- Page 1 Instructions for Use KED602 Condenser Dryer...
-
Page 2: Table Of Contents
Thank you for your trust and for buying our condenser dryer. We congratulate you on your wise decision. This appliance is designed for drying clothes for home use only. The dryer enables quick drying of laundry, leaving clothes soft and fluffy without affecting the shape. Our appliances are environmentally friendly: some of the materials are recyclable while others are disposed of and destroyed. -
Page 3: Appliance Description
Appliance description 1. Front panel 5. Condenser 2. Drying program button 6. Cooling air slot 3. Water container 7. Legs 4. Door 8. Vent Technical data Dimensions of the appliance (w x d x h): 600 mm x 600 mm x 850 mm Weight (net): 43 kg Weight (gross): 45 kg Nominal voltage: 240 V, 50 Hz... -
Page 4: Warnings
Warnings It is not recommended to reduce the temperature or switch off the heater, as the drying time will be extended due to poor condensation of evaporated water. • Use the dryer to dry only laundry washed with water. Do not attempt to dry laundry, washed or cleaned with flammable detergents or solutions (gasoline, trichloroethylene etc.), as it may cause explosion. - Page 5 denatured alcohol, petrol/gasoline, kerosene, spot removers (some brands), turpentine, waxes and wax removers. • Items containing foam rubber (also known as latex foam) or similarly textured rubber. like materials should not be dried in a tumble dryer on a heat setting. Foam rubber materials can, when heated, produce fire by spontaneous combustion.
-
Page 6: Installation And Connection
To conceal the opening between the two appliances, a decorative trim (DECPL) is available. To order call your nearest Kleenmaid Store on 13 13 08. Do not place the appliance behind a lockable door, sliding door or door with hinges on the opposite side of the appliance. - Page 7 • Level the machine longitudinally and transversally by rotating the adjustable feet, thus enabling the leveling by +/- 1 cm. Vibrations, moving of the appliance and loud operation due to incorrect setting of the adjustable feet shall not be covered by this warranty. The appliance should be placed on a surface with concrete base;...
-
Page 8: Operation
Operation A - program selection jog D - START/PAUSE key B - MENU key E - display C - SELECTION key Program selection jog Program symbols Moisture level Cottons very dry Synthetics Delicates dry for storage Larger pieces of laundry slightly damp Quick program iron dry... - Page 9 Drying procedure Drying procedure Open the dryer door by pushing the left-hand side of the door towards the appliance. Sort the laundry according to the type of fabrics. Do up buttons and zippers, tie strings and pull out the pockets. Very delicate laundry should be put in a special laundry bag.
- Page 10 - Selecting language Press button C (SELECTION), and simultaneously turn the program selector jog A to the first clockwise position. Display indicates the default setting of language. Use button C (SELECTION) to select the desired language. Last selected language is stored. Turn the appliance off by turning the program selector jog A to the position “0”.
- Page 11 Lower temperature This function is selected if you wish to dry laundry at lower temperature than the program default (see Page 20 Program Chart). By selecting this function the drying time is longer. Use the C button to select. Certain programs do not allow selection of this function. After drying is completed, this function returns to the initial higher temperature.
- Page 12 - after drying is completed: By pressing the B button (MENU) for four seconds after the drying program is completed, the protection is switched off permanently. This means that it will remain inactive also the next time you start the drying procedure. Otherwise the protection remains active till the next drying process.
- Page 13 the beep signals the commencement of drying. • The display indicates different drying stages in their sequence, according to the selected program. EXAMPLE: Selected program: cotton, slightly moist, functions selected: delayed start, decreased temperature, child lock, no sound signal). Press the START button to confirm commencement of drying Press the START button to confirm commencement of drying (program starts when the delayed start time elapsed) (program starts when the delayed start time elapsed)
- Page 14 Interruptions Interruptions • By the user Changing the program or the functions After drying be careful when extracting laundry from the appliance, as it may be hot! Prior any changes child lock must be deactivated! By pressing button D (START/PAUSE) the drying program is paused;...
-
Page 15: Tips For Drying And For The Economic Use Of The Dryer
Special functions Special functions • Drum lamp The drum is illuminated when the appliance door is open. If the door is open for more than 5 minutes and no changes to the settings have been made, the lamp goes off. •... -
Page 16: Cleaning And Maintenance
Cleaning and maintenance Cleaning the filter Cleaning the filter • After every drying clean the filter, located in the inner part of the door. • Lift the filter lid (Fig.). • Pull your fingers over the filter to remove fibers and threads lining. - Page 17 • Open the exterior lid of the condenser by grabbing the handle on the lower left part of the appliance housing and pull it downwards. • Remove interior hatch by rotating the lever vertically down, tilt the hatch towards you and remove it. •...
-
Page 18: Troubles
Troubles External interferences (for example electrical wiring) could induce signalization of different faults. For example..- switch the appliance off, and wait for a few seconds; - switch the appliance back on and repeat the drying program. If the fault continues call an authorised service agent. Warranty shall not apply in case of failures due to interferences from the environment (lightning stroke, power supply circuit faults, natural disasters). -
Page 19: Tables
Tables Program chart Program Type of laundry Example of laundry COTTON max. load: 7 kg Very dry Thick or multiple layer laundry. Terry cloth, bathrobe Thick laundry not requiring ironing Terry cloth, tricot laundry Dry for storage Uniformly thick laundry, requiring little or no Terry cloth, tricot laundry ironing. -
Page 20: Additional Functions
Program chart / additional functions Program Additional functions Start Lower Anti- Heater Child Sound Drying in delay tempera- crease lock signal basket ture Cottons Synthetics Delicates Larger pieces of ... - Page 21 Table of textile symbols Drying Drying in dryer not permitted Drain, hang on washing line and dry Do not drain, hang wet and dry Drain, lay on a flat surface and dry Machine drying not permitted Drying at normal temperature Drying at lower temperature We reserve the rights to make any changes or mistakes in these operation instructions.
- Page 24 SP PG3,4 KLE 251823/en (11-08)
