Firenzo Contessa AG DRY Installation Manual

Freestanding clean air wood burner

Advertisement

Quick Links

Please read this booklet and keep for future reference for the safe
installation of your:
DRY MODEL
FREESTANDING CLEAN AIR WOODBURNER
All installations must be in accordance with these instructions. Consult
with the building authority having jurisdiction to determine the need for a
permit prior to commencing the installation. Failure to follow these
instructions may also void your fire insurance and warranty.
This fire conforms with Ecan Requirements

Advertisement

loading
Need help?

Need help?

Do you have a question about the Contessa AG DRY and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Firenzo Contessa AG DRY

  • Page 1 Please read this booklet and keep for future reference for the safe installation of your: DRY MODEL FREESTANDING CLEAN AIR WOODBURNER All installations must be in accordance with these instructions. Consult with the building authority having jurisdiction to determine the need for a permit prior to commencing the installation.
  • Page 2 Please leave this manual with the owner when installation is complete. INDEX Page No: Item No: Topic Warnings Installation Responsibilities Floor Protector Requirements Installation Clearances Assembly Instructions Fitting Seismic Restraints Flue Installation Minimum Height of Flue Exit Position of Triangular Baffles Published 15/11/2012 Contessa AG Dry...
  • Page 3 PRODUCE ADVERSE EFFECTS ON REFACTORY LINING IN SOLID FUEL APPLIANCES. EMISSION OF POISONOUS GASES CAN ALSO BE EXPERIENCED WITH THE BURNING OF TREATED WOOD. Driftwood with salt content will also cause rapid deterioration of the heater and should not be used. Contessa AG Dry...
  • Page 4: Installation Responsibilities

    20mm of an approved insulation material i.e. 2 sheets of 10mm micorboard or superlux, 10mm tile backing board and 10mm tiles or similar on the top surface. All joints on the upper surface should be sealed to prevent spilt ash from contacting any heat-sensitive material. Contessa AG Dry...
  • Page 5: Installation Clearances

    *Clearances A, F & K can be reduced BY 30mm provided a Contessa cooktop grill is fitted to the fire. If the heater is to be placed on or within 500mm of a heat sensitive floor an insulated floor protector will be required (page 4). Contessa AG Dry...
  • Page 6 14. Fit door knob. »» 15. Fit the control knob - place the flat on the knob to the flat on the air control shaft situated on the right hand side of the fire. Press home firmly. Contessa AG Dry...
  • Page 7 LEG MODELS 1. Place firebox on leg assembly and fit brackets. 2. Locate as per appropriate clearances 3. Secure both the floor protector and the appliance to the floor using a dyna bolt or similar. Contessa AG Dry...
  • Page 8 Where such action is considered the manufacturer should be consulted in the first instance. WARNING: The appliance and flue system shall be installed in accordance with AS/NZS 2918:2001 and the appropriate requirements of the relevant building code or codes. Contessa AG Dry...
  • Page 9 Contessa AG Dry...
  • Page 10 CONTESSA AG DRY IMPORTANT BAFFLES UPON INSTALLATION CHECK THAT THE TRIANGLE BRICKS ON TOP OF THE BAFFLES ARE PLACED AS SHOWN Contessa AG Dry...
  • Page 11 HEWITSONS LIMITED Manufacturers of: Lady Kitchener Contessa Coaster Bronte Royale Viking Encore Zealandia Aqualux Athena Forte Plaza Deco Kompact 98 Niven Street PO Box 3231 Onekawa Napier Phone: 06 8438260 Fax: 06 8430505 Email: hothouse@firenzo.co.nz Website: www.firenzo.co.nz Contessa AG Dry...
