DVR4E Contents
Before installation, please ensure you have all the parts listed below).
(
Additional DVR4E(PACK) Contents (
1 x 4ch Digital Video Recorder with 1TB Hard Disk Drive
● Advanced H.264 Video Compression Technology for High Quality Images
● Easy to Operate
● Can be Connected to a PC Network for Remote Viewing & Backup (Software on Disc)
1 x USB Mouse
● To operate the DVR
1 x IR Remote Control with batteries
● To operate the DVR
1 x HDMI Connection Cable
● Connect the DVR to a HDMI ready TV or Monitor
2 x Switch Mode Low Voltage Power Supplies
● 1 x 12v Power Supply for use with the DVR4E
● 1 x 12v Power Supply for use with the Power Split Cable to Power All Cameras (Pack)
Only included when purchased as with the DVR4EPACK)
4 x Day/Night Weatherproof Colour Cameras with Infrared LEDs - 20m Range
● IR LEDs for Viewing in Total Darkness up to 20m (B&W Mode)
● 650TVL Resolution
● Ideal for use Indoors and Out
4 x Camera Connection Cables
● Combined DC Power and Video Leads
● Pre-terminated - Allowing Simple Plug-in Connection – No Tools Required
● 2 x 10m, 1x 20m, 1 x 30m Leads Supplied
1 x Power Split Cable
● Allows You to Connect All 4 Cameras to 1 Power Supply
1 x Network Cable
● Allows You to Connect the LAN Port on the DVR to Your PC or Network to Facilitate
Remote Viewing or Backup Functions
