Wilson Electronics 801101 Installation Manual

Mobile wireless single band signal booster
Hide thumbs
Table of Contents

Advertisement

Quick Links

Signal Booster
Installation
Guide
Contents:
How it Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Before Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installing the Low-Profile Antenna . . . . . . . . . . . . . . . . . . . 5
Warnings and Recommendations . . . . . . . . . . . . . . . . . . . 7
Understanding the Signal Booster Lights . . . . . . . . . . . . . 8
About Wilson Electronics . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Guarantee and Warranty . . . . . . . . . . . . . . . . . . . . . . . . . 10
Signal Booster Specifications . . . . . . . . . . . . . .Back Cover
Note: This manual contains important safety and operating information .
Please read and follow the instructions in this manual . Failure to do so
could be hazardous and result in damage to your signal booster .
Mobile Wireless
Single Band
Signal Booster
Wilson
®
Electronics, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 801101 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wilson Electronics 801101

Summary of Contents for Wilson Electronics 801101

  • Page 1: Table Of Contents

    Installing a Wilson Electronics Outside Antenna . . . . . . . . 3 Installing a Wilson Electronics Signal Booster . . . . . . . . . . 4 Installing the Low-Profile Antenna .

  • Page 2: How It Works

    . Wilson Electronics manufactures a wide variety of antennas to help you customize your signal booster for your specific application . Several are shown below . See your dealer or visit www .wilsonelectronics .com .

  • Page 3: Before Getting Started

    Before Getting Started This guide will help you properly install Wilson Electronics single-band, mobile wireless signal booster . It is important to read through all of the installation steps for your particular application prior to installing any equipment. Read through the instructions, visualize where all the equipment will need to be installed and do a soft installation before mounting any equipment .

  • Page 4: Installing A Wilson Electronics Outside Antenna

    . The antenna cable is small enough to easily tuck under the door seal or plastic molding . Tuck Cable Under Seal Contact Wilson Electronics Tech Support with any questions at 866-294-1660 Or email: tech@wilsonelectronics.com Hours: 7am to 6pm MST.

  • Page 5: Installing A Wilson Electronics Signal Booster

    . Attach the inside antenna cable to the FME- Male connector labeled “inside antenna” on the signal booster . Contact Wilson Electronics Tech Support with any questions at 866-294-1660 Or email: tech@wilsonelectronics.com Hours: 7am to 6pm MST.

  • Page 6: Installing The Low-Profile Antenna

    8 inches from all persons and must not be located in conjunction with any other antenna or signal booster . Contact Wilson Electronics Tech Support with any questions at 866-294-1660 Or email: tech@wilsonelectronics.com Hours: 7am to 6pm MST.

  • Page 7: Powering Up A Wilson Electronics Signal Booster

    . This prevents the signal booster from overloading or oscillating . Distance between antennas through a sunroof must be 5 feet or more . Contact Wilson Electronics Tech Support with any questions at 866-294-1660 Or email: tech@wilsonelectronics.com Hours: 7am to 6pm MST.

  • Page 8: Warnings And Recommendations

    . Use of a cellular signal booster with an antenna gain higher than 5 .12 dBi is in violation of FCC regulations for which the offender is fully liable . All Wilson Electronics mobile antennas are 5 .12 dBi or less in the 800 MHz band .

  • Page 9: Understanding The Signal Booster Lights

    DC power cable to reset the light . If it still shows red, repeat the procedure . Contact Wilson Electronics Tech Support with any questions at 866-294-1660 Or email: tech@wilsonelectronics.com Hours: 7am to 6pm MST.

  • Page 10: About Wilson Electronics

    . All products are engineered and assembled in the company’s 55,000-square-foot headquarters in St . George, Utah . Wilson Electronics has product dealers in all 50 states as well as in countries around the world .

  • Page 11: Guarantee And Warranty

    Wilson Electronics . Wilson Electronics shall, at its option, either repair or replace the product . Wilson Electronics will pay for delivery of the repaired or replaced product back to the original consumer if located within the continental U .S .A...

  • Page 12: Signal Booster Specifications

    Signal Booster Specifications Single Band Cellular Single Band iDEN 800 MHz Specifications 800 MHz Specifications Model Number 801101 804002 Connectors FME-Male Impedance (input/output) 50 ohms Dimensions 5 .5 x 4 .3 x 1 .4 inch or 14 x 10 .8 x 3 .5 cm Weight 1 .32 lbs or 0 .6 kg...
