n Programmable function keys
The following functions can be assigned to [UP], [DOWN],
[P0], [P1], [P2], [P3] and [P4] programmable function keys.
Consult your Icom dealer or system operator for details con-
cerning your transceivers programming.
If the programmable function names are bracketed in the fol-
lowing explanations, the specific key is used to activate the
function depends on the programming.
CH UP AND DOWN KEYS
➥ Push to select an operating channel.
➥ Push to select a scan group after pushing and holding
[Scan A Start/Stop]/[Scan B Start/Stop].
ZONE KEY
Push this key, then push [CH Up] or [CH Down] to select the
desired zone.
What is "zone"?—The desired channels are assigned
into a zone according to the intended use for grouping.
For example, 'Staff A' and 'Staff B' are assigned into a
"Business" zone, and 'John' and 'Cindy' are assigned into a
"Private" zone.
PANEL DESCRIPTION
SCAN A START/STOP KEY
➥ Push to start and cancel scanning operation.
• When Power ON Scan function is activated, push to pause the
scanning operation. And the paused scan resumes after the
specified time period has passed.
➥ Push and hold this key for 1 sec. to indicate the scan list,
then push [CH Up] or [CH Down] to select the desired list.
(Available depending on the pre-setting.)
SCAN B START/STOP KEY
➥ Push to start and cancel scanning operation.
The scan restarts after the specified time period has
passed when the scan (started with this key) is cancelled
by except for this key operation.
➥ Push and hold this key for 1 sec. to indicate the scan list,
then push [CH Up] or [CH Down] to select the desired list.
SCAN ADD/DEL (TAG) KEY
Push to add or delete the selected channel to/from the scan
list.
1. Push to indicate the scan list, then push [CH Up] or [CH
Down] to select the desired list.
2. Push to add or delete the channel to/from the selected
scan list.
3. Push and hold for 1 sec. to exit the scan list selection
mode.
