LANDING GEAR ASSEMBLY
(1)
Prebent Aluminum Main Gear Strut
(2)
Blow-Molded Wheel Pants
(2)
Main Gear Wheels
(2)
M4 x 16 Machine Screws
(2)
M4 x 35 Smooth-Shank Machine Screws
(8)
M4 Flat Washers
(2)
M4 Nylon Spacers
(6)
M4 Lock Nuts
(4)
M2 x 10 Wood Screws
ELEVATOR CONTROL SYSTEM
(1)
14-1/2" Threaded Wire w/90º Bend
(1)
13-1/2" Threaded Wire
(2)
Nylon Control Horns w/Backplates
(4)
M2 x 12 Machine Screws
(2)
Nylon Clevises
(1)
Nylon 90º Snap Keeper
(2)
Wheel Collars w/M3 x 8 Set Screws
(6)
C/A Style Hinges
ENGINE MOUNT ASSEMBLY
(2)
Engine Mounting Beams
(4)
M3 x 16 Socket-Cap Screws
(4)
M3 Blind Nuts
(4)
M3 x 25 Socket-Cap Screws
(4)
M3 Lock Nuts
(12) M3 Flat Washers
MISCELLANEOUS PARTS
(1)
Length of Clear Tubing
(1)
Decal Set
SECTION 4: METRIC CONVERSION CHART
1/64"
=
.4mm
1/32"
=
.8mm
1/16"
=
1.6mm
3/32"
=
2.4mm
1/8"
=
3.2mm
5/32"
=
4.0mm
6
Visit our website at http://modeltech.globalhobby.com or for Customer Service at http://globalservices.globalhobby.com
To convert inches into millimeters: Inches x 25.4 = mm
To convert millimeters into inches: Millimeters / 25.4 = in
3/16"
=
4.8mm
1/4"
=
6.4mm
3/8"
=
9.5mm
1/2"
=
12.7mm
5/8"
=
15.9mm
3/4"
=
19.0mm
RUDDER CONTROL SYSTEM
(2)
17" Threaded Wires w/90º Bend
(2)
Nylon Control Horns
(4)
M2 x 15 Machine Screws
(4)
M2 Hex Nuts
(2)
Nylon Clevises
(2)
Nylon 90º Snap Keepers
(3)
C/A Style Hinges
FUEL TANK ASSEMBLY
(1)
240cc Fuel Tank
(1)
Large Diameter Metal Plate
(1)
Small Diameter Metal Plate
(1)
Rubber Stopper
(1)
Fuel Pick-Up "Clunk"
(1)
M3 x 20 Machine Screw
(1)
Silicon Fuel Tubing
(2)
Aluminum Tubing
MISCELLANEOUS WING PARTS
(1)
Hardwood Wing Joiner
(1)
Plywood Wing-Screw Doubler
(2)
M4 x 35 Machine Screws
(2)
M4 Flat Washers
(2)
M4 Blind Nuts
MISCELLANEOUS FUSELAGE PARTS
(1)
Prepainted Molded Fiberglass Cowling
(1)
Molded Canopy
(1)
Spinner Assembly w/Wood Screws
(2)
M2 x 10 Wood Screws
(4)
M3 x 6 Wood Screws
(4)
M3 Flat Washers
1"
=
25.4mm
2"
=
50.8mm
3"
=
76.2mm
6"
=
152.4mm
12"
=
304.8mm
18"
=
457.2mm
21"
=
533.4mm
24"
=
609.6mm
30"
=
762.0mm
36"
=
914.4mm
