User Manual
ATX Form Factor with Intel® Core 2 Duo, Pentium®
D/Pentium® 4/Celeron® D CPU FSB 533/800/1066MHz,
VGA, Dual Channel DDR2, FDD, LPT, 4 x SATA II,8 x USB2.0
and 6 x COM
Quick Installation Guide
Package Contents
IMBA-9454 package includes the following items:
1 x IMBA-9454 single board computer
1 x IDE Cable
2 x SATA Cable
1 x SATA Power Cable
2 x Dual RS-232 Cable
1 x I/O Shielding
1 x mini jumper pack
1 x Utility CD
1 x QIG (Quick Installation Guide)
IMBA-9454
Version 1.0
Feb 27, 2007
©2006 Copyright by IEI Technology corp.
All rights reserved.
1
Advertisement
Table of Contents
Related Manuals for IEI Technology IMBA-9454
Summary of Contents for IEI Technology IMBA-9454
-
Page 1: Quick Installation Guide
IMBA-9454 Quick Installation Guide Version 1.0 Feb 27, 2007 Package Contents IMBA-9454 package includes the following items: 1 x IMBA-9454 single board computer 1 x IDE Cable 2 x SATA Cable 1 x SATA Power Cable 2 x Dual RS-232 Cable... -
Page 2: Specifications
Specifications CPU: LGA 775 Intel® Core 2 Duo, Pentium® 4/ Celeron® D processor, FSB 533/800/1066MHz System Chipset: Intel® 945G + ICH7 BIOS : AMI BIOS Label System memory: 4 x 240-pin Dual channel DDR2 400/533/667MHz up to 4GB Ethernet: Dual Broadcom BCM5787M for PCI express GbE (LAN1 with ASF2.0 remote control support) I/O Interface: 8 x USB 2.0... -
Page 3: Ordering Information
Ordering Information IMBA-9454G-R10 ATX Motherboard with Intel® LGA 775, Core 2 Duo, Pentium® D/ Pentium® 4/ Celeron® D processor FSB 533/800/1066MHz, PCIe GbE, SATA II and Audio 32200-000017-RS: FDD Cable CB-USB02-RS: Dual USB Cable CB-USB14-RS: Four USB Cable CF-520-RS: CPU Cooler CF-775A-RS: CPU Cooler TPM-SI01-R10: 20-pin SINOSUN TPM Module, S/W Management Tool TPM-WI01-R10: 20-pin WINBOND TPM Module, S/W Management Tool... - Page 4 CN2: Multi Panel Description Description SPEAKER+ ACPILED+ ACPILED- ATX POWER BUTTON SPEAKER- IDE LED+ RESET SW IDE LED - CN3: Front Panel Audio Connector (2.54mm) Description Description MIC IN GND AUDIO MIC BIAS LINE OUT(R) LINE OUT(R) Return LINE OUT(L) LINE OUT(L) Return CN4: Audio Connector (2.54mm) Description...
- Page 5 FAN1: CPU Fan Connector FAN2~3: CPU Fan Connector Description Description +12V Linear control Linear control Fan Sensor Fan Sensor AUX1: Audio AUX IN (2.54mm) Description Description AUX IN_L AUX IN_R IDE1 (Blue): IDE Interface Connector Description Description RESET# DATA 7 DATA 8 DATA 6 DATA 9...
- Page 6 COM3~6: Serial Port 2 x 5 Box Header Connector Description Description COM2: Serial Port 2 x 7 Pin Header Connector Description Description TXD1+ TXD1- RXD1+ RXD1- USB3,USB4: 8-PIN Header USB Connectors Description USBD- USBD+ DIO1: Digital Input / Output Description Description Output0 Output1...
-
Page 7: Board Layout: Jumper And Connector Locations
Board Layout: Jumper and Connector Locations...
