Guide
Contents:
Guarantee and Warranty ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 1
How it Works ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 2
Before Getting Started ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 3
Installing the MagnetMount Antenna ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 4
Installing the Amplifi er ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 5
Installing the Cradle Plus ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 5
Powering Up a Wilson Amplifi er ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 7
Connecting the Earbud ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 7
Warnings and Recommendations ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 8
Understanding the Amplifi er Lights ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 9
About Wilson Electronics ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 10
Amplifi er Specifi cations ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ Back Cover
Mobile Wireless
Amplifi er Kit with
Phone Cradle
!
Warning: This manual contains
important safety and operating information.
Please read and follow the instructions
in this manual. Failure to do so could be
hazardous and result in damage to your
amplifi er.
Advertisement
Table of Contents
Related Manuals for Wilson Electronics 801213
Summary of Contents for Wilson Electronics 801213
-
Page 1: Table Of Contents
Amplifier Kit Amplifier Kit Installation Installation Installation Guide Mobile Wireless Amplifi er Kit with Phone Cradle Contents: Guarantee and Warranty ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 1 How it Works ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 2 Before Getting Started ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 3 Installing the MagnetMount Antenna ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 4 Installing the Amplifi er ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 5 Installing the Cradle Plus ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 5 Powering Up a Wilson Amplifi er ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 7 Connecting the Earbud ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 7 Warnings and Recommendations ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 8 Understanding the Amplifi er Lights ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 9 About Wilson Electronics ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ 10 Amplifi er Specifi cations ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ ∙ Back Cover Warning: This manual contains ... -
Page 2: Guarantee And Warranty
30Day MoneyBack Guarantee All Wilson Electronics products are protected by Wilson’s 30day moneyback guarantee. If for any reason the performance of any product is not acceptable, simply return the product directly to the reseller with a dated proof of purchase. 1Year Warranty Wilson Electronics amplifi ers are warranted for one (1) year against defects in workmanship and / or materials. Warranty cases may be resolved by returning the ... -
Page 3: How It Works
Installation Instructions for the Following Wilson Amplifi er: Mobile Wireless DualBand Amplifi er Model # 271245 Part # 801213 FCC ID: PWO8012SM IC: 4726A8012SM The term “IC” before the radio certifi cation number only signifi es that Industry Canada technical specifi cations were met. Inside this Package Wireless Cell Phone DC plugin Earbud amplifi er Cradle Plus power supply Adhesive/Screw MagnetMount Adhesive Airvent Bracket Swivel Bracket Antenna Bracket How it Works Your new Wilson Mobile Wireless Amplifi er Kit with Phone Cradle includes everything you need to begin enjoying improved cellular performance in mobile applications. Using this kit will amplify the signals to and from the cell phone that you place in its cradle, and will extend the range of other phones or cellular data cards in the vehicle. The kit includes the magnetmount outside antenna, one of Wilson’s most popular products, which will collect the signal from the cell tower and send it through the cable to the mobile wireless dualband amplifi er. The amplifi er’s stateoftheart technology is designed to ... -
Page 4: Before Getting Started
Before Getting Started This guide will help you properly install Wilson’s Mobile Wireless Amplifi er Kit with Phone Cradle. It is important to read through all of the installation instructions for this kit prior to installing any of the equipment. Read through this installation guide, visualize where all of the parts will be installed, and do a soft installation before mounting any equipment. If you do not understand the instructions in full, seek professional help, or contact Wilson Technical Support at 8662941660. ! Warning: In a wireless installation, Outside do not plug the amplifi er directly into the Antenna cell phone or data card using an antenna adapter. It will damage the amplifi er. Cell Phone Cradle Plus DC Power Supply Amplifi er 3 ... -
Page 5: Installing The Magnetmount Antenna
Installing the MagnetMount Antenna To receive the best cell signal, select a location in the center of the vehicle’s roof that is 12 inches away from any other antennas and free of obstructions. ! Warning: Do not use any type of glass mount antenna with this amplifi er. The outside antenna and Cradle Plus must be shielded from each other to prevent oscillation. The outside antenna must be installed vertically. Signal performance will be degraded if the antenna is not vertical. MagnetMount The antenna cable may be run through the Antenna door to the amplifi er. Warning: The outside antenna must have a separation of at least 10 inches from all persons during normal operation. For a more professionallooking installation, Carefully Run Cable the antenna cable may be run under the Pull Down Under door seal. Carefully pull down the door Door Seal Seal seal. Run the cable through the seal and push the seal back into place. This prevents constant wear and tear on the cable as the door opens and closes. The antenna cable is small enough to easily tuck under the door seal or plastic molding. Tuck Cable Under Seal 4 ... -
Page 6: Installing The Amplifi Er
Installing a Wilson Amplifi er ! Warning: Do not plug in the DC power supply until the outside and inside antenna cables are attached to the amplifi er. Select a location to install the amplifi er that is away from excessive heat, direct sunlight or moisture and that has proper ventilation. Recommended installation locations for the amplifi er are: · Under the seat · In the trunk · Under the dash Run the cable from the outside antenna and attach it to the FMEMale connector labeled “outside antenna” on the amplifi er. Attach the Cradle Plus cable to the FME Male connector labeled “inside antenna” on the amplifi er. Installing the Cradle Plus Option 1 Air Vent Bracket Insert the two vent clips into the circular hole in the bracket and slide them to each end of the slot. The fl at surface of the clips should face upwards. Slide the bracket clips into the chosen vent until they snap into place. If necessary, use a thinbladed screwdriver to gently pry the clips apart as they slide into the vent. Position the moveable arm at the base of the bracket to achieve the desired angle ... - Page 7 Option 2 Adhesive Bracket Clean the area where the bracket is to be mounted with rubbing alcohol and a soft cloth. Allow to dry. Peel the backing to expose the adhesive and press the bracket onto the desired location in the vehicle. Note: be sure the bracket is positioned vertically, not horizontally. Allow the adhesive to cure for 24 hours before you attach the cradle. Note: Once the cradle is attached, you can adjust the angle of the adhesive bracket by applying gentle pressure to the top or bottom of the cradle. Option 3 Adhesive/Screw Swivel Bracket Clean the area where the bracket is to be mounted with rubbing alcohol and a soft cloth. Allow to dry. For an adhesive mount, peel the backing to expose the adhesive and press the bracket onto the desired location in the vehicle. Allow the adhesive to cure for 24 hours before you attach the cradle. For a screw mount, use an ice pick or awl For best mounting results and long to punch through the adhesive and expose term performance, we suggest that the four screw holes in the bracket. You you choose a fl at smooth surface must provide the screws of an appropriate like the console area of your vehicle size for your particular application. Using between the two front seats. If this is the bracket as a template, mark the not available in your vehicle, you may locations for the screws as shown, drill pilot mount the cradle on the front of the holes and attach the bracket with screws. ...
-
Page 8: Powering Up A Wilson Amplifi Er
Powering up a Wilson Amplifi er Make sure both the outside antenna and Cradle Plus cables are connected before powering up the amplifi er. Connect the power cable from the DC plugin power supply to the amplifi er marked “Power” and insert the large end into DC power socket (the cigarette lighter outlet.) ! Warning: Use only the power Carefully insert the power cable. supply provided in this package. The power supply must be 6 V DC. The amplifi er may remain on all the time. However, leaving the amplifi er on in a vehicle when it is not running can discharge the battery in a day or two. A good option is to power the amplifi er through the ignition switch so the amplifi er IMPORTANT: Do not power up the ampli is turned on and off with the vehicle. fi er unless antenna cables are attached to amplifi er. Connecting the Earbud Plug the earbud into your cell phone and carefully place the earbud’s speaker into your ear. NOTE: The aluminum casing of a Wilson amplifi er will adjust very quickly to the ambient temperature of its environment. For example, in the summer, when the inside of a car can reach 140 degrees Fahrenheit, the amplifi er temperature may be 150 degrees or higher. The casing will be hot to the touch, similar to a metal door handle or a steering wheel. Such ... -
Page 9: Warnings And Recommendations
Warnings and Recommendations Warning: Do not plug the amplifi er directly into the cell phone or cellular data card using an antenna adapter. It will damage the cell phone or cellular data card. Warning: Do not plug in the DC power supply until the outside antenna and Cradle Plus cables are attached to the amplifi er. Warning: RF Safety: The Cradle Plus must be installed with a separation of at least eight inches from all persons and must not be located in conjunction with any other antenna or amplifi er. Warning: RF Safety: The outside antenna must be installed with a separation of at least 10 inches from any of the vehicle’s occupants or nearby persons and must not be located or operating in conjunction with any other antenna or amplifi er. All roofmount antennas should be centrally located on the roof of the vehicle. Mirrormount antennas should be at least six inches from the ground and leave at least 20 inches of separation from any persons near or around the vehicle. Use of this cellular amplifi er with an antenna gain higher than 6.12 dBi is in violation of FCC regulations for which the offender is fully liable. All Wilson mobile antennas are 6.12 dBi or less. Recommended amplifi er installation locations for a vehicle are: · Under the seat · In the trunk · Under the dash Power the amplifi er through the ignition switch so the amplifi er is turned on and off with the vehicle. ... -
Page 10: Understanding The Amplifi Er Lights
Understanding the Amplifi er Lights The power light PWR will turn green when the amplifi er is successfully powered up. When the 800 MHz or 1900 MHz lights are lit green, the amplifi er is amplifying the outside signal. If one or both frequency lights turn red, oscillation is occurring and the amplifi er has powered down. The outside antenna needs to be moved farther from the Cradle Plus. Move the outside antenna on the roof of the car to the rear of the car, but at least 812 inches from the rear or side windows. Remove power from the amplifi er and reinstall power this resets the amplifi er. If the lights are now green, the oscillation has stopped and the amplifi er is working. If the red light is still on, move the antenna farther away and repeat the process. Always use a magnetmount, mirror mount or roofmount antenna. Do not use a glassmount antenna, as oscillation may cause continuous shut down of the amplifi er. An amber light in either the 800 MHz or 1900 MHz position indicates overload from the cell site. The amplifi er has temporarily shut down and will automatically reset. -
Page 11: About Wilson Electronics
About Wilson Electronics Wilson Electronics, Inc. has been a leader in the wireless communications industry for nearly 40 years. The company designs and manufactures amplifi ers, antennas and related components that signifi cantly improve cellular telephone signal reception and transmission in a wide variety of applications, both mobile and inbuilding. With extensive experience in antenna and amplifi er research and design, the company’s engineering team uses a stateoftheart testing laboratory, including an anechoic chamber and network analyzers, to fi netune antenna designs and performance. For its amplifi ers, Wilson uses a double electrically insulated RF enclosure and cell site simulators for compliance testing. All products are engineered and assembled in the company’s 50,000squarefoot headquarters in St. George, Utah. Wilson has product dealers in all 50 states as well as Canada and Mexico, Central and South America. 10 ... -
Page 12: Amplifi Er Specifi Cations
Amplifi er Specifi cations Dual Band 800/1900 MHz Specifi cations Model Number / Part Number 271245 / 801201 Connectors FMEMale Impedance (input/output) 50 ohms Dimensions 5.6 x 3.6 x 1.7 inch or 14.2 x 9.1 x 4.4 cm Weight 1.44 lbs or 0.65 kg Frequency 824894 MHz / 18501990 MHz 1 Passband Gain (nominal) 800 MHz 40 dB (typical) / 45 dB (maximum) 1900 MHz 45 dB (typical) / 50 dB (maximum) 2 20 dB Bandwidth (nominal) 800 MHz (uplink/downlink) 53.5 MHz / 47.7 MHz 1900 MHz (uplink/downlink) 86 MHz / 83 MHz Power output for single cell phone (uplink) 800 MHz 1900 MHz CDMA +30.9 dBm +30.5 dBm GSM +30.0 dBm +29.7 dBm EDGE +30.4 dBm ...
