IEI Technology WSB-9454 Quick Installation Manual
Picmg 1.0 cpu card support lga775 intel core 2 duo, pentium d/4, celeron d cpu with vga/dvi, dual pcie gbe lan and sataii
Hide thumbs
Also See for WSB-9454:
- User manual (234 pages) ,
- Quick installation manual (9 pages) ,
- Quick installation manual (9 pages)
Table of Contents
Advertisement
Quick Links
Download this manual
See also:
User Manual
PICMG 1.0 CPU Card support LGA775 Intel
Pentium
Quick Installation Guide
Package Contents
WSB-9454 package includes the following items:
1 x WSB-9454 Single Board Computer
1 x mini jumper pack
1 x ATA flat cable
1 x Dual RS-232 cable
1 x SATA Power cable
2 x SATA cable
1 x KB/MS Y cable
1 x Dual Ports USB cable
1 x IO-KIT-001-R20 (WSB-9454DVI only)
1 x Utility CD
1 x QIG (quick installation guide)
®
D/4, Celeron
Dual PCIE GbE LAN and SATAII
WSB-9454
Version 1.2
Aug. 31, 2009
©2006 Copyright by IEI Technology corp.
All rights reserved.
®
D CPU with VGA/DVI,
®
Core 2 Duo,
1
Advertisement
Table of Contents
Related Manuals for IEI Technology WSB-9454
Summary of Contents for IEI Technology WSB-9454
-
Page 1: Quick Installation Guide
WSB-9454 Quick Installation Guide Version 1.2 Aug. 31, 2009 Package Contents WSB-9454 package includes the following items: 1 x WSB-9454 Single Board Computer 1 x mini jumper pack 1 x ATA flat cable 1 x Dual RS-232 cable 1 x SATA Power cable... -
Page 2: Specifications
Specifications ® ® ® CPU: LGA 775 Intel Core 2 duo, Pentium D/4, Celeron D with 533/800/1066 MHz FSB ® System Chipset: Intel 945G + ICH7 BIOS: AMI Flash BIOS System Memory 4x240-pin Dual-channel DDR2 400/533/667 MHz DRAM up to 4GB Ethernet: Dual Broadcom BCM5787M PCIe interface GbE controller I/O Interface 2 x RS232... -
Page 3: Ordering Information
Ordering Information WSB-9454-R12 ® ® PICMG 1.0 CPU Card support LGA775 Intel Core 2 Duo, Pentium D/4, ® Celeron D 1066MHz processor, VGA, Dual PCIE GbE and SATAII WSB-9454DVI-R12 ® ® PICMG 1.0 CPU Card support LGA775 Intel Core 2 Duo, Pentium D/4, ®... -
Page 4: Jumpers Setting And Connectors
Jumpers setting and Connectors LABEL FUNCTION J_CMOS1 Clear CMOS Jump JLAN_PWR1 WOL Setting Jump KB_MS1 PS/2 MOUSE & KEYBOARD connector LAN1 RJ45 LAN Connectors LAN2 VGA1 VGA 15-pin Female connector USB_C6 External USB Port connector PIDE1 IDE connector FDD1 FDC connector LPT1 Parallel Port connector COM1... - Page 5 J_CMOS1 : Clear CMOS Setup J_CMOS1 DESCRIPTION Short 1-2 Keep CMOS Setup (default)* (Normal Operation) Short 2-3 Clear CMOS Setup JLAN_PWR1:WOL setting JLAN_PWR1 DESCRIPTION Short 1-3 LAN 2 WOL Enable Short 2-4 LAN 1 WOL Enable(Default) Short 3-5 LAN 2 WOL Disable(Default) Short 4-6 LAN 1 WOL Disable AT/ATX Mode Select jump...
- Page 6 USB01, USB23, USB45: Internal USB Connector DESCRIPTION DESCRIPTION VCC +5V DATA- DATA+ DATA+ DATA- VCC +5V IR1: Infrared Interface Connector CPU_FAN1 : CPU Fan Connector DESCRIPTION PIN DESCRIPTION VCC +5V +12V IR-RX Rotation Signal Control IR-TX FDD1: FDC Connector PIN DESCRIPTION DESCRIPTION REDUCE WRITE INDEX#...
- Page 7 COM1,COM2 :Internal Serial Port 10-pin Connectors Connector Ports Address Interrupt COM1 COM1 IRQ4 COM2 COM2 IRQ3 COM1,COM2: Internal Serial Port 10-pin Connectors DESCRIPTION DESCRIPTION DCD# DSR# RTS# CTS# DTR# CPU12V1 : CPU POWER Input Connector DESCRIPTION DESCRIPTION +12V +12V DIO1 : Digital Input / Output Connector DESCRIPTION DESCRIPTION VCC +5V...
- Page 8 LPT1 : Parallel Port Connector DESCRIPTION DESCRIPTION STROBE# AUTO FORM FEED # DATA0 ERROR# DATA1 INITIALIZE# DATA2 PRINTER SELECT LN# DATA3 DATA4 DATA5 DATA6 DATA7 ACKNOWLEDGE# BUSY PAPER EMPTY PRINTER SELECT J_AUDIO1: Audio Connector PIN DESCRIPTION DESCRIPTION SYNC BITCLK SDOUT PCBEEP SDIN RST#...
- Page 9 DVI1 : DVI Connector (WSB-9454DVI Only) DESCRIPTION PIN DESCRIPTION Data 2- VCC(+5V) Data 2+ 16 Hot Plug Detect. Data 0- Data 0+ DDC Clock DDC Data Data 1- Data 1+ Clock + Clock - PIDE1: IDE Interface Connector DESCRIPTION DESCRIPTION RESET# DATA 7 DATA 8...
-
Page 10: Board Layout: Jumper And Connector Locations
Board Layout: Jumper and Connector Locations...
