version 16/05/2013...

  • Page 11: Typical Insulation Requirements

    7. TYPICAL INSULATION REQUIREMENTS Diagram 6 WHITE KAOWOOL BLANKET PLACED ON TOP OF HEATER AIRPORTS INTO HEATER YELLOW I.S.B INSULATION DO NOT PACKED BETWEEN HEATER BLOCK CANOPY AND MASONRY ENCLOSURE MAX DEPTH OF 80MM. DO NOT COVER AIRPORTS. Kompact Guide Version 16/05/2013...
  • Page 12 UNDER NO CIRCUMSTANCES SHOULD THE AIR SUPPLY INTO THE AIRPORTS ON THE SIDE OF THE HEATER BE RESTRICTED Diagram 7 BRICK / MASONRY FIRE BOX IN CANOPY ENCLOSURE I.S.B INSULATION (YELLOW) PACKED BETWEEN HEATER AND BRICK / MASONARY ENCLOSURE Kompact Guide Version 16/05/2013...
  • Page 13 8. FASCIA DIMENSONS, ASSEMBLY & INSTALLATION ATHENA KOMPACT WITH FASCIA Kompact Guide Version 16/05/2013...

  • Page 14: Kompact With Athena Fascia

    Assembly and Installation Instructions: KOMPACT with ATHENA Fascia Canopy Bottom grill 1. Remove all items from packaging and separate. 4. Fit the bottom grill on to the 2 locating screws. Remove door. Then remove the two 50mm screws (1) located one on each side of the door opening.
  • Page 15 DECO KOMPACT WITH FASCIA Kompact Guide Version 16/05/2013...

  • Page 16: Kompact With Deco Fascia

    Assembly and Installation Instructions: KOMPACT with DECO Fascia Fascia Granite ashlip Bottom grill 3. Remove the granite ashlip from the fascia 1. Remove all items from packaging and box and fit below the door opening using the separate. two locator screws at the bottom of the firebox Remove door.
  • Page 17 FORTE KOMPACT WITH FASCIA Kompact Guide Version 16/05/2013...

  • Page 18: Kompact With Forte Fascia

    Assembly and Installation Instructions: KOMPACT with FORTE Fascia Canopy Forte top grill Top grill Forte ashlip 3. Refit the top grill. 1. Remove all items from packaging and separate by Remove the granite ashlip from the fascia box releasing the bottom grill screws...

  • Page 19: Operating Instructions

    3-4 adjustments to get to the low setting (extended burn). Always ensure a good burn is established otherwise the fire will smoulder and smoke will build up which could result in a flash back or back fire where the smokes ignites. RELOADING Kompact Guide Version 16/05/2013...
  • Page 20 The heat output level on the heater is controlled not only by the Air Control but also by the type and quantity of fuel in the firebox. Using the proper fuel means the appliance will run correctly GOOD FUEL IN = GOOD HEAT OUT Kompact Guide Version 16/05/2013...

  • Page 21: Maintenance

    Your heating retailer or local reputable chimney sweep will be able to assist with flue cleaning. SECONDARY CHAMBER The baffles (horizontal bricks in the ceiling of firebox) are critical to the heaters Kompact Guide Version 16/05/2013...

  • Page 22: Door Glass

    NEVER place glass directly against the door. Without the insulation seal tape in place, the glass is likely to shatter. Your Firenzo agent will be able to supply any spare parts.

  • Page 23: Warranty

    Firenzo Australia Pty will provide free labour and replacement of any parts covered by this warranty or the entire heater at its option after receiving a fully completed Firenzo Australia Pty warranty claim form (available from stockists nationwide).
  • Page 24 Any claim under this warranty should be submitted first to the dealer from whom the stove was purchased. In such cases where the dealer cannot be located, the fully completed warranty claim form should be mailed to Firenzo Australia Pty.
